The changing role of electrical networks and why it matters to you. • Stewart Reid - Head of Future Networks

Networks … 2

Real progress on decarbonisation since 2008 Climate Change Act • GB Power sector emissions intensity down 50% since 2008. • 33% of power from Renewables vs 5% in 2008. • Energy networks are a high performing success story, playing a key role in decarbonisation: • Since 1990 the networks have invested £100billion and costs have fallen by 17% • Power cuts are at their lowest level ever with a 59% reduction since 1990. • We’ve accommodated the rapid rise in renewables with 28GW of local generation connected • SSEN alone has connected enough renewables electricity to power 4million homes. • Customer satisfaction in networks, recorded by Ofgem, is over 80% 3

INCREASING THE PACE OF CHANGE? 2030 Generation +7.5GW 16.0 Capacity Connected Generation Capacity (GW) 14.0 +3.9GW 8.2 GW 12.0 (+3.9 GW) 10.0 +0.4GW 8.0 4.3 GW 60% low 6.0 4.0 2.0 13/14 14/15 15/16 16/17 17/18 18/19 19/20 20/21 21/22 22/23 23/24 24/25 25/26 4 For methodology see: ssen-transmission.co.uk/information-centre/industry-and-regulation/future-energy-scenarios/

Key Changes New Data Complexity opportunities Distributed New trading Generation relationships Local Energy Less Uncertainty predictable energy flows Conflicts and Facilitating Congestion Markets Electrification of heat and Transport 5

New ways of managing network growth Optionality 7

New Methods Managing Congestion. Smart Solutions Network Investment Active Management Price Signals and flexibility 8

Networks buying flexibility services Constraint Managed Zone (CMZ) 9

The Social CMZ Adds local market S timulation and S ocial bid selection criteria 10

New types of Connection. Flexible connections: The opportunities are on your side of the meter! 11

Active Network Management Measurement Point threshold graph 9 Zone Export (A or MW’s or MVA) Thermal Rating 8 7 Trip 6 5 4 Trim 3 2 Reset 1 0 Time 12

Active Network Management Rolling Out Flexible Connections We’ve already rolled out 150 MW of flexible connections: No. of Location MW's Generators Orkney 24.8 24 Stornoway 9 1 Shetland 12.5 5 Isle of Wight 0.5 1 Taynuilt 0.35 1 Thurso 31.2 2 Keith 15 1 ELS North 15.2 18 ELS South 45.4 25 SHEPD 108.05 SEPD 45.9 13

Timed Export Limitation 12 1 MW Wind Generator 9 3 6 SSEN install intertrip to protect network 5MW PV Generator Substation 14

G100 - Customer Export Limiting Schemes (ELS) 200kW Wind Generator Wind Turbine Installation at a Farm Farm Import Capacity – 200kW Substation Export Capacity - 150kW 15

Flexible Demand Connections 16

Cross country Flexible Connections £ Active Network Management (ANM) 17

New Markets Peer to Peer trading across the network 18

New ways to buy and trade energy Local Generation New Value streams 19

“Must work for all customers” • Penalise those that cannot use demand flexibly • Reward those that have flexible demand • Create opportunities for gaming • Stimulate markets • Minimise the resilience of the network • Maximise the utilisation of the network • Digitise the Energy System • Increase system interdependencies • Enable Community energy trading • Penalise those that don’t belong to communities • Remove the energy universal service obligation • User pays • Generate duplication • Promote competition between DNOs 20

& Project LEO Local Energy Oxfordshire

TRANSITION in Oxfordshire TRANSITION proposes to deliver a trial in Oxfordshire, coordinating with Project LEO (Local Energy Oxfordshire) to enhance overall learning value. Project LEO provides a £40m programme. The requested £13m Innovate UK grant funding is matched by £27m private sector funding, and further leveraged by £46m public sector investment. Project LEO will be led by SSEN and delivered with the following varied and active partners: • University of Oxford • • Oxford Brookes University Open Utility • The Low Carbon Hub • Origami Energy • Oxfordshire County Council • EDF Energy • Oxford City Council • Nuvve 22

Why it matters to you? New Opportunities opportunities to to connect for sell flexibility less and quicker. Opportunities Opportunities to trade energy to buy energy in locally. new ways. 23

SSEN Innovation ENA Innovation Portal https://www.ssepd.co.uk/ http://www.smarternetworks.org/ Innovation/ Constraint Managed Zones https://picloflex.com/ 24
