VMware Backup & Replication using Vembu VMBackup
About Vembu Technologies Founded in 200 2 4000+ Channel Partners Private Company Reached more than 60,000 businesses Profitable since 2006 70 % of our customers are from North America, 20% from Europe and the rest 10% HQ in Chennai, India from APAC 2
Vembu BDR Suite Vembu BDR suite is an one stop solution to all your backup and DR Vembu BDR Suite needs - catering every requirement of small and medium businesses. Backup & Replication for VMware and Hyper-V ● VMBackup Backup and Bare-metal recovery for Physical Windows Server & ● Desktops Image Backup Backup solution for file/folders, applications like exchange, SQL, ● NetworkBackup SharePoint, AD, MySQL etc., Backup solution for file/folders, applications like exchange, SQL, ● OnlineBackup SharePoint, AD, Outlook and etc. directly to Vembu Cloud Backup Solution for SaaS Applications like Office 365 and Google ● SaaSBackup Apps 3
Why Vembu VMBackup? Challenges Backing up a Virtual & Physical server typically is more expensive and difficult to ● manage As we all know that it requires a fundamentally different approach ● Solution Vembu VMBackup is exclusively designed for Virtual & Physical Environments ● by the experts in the industry Vembu fills a purpose here to be the best of breed technology in providing ● manageable solution in affordable cost for both physical and virtual servers along with the applications that resides in the system and also optional Cloud Disaster Recovery. 4
VMware Backup - Architecture vCenter Server Vembu VMBackup agent will communicate with VMware ESXi production storage and ● backup the VM data VMBackup works as a proxy between ESXi host and Vembu BDR Backup Server ● VM data will be compressed and encrypted on-fly ● VM data will be compressed and encrypted at rest on Storage Repositories ● 5
VMware Replication - Architecture Vembu VMBackup agent will communicate with VMware ESXi production storage and ● replicate the VM data to another ESXi host VMBackup works as a proxy between both the ESXi hosts ● Replicated VM will be in power-off mode ● Supports VM Failover and Failback ● 6
Backup Transport Modes Vembu VMBackup proxy agent transfers the VM data through different modes. ● Based on the agent installation and VMware environment, VMBackup agent automatically choose any one of following transport mode. Direct SAN Mode ○ Hot-Add Mode ○ Network Mode ○ You can configure the Vembu VMBackup agent to use any one of above mode ● permanently 7
Direct SAN Transport Mode Metadata Request Metadata Response Metadata Response SAN Data Transfer Vembu VMBackup agent should have access to the SAN environment. It works on both ● physical server/FC or VM/iSCSI. VMBackup agent directly read the data which needs to backup from the SAN and send ● them to Vembu BDR Backup Server's storage repositories 8
Hot-Add Transport Mode Data Transfer vCenter Server Vembu VMBackup agent needs to be installed on anyone of the Windows VM running on an ● ESXi host or vCenter. During the backup, the virtual disk of the VM will be directly attached to the VM where we ● have installed VMBackup agent. Then VMBackup agent read the attached disks and send the backup data to Vembu BDR ● Backup Server's storage repositories. 9
Network Transport Mode Request Data Transfer Response Vembu VMBackup agent can be either installed on physical or virtual machine. ● After receiving the request from the VMBackup agent, ESXi host will send the data to the ● VMBackup agent. Then VMBackup agent transmits the data over the TCP/IP connection. ● The data transfer speed will be lower than other two modes ● 10
Recovery Scenarios Instant Virtual Machine Recovery ● Instant file-level recovery ● Instant granular recovery tools for Microsoft Applications, such as Exchange, ● SQL, Active Directory and SharePoint Direct restore to ESXi host ● Disk level restore ● V2V migration (migrate a VM from VMware to Hyper-V or KVM) ● Failover and Failback ● 11
Live Demo 12
Thank You USA & CANADA +1-512-256-8699 Toll Free Phone USA & CANADA +1-844-312-5773 UNITED KINGDOM +44-203-793-8668 Email vembu-sales@vembu.com vembu-support@vembu.com www.vembu.com 13
