BBUGS & BOHOGS 2015 Supplier and Consultant Day The Use of Multiple Geophysical Techniques to Detect Structural Features Author: Wes Nichols Co-Author: Warwick Smyth
Mine-Scale Case Study – Fault • TSIM – Shallow layer VLF-EM technique (down to 50m) – Uses VLF transmissions (e.g. 19.8kHz @ NW Cape) – Resistivity contrast • Borehole Acoustic Scanner – Measures acoustic impedance of borehole wall – Defect/bedding/structure identification • RIM – In-seam borehole-borehole radio imaging – Used for confirmation only
Fault Detection • Near-surface expression
TSIM Grid (100m x 150m – 10m)
Holes targeted to TSIM Results
Downhole Acoustic Scanner Example: Chip hole R1833
Level of fault
RIM: In-seam EM (Borehole-Borehole) Direction of highwall advance
Geotechnical Implication Wedge failure risk
Interpretation of Structural Regime
3D Schematic Interpration
Top of Coal Surface Showing Interpreted Faults
Mine-Scale Case Study - LOX • TSIM – Shallow layer VLF-EM technique (down to 50m) – Uses VLF transmissions (e.g. 19.8kHz @ NW Cape) – Resistivity contrast • Confirmed by drilling
LOX Definition
Mine-Scale Case Study – Alluvium/Surface Channel Deposits • TSIM – Shallow layer VLF-EM technique (down to 50m) – Uses VLF transmissions (e.g. 19.8kHz @ NW Cape) – Resistivity contrast • Confirmed by drilling
Alluvial Thickness Mapping
TSIM – Structural Targets • Near surface expression of geological structures of Geotechnical Importance • Target types outlined in this presentation – Faults (TSIM + Scanner + RIM) – LOX/subcrop (TSIM) – Alluvium (TSIM)
TSIM VLF-EM • Provider to industry • $100,000+ in R&D expenditure • Development of new TranSIM instrument in progress • Handleability and ease of operation • Cost advantage • Saving in Drilling Costs
Scanner Interpretation Services • Defect mapping • Stress regimes • Full interpretive report
Questions?
