Systems Infrastructure for Data Science Web Science Group Uni Freiburg WS 2014/15 Lecture II: Indexing Indexing Part I of this course 3 Database File Organization and Indexing Remember: Database tables are implemented as files of


  1. Systems Infrastructure for Data Science Web Science Group Uni Freiburg WS 2014/15

  2. Lecture II: Indexing

  3. Indexing Part I of this course 3

  4. Database File Organization and Indexing • Remember: Database tables are implemented as files of records: – A file consists of one or more pages . – Each page contains one or more records . – Each record corresponds to one tuple in a table. • File organization: Method of arranging the records in a file when the file is stored on disk. • Indexing: Building data structures that organize data records on disk in (multiple) ways to optimize search and retrieval operations on them. 4

  5. File Organization • Given a query such as the following: • How should we organize the storage of our data files on disk such that we can evaluate this query efficiently? 5

  6. Heap Files? • A heap file stores records in no particular order . • Therefore, CUSTOMER table consists of records that are randomly ordered in terms of their ZIPCODE. • The entire file must be scanned , because the qualifying records could appear anywhere in the file and we don’t know in advance how many such records exist. 6

  7. Sorted Files? • Sort the CUSTOMERS table in ZIPCODE order. • Then use binary search to find the first qualifying record, and scan further as long as ZIPCODE < 8999. 7

  8. Are Sorted Files good enough?  Scan phase: We get sequential access during this phase. Search phase: We need to read log 2 N records during this phase (N: total number of records in the CUSTOMER table). – We need to fetch as many pages as are required to access these records. – Binary search involves unpredictable jumps that makes prefetching difficult. What about insertions and deletions? 8

  9. Tree-based Indexing • Can we reduce the number of pages fetched during the search phase ? • Tree-based indexing: – Arrange the data entries in sorted order by search key value (e.g., ZIPCODE). – Add a hierarchical search data structure on top that directs searches for given key values to the correct page of data entries. – Since the index data structure is much smaller than the data file itself, the binary search is expected to fetch a smaller number of pages. – Two alternative approaches: ISAM and B + -tree . 9

  10. ISAM: I ndexed S equential A ccess M ethod • All nodes are of the size of a page. pointer – hundreds of entries per page – large fan-out, low depth • Search cost ~ log fan-out N • Key k i serves as a “separator” for the pages pointed to by p i-1 and p i . 10

  11. ISAM Index Structure • Index pages stored at non-leaf nodes • Data pages stored at leaf nodes – Primary data pages & Overflow data pages index pages data pages 11

  12. Updates on ISAM Index Structure • ISAM index structure is inherently static . – Deletion is not a big problem: • Simply remove the record from the corresponding data page. • If the removal makes an overflow data page empty, remove that overflow data page. • If the removal makes a primary data page empty, keep it as a placeholder for future insertions. • Don’t move records from overflow data pages to primary data pages even if the removal creates space for doing so. – Insertion requires more effort: • If there is space in the corresponding primary data page, insert the record there. • Otherwise, an overflow data page needs to be added. • Note that the overflow pages will violate the sequential order .  ISAM indexes degrade after some time. 12

  13. ISAM Example • Assume: Each node can hold two entries. 13

  14. After Inserting 23*, 48*, 41*, 42* Overflow data pages had to be added. 14

  15. … Then Deleting 42*, 51*, 97* 51 appears in index page, but not in the data page. The empty overflow data page is removed. 15

  16. ISAM: Overflow Pages & Locking • The non-leaf pages that hold the index data are static; updates affect only the leaf pages.  May lead to long overflow chains . • Leave some free space during index creation.  Typically ~ 20% of each page is left free. • Since ISAM indexes are static, pages need not be locked during index access. – Locking can be a serious bottleneck in dynamic tree indexes (particularly near the root node). • ISAM may be the index of choice for relatively static data. 16

  17. B + -trees: A Dynamic Index Structure • The B + -tree is derived from the ISAM index, but is fully dynamic with respect to updates. – No overflow chains ; B + -trees remain balanced at all times. – Gracefully adjusts to insertions and deletions. – Minimum occupancy for all B + -tree nodes (except the root): 50% (typically: 67 %). – Original version: • B-tree : R. Bayer and E. M. McCreight , “Organization and Maintenance of Large Ordered Indexes”, Acta Informatica, vol. 1, no. 3, September 1972. 17

  18. B + -trees: Basics • B + -trees look like ISAM indexes, where – leaf nodes are, generally, not in sequential order on disk – leaves are typically connected to form a doubly-linked list – leaves may contain actual data (like the ISAM index) or just references to data pages (e.g., record ids (rids)) • We will assume the latter case, since it is the more common one. – each B + -tree node contains between d and 2d entries ( d is the order of the B + -tree; the root is the only exception). 18

  19. Searching a B + -tree • Function search (k) returns a pointer to the leaf node that contains potential hits for search key k . • Node page layout: pointer 19

  20. Insertion to a B + -tree: Overview • The B + -tree needs to remain balanced after every update (i.e., every root-to-leaf path must be of the same length).  We cannot create overflow pages. • Sketch of the insertion procedure for entry <k, p> (key value k pointing to data page p ): 1. Find leaf page n where we would expect the entry for k . 2. If n has enough space to hold the new entry (i.e., at most 2d-1 entries in n ), simply insert <k, p> into n . 3. Otherwise, node n must be split into n and n’ , and a new separator has to be inserted into the parent of n . Splitting happens recursively and may eventually lead to a split of the root node (increasing the height of the tree). 20

  21. Insertion to a B + -tree: Example • Insert new entry with key 4222 . – Enough space in node 3, simply insert without split. – Keep entries sorted within nodes . 21

  22. Insertion to a B + -tree: Example • Insert key 6330 . – Must split node 4. – New separator goes into node 1 (including pointer to new page). 22

  23. Insertion to a B + -tree: Example • After 8180 , 8245 , insert key 4104 . – Must split node 3. – Node 1 overflows => split it! – New separator goes into root. • Note: Unlike during leaf split, separator key does not remain in inner node. 23

  24. Insertion to a B + -tree: Root Node Split • Splitting starts at the leaf level and continues upward as long as index nodes are fully occupied. • Eventually, this can lead to a split of the root node: – Split like any other inner node. – Use the separator to create a new root. • The root node is the only node that may have an occupancy of less than 50 %. • This is the only situation where the tree height increases. 24

  25. Insertion Algorithm 25

  26. 2d+1 2d+1 d+1 2d+1 2d+1 26

  27. • insert (k, rid) is called from outside. • Note how leaf node entries point to rids, while inner nodes contain pointers to other B + -tree nodes. 27

  28. Deletion from a B + -tree • If a node is sufficiently full (i.e., contains at least d+1 entries), we may simply remove the entry from the node. – Note: Afterwards, inner nodes may contain keys that no longer exist in the database. This is perfectly legal. • Merge nodes in case of an underflow (i.e., “undo” a split): • “Pull” separator (i.e., key 6423 ) into merged node. 28

  29. Deletion from a B + -tree • It is not that easy: • Merging only works if two neighboring nodes were 50% full. • Otherwise, we have to re-distribute : – “rotate” entry through parent 29

  30. B + -trees in Real Systems • Actual systems often avoid the cost of merging and/or redistribution, but relax the minimum occupancy rule. • Example: IBM DB2 UDB – The “ MINPCTUSED ” parameter controls when the system should try a leaf node merge (“on - line index reorganization”). – This is particularly easy because of the pointers between adjacent leaf nodes. – Inner nodes are never merged (need to do a full table reorganization for that). • To improve concurrency, systems sometimes only mark index entries as deleted and physically remove them later (e.g., IBM DB2 UDB “type - 2 indexes”). 30

  31. What is stored inside the leaves? • Basically there are three alternatives: 1. The full data entry k* . Such an index is inherently clustered (e.g., ISAM). 2. A <k, rid> pair, where rid is the record id of the data entry. 3. A <k, {rid 1 , rid 2 , …}> pair, where the items in the rid list rid i are record ids of data entries with search key value k . • 2 and 3 are reasons why we want record ids to be stable. • 2 seems to be the most common one. 31

  32. B + -trees and Sorting • A typical situation according to alternative 2 looks as follows: 32

  33. Clustered B + -trees • If the data file was sorted, the scenario would look different: • We call such an index a clustered index . – Scanning the index now leads to sequential access . – This is particularly good for range queries . 33
