The Norwegian-German subsea cable project Schleswig-Holstein / - PowerPoint PPT Presentation

The Norwegian-German subsea cable project Schleswig-Holstein / Eastern Norway County Network 07.11.12 The Norwegian 930 employees Transmission System Operator Nine overhead Four subsea interconnectors interconnectors 10 000 km lines


  1. The Norwegian-German subsea cable project Schleswig-Holstein / Eastern Norway County Network 07.11.12

  2. The Norwegian 930 employees Transmission System Operator Nine overhead Four subsea interconnectors interconnectors

  3.  10 000 km lines  Population: 5 million  15 inhabitants pr km 2  11 000 km lines  Population: 27 million  370 inhabitants pr km 2

  4. 3700 MW Hallsberg Tveiten Kvilldal Tonstad Kristiansand Feda Barkefryd From 5400 MW to 10300 MW in 10 years Hurva The German Cable Project 1400 MW 700 MW Tjele Blyth 2018/2021 NorNed Existing interconnector Future interconnector Wilster Existing interconnector Moorriem Future interconnector Eemshaven

  5. Effect on grid in Norway - export mode 2011 2022

  6. German Grid development plan (a scenario) 7

  7. Tonstad Feda The Norwegian- German project Wilster Moorriem

  8.  Animation

  9. Projectpartners: Norwegian TSO, owner and operator of Norwegian grid, including interconnectors German TSO, owns and operates grids at connection points Government owned investment bank active in financing Energiewende projects

  10. Status  Parties: Statnett – KfW/TenneT 50-50  Cooperation agreement in place  Full political support  Ongoing licensing processes in  Germany  Schleswig-Holstein (NORD.LINK)  Niedersachsen (NorGer)  Denmark  Norway  Decision NORD.LINK vs NorGer Q1/2013.

  11. Required licenses/permits for NORD.LINK/NorGer Technical License Power license according exchange to the license Offshore Energy Act Offshore license Norwegian Water Ministry of Ministry of Resources and Petroleum and Petroleum and Energy Directorate Energy Energy Danish Energy Agency Exclusive Economic Zone (EEZ) State Mining Federal Maritime Authority (LBEG) and Hydrographic of Clausthal- Agency (BSH) Zellerfeld Regional Planning Regional Planning Planning Approval Planning Approval Procedure Procedure Procedure Procedure State Company for State Company for State Company for State Company for Road Construction Road Construction Road Construction Road Construction and Transport and Transport and Transport and Transport (NLStBV) (NLStBV) (LBV) (LBV)

  12. Offshore planning Planned/approved/in use offshore windpark Wattenmeer National NorGer Park Restricted Area -Military Practice Area -Submarine Diving Area -Fly zone Sylt Outer Reef Nature Reserve SPA Östliche Deutsche Bucht (Protected Area) Seevogelschutzgebiet Helgoland (Protected Area) Shipping Separation Area (Shipping lanes) Protection Corridor – No Anchoring Zone Bird Protection Area Former Munitions Dumping Grounds NorGer Proposed Route Nord.Link Proposed Route Map: Common Wadden Sea Secretariat

  13. Onshore - overall feasibility  Grid connection point – feasible plot  Feasible onshore route  Agreements with 250 landowners  Property- and environmental compensations  Crossing of infrastructure  Crossing of dikes  Crossing of Nord-Ost See Kanal  Crossing of roads and bridges  Crossing agreements offshore infrastructure
