AEROGEL BASED PRODUCTS FOR THERMAL INSULATION OF BUILDINGS Prof. Dr. Can Erkey Department of Chemical and Biological Engineering Ko University Ko University- TPRA Energy Center (KUTEM) Istanbul, Turkey Projections of Residential Energy


slide-1
SLIDE 1
  • Prof. Dr. Can Erkey

Department of Chemical and Biological Engineering Koç University Koç University-TÜPRAŞ Energy Center (KUTEM) Istanbul, Turkey

AEROGEL BASED PRODUCTS FOR THERMAL INSULATION OF BUILDINGS

slide-2
SLIDE 2

Projections of Residential Energy Consumption in Turkey

Forecasting of Turkey's net electricity energy consumption on sectoral bases Coşkun Hamzaçebi, Energy Policy, 35, 2009 (2007)

slide-3
SLIDE 3

Savings of Turkey by Reducing Residential Energy Consumption by 20% by Insulation

1 Barrel of Oil  ~$50

slide-4
SLIDE 4

Heat Losses from Windows of Buildings

Ref: Retrieved from http://www.imagingnotes.com (image courtesy of FLIR Systems, Inc.)

slide-5
SLIDE 5

Transparent Thermal Insulation Systems

Possible Solutions:

  • Instead of argon or air,

use a transparent insulator

  • Replace glass with a

transparent insulator

slide-6
SLIDE 6

November 1, 2016 6

Vacuum Insulation Panels

Fumed silica, glass fiber

NOT TRANSPARENT

slide-7
SLIDE 7

Electronic and Phonon Conduction Knudsen Conduction Gas Phase Conduction Radiation Scattering at Interfaces and Grain Boundaries Recirculatory and Gas Flow Convection Porous Aerogel Structure Heat Flow

Porous Media

Heat Transfer in Porous Materials

slide-8
SLIDE 8

Fundamental Mechanisms of Heat Transfer

  • Conduction
  • Convection
  • Radiation
  • Coupling Terms

Circuit in Series

total conduction convection radiation coupling terms

        

slide-9
SLIDE 9

Fundamental Mechanisms of Heat Transfer

total conduction convection radiation coupling terms

        

NEGLIGIBLE FLOW OF THE GAS MOLECULES WITHIN THE PORES ARE SUPPRESSED OWING TO THE FINE PORE SIZES OF THE AEROGEL STRUCTURE

slide-10
SLIDE 10

Fundamental Mechanisms of Heat Transfer

total conduction radiation

    

Scattering at Interfaces & Grain Boundaries Solid Conduction Gaseous (Knudsen) Conduction

slide-11
SLIDE 11

Solid Conduction

Depends on the structural parameters of the porous material:

  • Density
  • Porosity
  • Interconnectivity of the pores

Hrubesh et.al. & Fricke et.al.;

p

  • s

s s d

V           

: Solid network conductivity : Intrinsic conductivity of network material : Volume fraction of the solid : Sound velocities in porous and dense bodies

s

  • s

s

V

,

p d

 

slide-12
SLIDE 12

Solid conduction can be reduced by:

  • reducing the intrinsic conductivity of network material
  • and reducing the volume fraction of the solid (increasing the porosity)

Solid Conduction

p

  • s

s s d

V           

  • s

s

V

slide-13
SLIDE 13

Gaseous Conduction: Knudsen Conduction

Knudsen equation:

 

1

  • g

g g n

V K     

: Thermal conductivity of free air : Parameter considering energy transfer between gas molecules & solid matrix (~2) : Volume fraction of the voids (porosity) : Knudsen number

  • g

g

V

n

K 

slide-14
SLIDE 14

Gaseous Conduction: Knudsen Conduction

Knudsen number:

g n

l K  

: Mean free path of gas molecules : Pore diameter

g

l 

From Kinetic Theory of Gases:

2

2

B g g

k T l d P  

: Boltzmann constant : Average size of gas molecules : Temperature & Pressure

B

k , T P

g

d

slide-15
SLIDE 15

Gaseous Conduction: Knudsen Conduction

For air at ambient conditions:

2

2.534 10 /

  • g

W mK 

  2   70

n

K  

2

2.534 10 140 1

g g

V  

        

slide-16
SLIDE 16

Gaseous Conduction: Knudsen Conduction

For air at ambient conditions:

2

2.534 10 140 1

g g

V  

        

5

1.7 10 for 140

g g

V nm   

  

Knudsen conduction can be reduced by:

  • reducing the average pore size
  • reducing the porosity
slide-17
SLIDE 17

Radiation: Scattering at Interfaces & Grain Boundaries

Becomes significant for transparent porous materials: affected by the scale of the pore structure Rosseland approximation:

2 3

16 3 ( )

r

n T e T    

: Stephen-Boltzmann constant : Density of the material : Mass-specific extinction coefficient : Absolute temperature

 ( ) e T T 

slide-18
SLIDE 18

Effect of Porosity and Pore Size on Total Thermal Conductivity

0.80 0.85 0.90 0.95 1.00 0.01 0.02 0.03 0.04

D=1nm D=10nm D=20nm D=50nm D=100nm Total Thermal Conductivity (W/mK) Porosity

Preferred region for achieving low conductivity

slide-19
SLIDE 19

Total Thermal Conductivity

Desired material properties for low thermal conductivity:

  • Low density
  • High porosity
  • Small pore sizes

AEROGELS

slide-20
SLIDE 20

Silica Aerogels & Insulation

Why Silica Aerogels?  monolithic  high porosity (80-99%)  transparent  low density (as low as 3 kg/m3)  pore sizes smaller than 50 nm

AEROGELS ARE PERFECT CANDIDATES FOR TRANSPARENT INSULATION SYSTEMS

slide-21
SLIDE 21

OBJECTIVE: DEVELOP AEROGEL BASED TRANSPARENT VACUUM INSULATION PANELS

slide-22
SLIDE 22

(OR)3Si-OH + HO-Si(OR)3 ↔ (OR)3Si-O-Si(OR)3 + H2O (OR)3Si-OH + RO-Si(OR)3 ↔ (OR)3Si-O-Si(OR)3 + ROH

Si(OR)4 + 4H2O ↔ Si(OH)4 + 4ROH

Synthesis of Aerogels

slide-23
SLIDE 23

Effect of Reactant Concentration on Transparency

H2O/TEOS molar ratios: 2, 4, 8, 10 (constant EtOH/TEOS: 4) EtOH/TEOS molar ratios: 6, 5, 3 (constant H2O/TEOS: 3)

EtOH/ TEOS 6 5 3

slide-24
SLIDE 24

EtOH/TEOS molar ratios Water/TEOS molar ratios Diffuse/Total=Haze; 1-Haze=TR%

E/T Ratio Haze (@ 600 nm) TR% (@ 600 nm) 3 12.3 87.7 5 18.2 81.8 6 22.2 77.8

Effect of Reactant Concentration on Transparency

slide-25
SLIDE 25

Effect of Mold Materials on Surface Scattering

  • Types of molds
  • Glass
  • Teflon
  • Polypropylene (PP)
  • Plexiglass (polymethylmethacrylate)
slide-26
SLIDE 26

Teflon and PP Molds

Drawbacks:

  • High surface roughness due to manufacturing
  • Manufacturing of large scale Teflon and PP molds is not easy.

Aerogel synthesized in PP mold (1) and in Teflon mold (2)

slide-27
SLIDE 27

One Drawback of Silica Aerogels

 Fragile & brittle  Poor mechanical properties

WAYS TO IMPROVE MECHANICAL PROPERTIES

AEROGEL COMPOSITES

slide-28
SLIDE 28
  • 1. Blend with the silica network
  • 2. Chemically linked to the silica network
  • 3. H-bonding with the surface groups
  • 4. Entagled within the pore
  • 5. Reactive supercritical deposition of polymer

Typical Approaches to Produce Aerogel Composites with Polymers

slide-29
SLIDE 29

Reactive Supercritical Deposition of PDMS(OH)

Conformal coating of the silica aerogel surface with a thin layer of polymer

slide-30
SLIDE 30

Large Scale Production

35 L autoclave vessel 50x35x2.2 cc plexiglas mold

slide-31
SLIDE 31

A Large Scale Transparent Silica Aerogel

(d: 0.180 g/mL and λT: 16 mW/m.K)

slide-32
SLIDE 32
slide-33
SLIDE 33
slide-34
SLIDE 34

Conclusion

  • Aerogels are perfect candidates for transparent insulation

systems because of their transparency and low thermal conductivity

  • Density, porosity and average pore size of the aerogels are the

major parameters affecting their thermal conductivity

  • EtOH/TEOS and H2O/TEOS molar ratios and type of the mold used

during gelation affect the transparency.

  • One drawback of aerogels are their poor mechanical properties

which can be improved by incorporation of polymers

  • Among various routes, supercritical deposition seems to be

promising to to obtain polymer-aerogel composites without losing the transparency

slide-35
SLIDE 35

We acknowledge the Financial Support of the NANOINSULATE “Development of Nanotechnology-based High-performance Opaque & Transparent Insulation Systems for Energy-efficient Buildings Project “being funded by the EU Program EeB.NMP.2010-1
