WASTEWATER GRIT EFFECTS, MANAGEMENT, AND REMOVAL PRESENTED BY MARK - PowerPoint PPT Presentation

WASTEWATER GRIT EFFECTS, MANAGEMENT, AND REMOVAL PRESENTED BY MARK MANN, P.E. WHAT IS GRIT? Inert material, both organic and inorganic, that is not benefitted by secondary treatment or sludge processing. WHAT IS GRIT? Majority of particles


  1. WASTEWATER GRIT EFFECTS, MANAGEMENT, AND REMOVAL PRESENTED BY MARK MANN, P.E.

  2. WHAT IS GRIT? Inert material, both organic and inorganic, that is not benefitted by secondary treatment or sludge processing.

  3. WHAT IS GRIT? Majority of particles fall in 75-150 micron range.

  4. HOW SMALL IS THAT? • Grit Particles: Majority 75-150 micron • Typical Raindrop: 2000 microns

  5. HOW SMALL IS THAT? • Grit Particles: Majority 75-150 micron • Human Hair: 70-100 microns

  6. EXAMPLES OF GRIT Inorganic Sand Gravel Cinders Asphalt Concrete

  7. EXAMPLES OF GRIT Inorganic Organic Sand Eggshells Gravel Seeds Cinders Bone Chips Asphalt Coffee Grounds Concrete

  8. CHARACTERISTICS OF GRIT • Higher specific gravity than treatable organic solids. • Particle shape can be spherical, flat, or angular.

  9. WHERE DOES GRIT COME FROM? The Collection System • Materials that are flushed by homeowners • Infiltration/Inflow

  10. WHERE DOES GRIT COME FROM?

  11. WHERE DOES GRIT COME FROM? Within the Plant •Fixed film predators •Wind blown sand and dust •Damaged piping

  12. HOW DOES GRIT AFFECT MY PLANT? Disrupts biological processes and reduces effluent quality

  13. HOW DOES GRIT AFFECT MY PLANT? Disrupts biological processes and reduces effluent quality • Wear and tear on mechanical equipment

  14. HOW DOES GRIT AFFECT MY PLANT? Disrupts biological processes and reduces effluent quality • Increase in energy demand

  15. HOW DOES GRIT AFFECT MY PLANT? Disrupts biological processes and reduces effluent quality • Reduction of treatment capacity

  16. HOW CAN GRIT BE MANAGED? , or Both Removal , Mitigation

  17. GRIT REM GRI REMOVAL WHERE SHOULD GRIT BE REMOVED? Option 1: Head of Plant -Better protection of process equipment -Larger unit required to handle full flows -Additional protection or removal may be needed after fixed film treatment processes

  18. GRIT REM GRI REMOVAL WHERE SHOULD GRIT BE REMOVED? Option 2: Sludge Stream -Located prior to thickener or digester -Solids concentration should not exceed 2% TS -Protection of upstream process equipment and tanks may be required

  19. GRIT REM GRI REMOVAL WHERE SHOULD GRIT BE REMOVED? Option 3: Multiple Locations -Protects upstream process equipment and basins -Removes grit generated within the plant prior to sludge digestion -Cost may be prohibitive

  20. GRI GRIT REM REMOVAL WHERE SHOULD GRIT BE REMOVED? No matter which option is selected, bar screening is required.

  21. GRI GRIT REM REMOVAL SELECTING GRIT REMOVAL OPTIONS PLANT FACTORS • Range of Flow •Allowable Headloss • Type of Treatment •Grit Testing Results Process •Other Benefits to • Location of Grit Treatment Removal

  22. GRI GRIT REM REMOVAL SELECTING GRIT REMOVAL OPTIONS REMOVAL SYSTEM FACTORS • Particle Size Range • Equipment and Energy Requirements • Maintenance Requirements

  23. GRIT REM GRI REMOVAL SELECTING GRIT REMOVAL OPTIONS OTHER FACTORS GRIT OPERATIONAL • Source of Grit • Maintenance Requirements • Size of Particles • Construction Cost • Age and Maintenance of System

  24. GRI GRIT REM REMOVAL OVERVIEW OF REMOVAL OPTIONS • Detridus Tank/Channel • Aerated Chamber • Hydraulic Vortex/Stacked Tray • Mechanical Vortex

  25. GRI GRIT REM REMOVAL OVERVIEW OF SYSTEM ELEMENTS

  26. GRI GRIT REM REMOVAL OVERVIEW OF SYSTEM ELEMENTS

  27. GRI GRIT REM REMOVAL OVERVIEW OF SYSTEM ELEMENTS

  28. GRI GRIT REM REMOVAL OVERVIEW OF SYSTEM ELEMENTS

  29. GRI GRIT REM REMOVAL DETRITUS/ SEDIMENTATION TANK OR CHANNEL

  30. GRI GRIT REM REMOVAL AERATED GRIT CHAMBER

  31. GRI GRIT REM REMOVAL HYDRAULIC VORTEX Stacked Tray

  32. GRI GRIT REM REMOVAL MECHANICAL VORTEX

  33. GRIT M MITIGATION WHAT IF REMOVAL ISN’T AN OPTION? There are several ways to mitigate the effects of grit in the wastewater stream.

  34. GRIT M MITIGATION WHAT IF REMOVAL ISN’T AN OPTION? Hardening of Exposed Equipment - Pump Impellers - Clarifier Scrapers

  35. GRIT M MITIGATION WHAT IF REMOVAL ISN’T AN OPTION? Frequent Basin Cleaning - Manual Removal/Liquidization - Combination Trucks

  36. GRIT M MITIGATION WHAT IF REMOVAL ISN’T AN OPTION? Aeration: Fine Bubble vs Coarse Bubble - Grit migration into diffuser heads

  37. GRIT M MITIGATION WHAT IF REMOVAL ISN’T AN OPTION? Predator Control for Trickling Filter/Fixed Film Treatment - Toxic chemicals (short term) or adverse environmental conditions

  38. A BIG THANK YOU TO THE FOLLOWING CONTRIBUTORS: City of Orange City of Beaumont Smith & Loveless Hydro International MARK MANN, P.E. mmann@spi-eng.com 409-866-0341

  39. MARK MANN, P.E. mmann@spi-eng.com 409-866-0341
