w w w . p a x . u s CONTENTS BUSINESS UPDATE 1 PAX Global - PowerPoint PPT Presentation

Dec 21, 2022 •487 likes •841 views

D R I V I N G P A Y M E N T I N N O V A T I O N w w w . p a x . u s CONTENTS BUSINESS UPDATE 1 PAX Global Technologys Worldwide Performance THE FUTURE OF PAYMENT 2 Cameras, New Mobile Payment Methods, Android

  1. D R I V I N G P A Y M E N T I N N O V A T I O N w w w . p a x . u s

  2. CONTENTS BUSINESS UPDATE 1 PAX Global Technology’s Worldwide Performance THE FUTURE OF PAYMENT 2 Cameras, New Mobile Payment Methods, Android & Cloud Solutions PRODUCT PORTFOLIO 3 Terminal Hardware & Software Solutions

  3. 01 Worldwide Performance

  4. The World’s Leading Payment Terminal Provider PAX has over 17 million terminals installed worldwide with direct offices & channel partners in over 120 countries MORE INNOVATIVE MORE COST EFFECTIVE OFFERING SUPERIOR QUALITY PAX h has a wider p product p portfolio t than all Com omparatively s y spea eaki king, PAX g guarantees es Customers constantly tell u us o our p products h have competitors c combined & & a a reputation f for b bringing the b best prices f for t termina nals w with l h latest the l lowest f failur ure rates & & that w we provide de t the inno nnova vative ve s solut utions s to market f fast stest st technology & & f full industry certifications best t technical s support

  5. The World’s Fastest Growing Payment Terminal Brand 2016 Terminal Shipments

  6. The World’s Most Trusted Payment Terminal Team NORTH AMERICA • Over half a million PAX terminals now installed • PAX team includes key former Verifone & Hypercom personnel • Strong demand on EMV migration for PAX’s more innovative portfolio

  7. 02 The Future of Payment

  8. we are experiencing a new phenomenon in the world of payments whereby merchants who switch to android smartpos will never go back to using traditional terminals

  9. so we created the as an in-house or hosted appstore , a customizable market place for distributing apps to merchants , creating new revenue streams

  10. around the world we are seeing the convergence of technology and payments in everyday devices

  11. 03 Product Portfolio

  12. T h e f a s t g r o w i n g P O S t e r m i n a l & s o l u t i o n s u p p l i e r Current Products Innovative Cost effective Superior Quality S80 S500 D180 S500-EXT S90 S300 SP30 S920 D210 D200 Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  13. Countertop Payments S80 S500 A80 (Q (Q2, 2, 2018) 2018) Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  14. Mobile Payments D210 S920 A920 Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  15. MPOS Terminals D180 D200 D220 A60 (Q3, 2018) Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  16. PIN pads SP30 S300 SP20v4 Q30 (Q2, 2018) Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  17. Integrated POS / Payment terminals Integrated “Combination” POS / Payment terminals PRICE • High-performance Android based tablets. • Separate Consumer & Merchant facing displays. • Integrated printer options. • Single reader for Magnetic Stripe & Smart Cards. • NFC Contactless Reader. • Dual cameras – for QR & Barcode scanning Guest Facing display Cast member Facing display E800 (Q2, 2018) E500 (Q4, 2017) E600 (Q1, 2018) FUNCTIONALITY 17

  18. Upcoming Products Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  19. A920 Intelligence of an ECR in a handheld point-of-sale OS Android 5.1 Processors ARM Cortex A7 1 GHz App + Cortex M4 Security Processor Memory 8GB Flash + 1GB RAM, Micro-SD up to 32GB Display 5" Capacitive Touch Screen, 1280*720 WXGA Printer 40mm paper roll, 30 line/s Communication 4G LTE + Wi-Fi + BT Slots 2 SAMs, 1 SIM, 1 Micro USB, 1 Micro SD Geographic GPS Battery Long lasting 5250mAH Dock Optional Charging or Multi Com Cameras Rear-facing Autozoom 5 MP & Front-facing fixed 0.3 MP

  20. A80 Next in Countertop Payments OS Android 6.0 Processors ARM Cortex A7 1 GHz App + Cortex M3 Security Processor Memory 8GB Flash + 1GB DDR3, Micro-SD up to 32GB Display 4" Capacitive Touch Screen, 800*480 Printer Thermal High Speed with 50mm paper roll Communication LAN, Wi-Fi, Bluetooth & Dial Slots 1 SIM & 2 SAMs Security PCI PTS 5.x Battery Backup 1440mAH Keypad 10 Numeric & 5 Function Keys Camera Front-facing fixed 0.3 MP

  21. A60 Mobile Payment Acceptance for Any Business OS Android 6.0 Processors ARM Cortex A7 1.3 GHz App + Cortex M3 Security Processor Memory 8GB Flash + 1GB RAM Display 4.5" Capacitive Touch Screen, 1280*720 Communication 4G LTE + Wi-Fi + BT Slots 1 SIMs, 2 SAM, 1 Micro USB & 1 Micro SD Geographic GPS Motion Accelerometer Battery 3350mAH Base Multi-Com Cameras Rear-facing Autozoom 5 MP & Front-facing fixed 0.3 MP

  22. Q30 Next Generation Smart Pin pad Processor 32 bit, 1GHz Cortex A9 Memory 512 MB Flash, 512 MB DDR SDRAM Display 4” 800x480 Color Touch Screen Keypad 10 numeric & 3 function keys Contactless NFC with PIN entry Ports 1 RS232, 1 LAN & 1 USB Security PCI PTS 5.x with SRED Dimensions 7.8 in. long x 4.4 in. wide x 2 in. high Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  23. D220 The power of mobile payments in a Smartphone form factor OS ProLin Processor Cortex-A9 1 GHz Memory 512MB Flash + 512MB DDR RAM Display 4”Capacitive Touch Screen, 480*800 WVGA Keypad Virtual numeric keypad Dock Wireless Charging Dock(Optional) Communication WIFI + BT + 4G LTE/3G Security PCI PTS 4.x with SRED Physical Dimension: 136.5mm(L) * 70mm(W) * 17.4mm(H) Battery Li-ion battery 3050mAh Camera 2D Rear-facing Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  24. E Series Overview Confidential & Proprietary to PAX Technology, Inc. For internal distribution only.

  25. E500, E600 & E700 Screen Size Comparison E500 E600 E800 Screen Options Merchant Facing Consumer Facing

  26. Q20 E600 Fully Certified Payment Terminal Peripheral OS Prolin Processors ARM Cortex A7 1 GHz App + Cortex M3 Security Processor Q20 Memory 128MB Flash + 256MB RAM Display 4" Capacitive Touch Screen, 480*272 Communication USB; device powered via USB Slots N/A Security PCI PTS 5.x including SRED and EMV L1 & L2 E800 Keypad Integrated PIN on Glass E500

  27. E500 All in one Android Tablet and Integrated Payment Device Consumer Facing: Q20 - Prolin (Linux) - Electronic payment OS Android 6.0 Processors Quad-core Cortex A53, 1.2GHz Merchant Facing Display: Memory 8GB Flash + 1GB RAM - Android tablet Display Tablet: 8” Capacitive Touch Screen, 1200*800 - POS Q20: 4" Capacitive Touch Screen, 480*272 Communication RS232 (RJ45), Micro-USB; 2 x USB Type A, Cash Drawer RJ11device HDMI, 2 x Ethernet (RJ45), Audio Wireless WiFi 802.11b/g/n, 2.4GHz, Hot-Spot, Bluetooth 4.1, 4G LTE Slots Dual SIM, Micro-SD Camera Clerk: 2MP fixed focus, Consumer: 5MP auto zoom and focus Security PCI PTS 5.x including SRED and EMV L1 & L2 Battery 3.7V / 2600mAH, Lithium-ion Printer 3” high speed, 150mm/sec, thermal, auto paper cutter

  28. E600 Merchant Facing Display: - Android tablet - POS Mobile Tablet and Integrated Payment Device OS Android 7.1 Processors Quad-core Cortex A53, 1.4GHz Memory 8GB Flash + 1GB RAM Display Tablet: 8” Capacitive Touch Screen, 1200*800, Portrait Q20: 4" Capacitive Touch Screen, 480*272 Consumer Facing: Q20 Communication RS232 (RJ45), Micro-USB; Ethernet (RJ45), Audio - Prolin (Linux) Wireless WiFi 802.11b/g/n, 2.4GHz, Hot-Spot, Bluetooth 4.1, 4G LTE - Electronic payment Slots Dual SIM, Micro-SD Camera Clerk: 0.3MP fixed focus, Consumer: 5MP auto zoom and focus Security PCI PTS 5.x including SRED and EMV L1 & L2 Battery 7.4V / 5200mAH, Lithium-ion Printer 2” high speed, 100mm/sec, thermal

  29. E800 Guest Facing Display: Large Display Point of Sale with Integrated Payment Device - Android tablet - POS OS Android 6.0 Processors Quad-core Cortex A17, 1.8GHz Memory 16GB Flash + 2GB RAM Display Merchant Tablet: 15.6” Capacitive Touch Screen 1920*1080 Consumer Tablet: 8” Capacitive Touch Screen, 1200*800 Q20: 4" Capacitive Touch Screen, 480*272 Cast Member: Communication RS232 (DB9), Micro-USB, 5 x USB type A, Cash Drawer, 24v RJ11, - Q20 (Payment) HDMI, 2 x Ethernet (RJ45), WAN (RJ45), Audio - 8” Consumer Wireless WiFi 802.11b/g/n, 2.4GHz, Hot-Spot, Bluetooth 4.1, 4G LTE Communication Slots Dual SIM, Micro-SD & interaction Camera 5MP auto zoom and focus Security PCI PTS 5.x including SRED and EMV L1 & L2 (Q20) Battery 7.4V / 2600mAH, Lithium-ion Printer 3” high speed, 150mm/sec, thermal, auto paper cutter

  30. 04 Terminal Management

  31. BroadPOS Cloud based Estate Management Tool Easy to use WEB-based architecture allows users to perform business management anywhere at anytime Manage a variety of terminal software resources: OS, font/language libraries, applications, parameters and data files Simultaneous downloads and cluster deployments, terminal grouping and batch deployment of terminal tasks Define download schedules and uniformly distribute terminal download plans Allows flexible administrator and user privilege management. Offers enhanced data reporting capabilities for business analysis and service improvement.
