Vacuum Lumber Drying Presented by, Jim Parker Bring your Cash Flow - PowerPoint PPT Presentation

Vacuum Lumber Drying Presented by, Jim Parker Bring your Cash Flow out of the woods EFFICIENCY QUALITY SPEED This is what your calendar looks like now EFFICIENCY QUALITY SPEED APRIL 2014 SUN MON TUES


  1. Vacuum Lumber Drying Presented by, Jim Parker Bring your Cash Flow out of the woods EFFICIENCY � QUALITY � SPEED

  2. This is what your calendar looks like now EFFICIENCY � QUALITY � SPEED

  3. APRIL 2014 SUN MON TUES WED THURS FRI SAT SAW GET DRY DRY DRY DRY LOG ORDER DRY DRY DRY DRY DRY DRY DRY DRY DRY DRY DRY DRY DRY DRY SHIP DRY DRY ORDER EFFICIENCY � QUALITY � SPEED

  4. This is what the Vacutherm Calendar looks like EFFICIENCY � QUALITY � SPEED

  5. APRIL 2014 SUN MON TUES WED THURS FRI SAT SAW GET SHIP DRY DRY Go fishing Go fishing LOG ORDER ORDER SAW GET SHIP DRY DRY Go fishing Go fishing LOG ORDER ORDER SAW GET SHIP DRY DRY Go fishing Go fishing LOG ORDER ORDER SAW GET SHIP DRY DRY Go fishing Go fishing LOG ORDER ORDER EFFICIENCY � QUALITY � SPEED

  6. EFFICIENCY � QUALITY � SPEED

  7. Drying Time Comparison Drying 4/4 Hard Maple 80 % Moisture Content 60 VacuPress from Green 40 Conventional from Green 20 0 0 1 1.5 2 3 4 5 6 7 8 9 10 11 12 13 Days EFFICIENCY � QUALITY � SPEED

  8. Drying Times Drying time (hours) Species 4/4 5/4 6/4 8/4 10/4 12/4 Maple 30 35 42 48 96 140 Birch 40 48 55 70 120 192 Red Oak (40%) 24 36 48 96 168 240 Walnut (40%) 45 50 58 65 115 168 White Pine 24 30 38 48 55 96 EFFICIENCY � QUALITY � SPEED

  9. Production Comparison vs Conventional Steam Kiln VacuPress 4000 Capacity 50,000 bf 4,000 bf Drying Time 15 days 30 Hours (4/4 Hard Maple) Annual Throughput 1,166,666 bf 1,120,000 bf (350 days) EFFICIENCY � QUALITY � SPEED

  10. EFFICIENCY � QUALITY � SPEED

  11. Production Throughput • Eliminates the ‘bottleneck’ • Increases responsiveness to market • Just-in-Time Inventory/production • Cash flow Machine EFFICIENCY � QUALITY � SPEED

  12. EFFICIENCY � QUALITY � SPEED

  13. VACUPRESS 8000 INSTALLATION EFFICIENCY � QUALITY � SPEED

  14. EFFICIENCY � QUALITY � SPEED

  15. EFFICIENCY � QUALITY � SPEED

  16. EFFICIENCY � QUALITY � SPEED

  17. CLICK ME EFFICIENCY � QUALITY � SPEED

  18. Contact Heating Aluminium hot water heating plate The hot water heating plates or heated air (for AirVac) heat the wood very efficiently and help drive the moisture out. EFFICIENCY � QUALITY � SPEED

  19. The “Press” in VacuPress Atmospheric Pressure (29.92 in Hg.) The rubber membrane holds the lumber flat and straight with 1200lbs/sqft Low Pressure (4 in Hg.) Atmospheric Pressure (29.92in Hg) EFFICIENCY � QUALITY � SPEED

  20. RESULTS Red Oak #2 COM 43%-6% 24hrs EFFICIENCY � QUALITY � SPEED

  21. EFFICIENCY � QUALITY � SPEED

  22. EFFICIENCY � QUALITY � SPEED

  23. EFFICIENCY � QUALITY � SPEED

  24. EFFICIENCY � QUALITY � SPEED

  25. The “Press” in VacuPress • Appox. 1200 lbs per foot of pressure • Does not affect dimension of wood • Prevents: • Cup • Bow • Twist • Crook • Can Eliminate cup, bow and twist already in lumber EFFICIENCY � QUALITY � SPEED

  26. VacuPress Equipment Costs Drying 4/4 Hard Maple Model Cost per Bf of production (paid for over 5 years + interest) VacuPress 500 $0.09 VacuPress 1000 $0.05 VacuPress 2500 $0.04 VacuPress 4000 $0.03 VacuPress 8000 $0.02 EFFICIENCY � QUALITY � SPEED

  27. EFFICIENCY � QUALITY � SPEED

  28. EFFICIENCY � QUALITY � SPEED

  29. EFFICIENCY � QUALITY � SPEED

  30. • Circulated Hot Air • Stickered Pack of Lumber • Track or Side Loaded • Cold Water EMC Control EFFICIENCY � QUALITY � SPEED

  31. EFFICIENCY � QUALITY � SPEED

  32. EFFICIENCY � QUALITY � SPEED

  33. EFFICIENCY � QUALITY � SPEED

  34. EFFICIENCY � QUALITY � SPEED

  35. AirVac 40 (40,000 Board Feet) EFFICIENCY � QUALITY � SPEED

  36. EFFICIENCY � QUALITY � SPEED

  37. AirVac Drying time (DAYS) Species 4/4 8/4 12/4 Maple 4 8 14 Birch 4 8 15 Red Oak 5 10 20 Walnut 5 10 20 White Pine 2 4 6 EFFICIENCY � QUALITY � SPEED

  38. AirVac Equipment Costs Drying 8/4 Hard Maple Model Cost per Bf of production (paid for over 5 years + interest) AirVac2.5 $0.20 AirVac4 $0.17 AirVac8 $0.15 AirVac20 $0.08 AirVac40 $0.07 EFFICIENCY � QUALITY � SPEED

  39. Total Energy Cost Wood Heat = $0.03/BF Propane Heat = $0.08/BF EFFICIENCY � QUALITY � SPEED

  40. Integrated Moisture Meter :: Remote Control :: Automatic or Manual Mode :: EMS EFFICIENCY � QUALITY � SPEED

  41. QUESTIONS?? www.vacutherm.com PHONE: 1-802-496-4241 EMAIL: sales@vacutherm.com EFFICIENCY � QUALITY � SPEED
