CS125 Spring 2014 Interim Web design Match your sites purpose, target audience and design Web site organization Navigation Best practices Design principles Page layout Text design Graphic design Accessibility

slide-1
SLIDE 1

CS125 Spring 2014 Interim

Web design

  • Match your site’s purpose, target audience and design
  • Web site organization
  • Navigation
  • Best practices

– Design principles – Page layout – Text design – Graphic design – Accessibility

5-1

slide-2
SLIDE 2

CS125 Spring 2014 Interim

Design for your target audience

5-2

slide-3
SLIDE 3

CS125 Spring 2014 Interim

Web site organization

  • Hierarchical
  • Linear
  • Random or web organization

5-3

slide-4
SLIDE 4

CS125 Spring 2014 Interim

Hierarchical organization

  • Has a clearly defined home page
  • Navigation links to major site sections
  • Often used for commercial and corporate

web sites The organization or architecture of your web site has a significant impact on the ease or difficulty with which visitors navigate it and locate the information they are looking for. A site map is a graphical representation of all the pages and sections in a web site. For example, see the UWO Computer Science web site for a site map on a separate page and http://www.whitehouse.gov/ for a footer site map.

5-4

slide-5
SLIDE 5

CS125 Spring 2014 Interim

Hierarchical organization: Poor examples

5-5

slide-6
SLIDE 6

CS125 Spring 2014 Interim

Linear organization

Well-suited for sequential viewing of a series of pages, for example:

  • virtual tour
  • business presentation
  • tutorial

5-6

slide-7
SLIDE 7

CS125 Spring 2014 Interim

Random organization

If you want visitors to get lost in your site, maybe like wandering around in an art gallery or museum.

5-7

slide-8
SLIDE 8

CS125 Spring 2014 Interim

Best practices for web site navigation

  • Make your site easy to navigate

– Provide clearly labeled navigation in the same location on each page: Most common locations are across the top or down the left side – Provide breadcrumb navigation (see CS web site) – Types of navigation: graphics-based, text-based, interactive navigation technologies (image roll-overs, Flash, fly-out or dropdown menus)

  • Accessibility : provide plain text links in the page footer when the main navigation is

non-text media such as images, Flash, or DHTML

  • Use a table of contents with links to other parts of the page (for long pages)

– Create bookmarks inside your document using a fragment identifier or named fragment e.g., in page book.html: <h1 id="C4">Chapter 4</h1> Then link to it from anywhere else: ∗ within book.html: <p><a href="#C4">See also Chapter 4</a></p> ∗ in any other page: <p><a href="book.html#C4">See also Chapter 4</a></p>

  • Consider breaking long pages into multiple shorter pages using, e.g., linear organization
  • Large sites should have a site map and/or site search feature

5-8

slide-9
SLIDE 9

CS125 Spring 2014 Interim

Design principles

  • 1. Repetition
  • Repeat visual elements (shapes, colors, fonts, images) throughout the design
  • Take advantage of consistency, avoid surprises for users
  • 2. Contrast
  • Ease of reading
  • Add visual excitement and draw attention
  • 3. Proximity
  • Group related items together
  • Minimize movement (eye, mouse) and cognitive load
  • 4. Alignment
  • Align visual elements (shapes, images, text) to create visual unity

5-9

slide-10
SLIDE 10

CS125 Spring 2014 Interim

Web page design: Best practices

Web site development requires strong design skills: good looking and easy to use web sites are not easy to develop! The web imposes additional constraints:

  • Load time:

– Try to limit your web page document and associated media to under 60K on the home page; how? – Minimize perceived load time, that is, the amount of time the user is aware of waiting; how?

  • Place the most important information ”above the fold:” what does this mean?
  • What is the most valuable “real estate” on a web page?
  • Avoid horizontal scrolling: use a page layout whose width is a percentage (100% or

less) of the width of the browser window

  • Use adequate white space: why?
  • Design for your target audience:

appropriate reading level of text (writing style, vocabulary, etc.), appropriate use of color (based on age, but remember also the accessibility guidelines on slide 3-6), appropriate use of animation

  • Web pages do NOT look the same in all the major browsers

5-10

slide-11
SLIDE 11

CS125 Spring 2014 Interim

– Design to look best in the browser(s) of choice and degrade gracefully (i.e., look OK) in others

  • Screen resolutions vary as well

– Widely used: 800x600, 1024x768, 1280x1024; getting larger and larger, except. . . – Consider centering your page contents Design for the Mobile Web

  • Small screen size
  • Scrolling
  • Low bandwidth
  • Fonts and colors
  • Navigation

5-11

slide-12
SLIDE 12

CS125 Spring 2014 Interim

Page layout

A wireframe is a sketch or blueprint of a web page that shows the structure of the basic page elements, including logo, navigation, main content and footer.

5-12

slide-13
SLIDE 13

CS125 Spring 2014 Interim

Popular page layout design techniques

  • 1. Ice design

www.msn.com

  • Also called ’rigid’ or ’fixed’ design because the page does not change its width when

the browser window is resized.

  • Page content is left-aligned
  • The chosen width makes the contents fit nicely in the browser window at the

minimum resolution at which the site is supposed to be viewed.

  • 2. Jello design
  • Page content has fixed size but is centered.
  • 3. Liquid design
  • Page expands to fill the browser at all resolutions.

What are the pros and cons of these designs?

5-13

slide-14
SLIDE 14

CS125 Spring 2014 Interim

Text design

  • Avoid long blocks of text; instead use bullet points, headings and sub-headings, and

short paragraphs

  • Use common fonts: Arial, Helvetica, Verdana (sans-serif fonts are easier to read on a

monitor), Times New Roman

  • Use appropriate text size: medium, 1em, 16px, 12pt, 100%
  • Use strong contrast between text and background
  • Use columns instead of wide areas of horizontal text
  • Bold text as needed
  • Avoid “click here”
  • Hyperlink key words or phrases, not entire sentences
  • Separate text with white or empty space
  • Check your spelling and grammar

5-14

slide-15
SLIDE 15

CS125 Spring 2014 Interim

Graphic design

  • Avoid large graphics
  • Use the alt attribute to supply descriptive alternate text
  • Be sure your message gets across even if images are not displayed
  • If using images for navigation, provide plain text links at the bottom of the page
  • Use animation only if it makes the page more effective; also provide a text description
  • Choose colors on the web palette if consistency across all (including older)

Windows/Mac platforms is needed

  • Use anti-aliased text in images:
  • Use only necessary images
  • Reuse images

5-15

slide-16
SLIDE 16

CS125 Spring 2014 Interim

Design for accessibility

Check out the WCAG 2.0 at: http://www.w3.org/TR/WCAG20/Overview and http://www.w3.org/WAI/WCAG20/quickref Goal: Universal/inclusive design Based on four principles (POUR): See Appendix E

  • Perceivable

– Content must be Perceivable

  • Operable

– Interface components in the content must be Operable

  • Understandable

– Content and controls must be Understandable

  • Robust

– Content should be Robust enough to work with current and future user agents, including assistive technologies

5-16

slide-17
SLIDE 17

CS125 Spring 2014 Interim

Check your work

  • Use a spell-cheker (ha ha)
  • Check your grammar
  • Validate your HTML:

http://validator.w3.org/

  • Validate your CSS:

http://jigsaw.w3.org/css-validator/

  • Test for Accessibility:

– Worldspace Online: http://worldspace.deque.com/ – University of Toronto http://achecker.ca/checker/index.php

5-17
