Course Outline About DITEK Corporation What are Surges and Spikes? Causes Effects How Surge Protection Works Surge Protection Solutions for Fire Alarm Systems Case Study Code References / UL Scopes Selecting the Correct Surge Protection Devices Installation Photos 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
This is not the International Symbol for Surge Protection... Perhap rhaps it it should be be! DITEK COR DIT CORPO PORA RATION TION continues to lead the industry in the design and manufacturing of electrical and low-voltage su surge rge pr protecti ection on devices vices. Founded in 1988 and located in Largo, Florida, DITEK manufactures more than 300 different product solutions offering unparalleled protection options for the commercial, industrial and residential markets. 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
About DITEK 60,000 Sq Ft Manufacturing Facility ISO 9001:2008 Quality Certified Active Participants in Shaping of UL, IEEE, IEC, ANSI, BICSI and SIA Standards Tampa Bay Times Top Workplace 2014 Dedicated Regional Account Managers Supporting the US, Canada, Europe and Latin American Markets Technical Support Available 24/7 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Proudly Made in the USA 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
What are Surges and Spikes? Surges s and Spik ikes are unexpe pect cted, d, temporar rary y and uncont ntrolle led d increas reases es in current nt or voltage in an electric ical al circuit. uit. They can be present on any metallic conductor. They can damage, degrade and even destroy electrical and electronic equipment. Surges are the most common cause of equipment damage and destruction. 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
What Causes Surges and Spikes? EXTERNAL CAUSE INTERNAL CAUSE Lightn tnin ing g – a direct hit, usually Inducti uctive e Loads – the switching catastrophic on and off of electric motors inside or outside a facility, such as Proxim imity ty Strikes es – lightning HVAC systems, refrigeration strikes several miles away equipment, pumps and CNC causing large voltage surges machines along transmission lines Mechan hanical cal Failures ures – Utilit ity Grid Switchin ching – utility components of the electrical companies switching distribution system failing transmission lines from one supply system to another Human n Error – accidental Brownouts nouts / Black ckout outs s – under induction of AC power on low voltage or voltage sag followed by voltage system circuits a surge or spike 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
What Causes Surges and Spikes? 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
What Causes Surges and Spikes? 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Effects of Surges and Spikes Gradual deterioration of internal circuitry DEGRAD RADATION TION • Premature equipment failure Instantaneous loss of expensive equipment DESTR TRUCTION CTION • Electronics, motors, controllers, etc. Loss of productivity and revenue DOWNTI TIME • Loss of critical data and information 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
How Surge Protection Works Surge Prot otecti ction on works s by simpl mply diver erting ting excess ess volta tage ge and curr rrent nt safel ely to earth ground d before ore it re reaches hes cri ritica ical equipm pmen ent! t! Initial Surge Surge Protector Response 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
How Surge Protection Works Initial ial Surge Normal Service Voltage DC/AC Surge Clam amped ed Surge Protective Device 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Surge Protection Applications DITEK manufactures a complete line of surge protection products to meet the needs of our target markets: IP Video / CCTV Systems Fire Alarm Systems Networking & Voice Communications Access Control & Intrusion Systems Commercial, Industrial & Residential AC Power 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Fire Alarm Surge Protection Is downtime an option in your life safety installations? 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Code References NFPA A 72 - 2013 , Chapt pter 12 – Circuits uits and Pa Pathw hways ys 12.2. .2.4.2 4.2 All non-power-limited and power-limited signaling system circuits entering a building shall be provided with transient protection. NFPA A 70 Na Natio ional al Electr trical ical Code de – 2014 Article Ar cle 760.3 0.32 Non-power-limited fire alarm circuits and power-limited fire alarm circuits that extend beyond one building and run outdoors shall meet the installation requirements of Parts II, III and IV of Article 800 and shall meet the installation requirements of Part I of Article 300. Informat ormational ional Not ote: e: An example of a protective device suitable to provide protection is a device tested to the requirements of ANSI/UL 497B, Protectors for Data Communications. 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Surge Protection UL Scopes th Editio UL 1449 4 th ion – Surge Prot otectiv ective Devices es These requirements cover Surge Protective Devices (SPDs) designed for repeated limiting of transient voltage surges as specified in the standard on 50 or 60 Hz power circuits not exceeding 1000 V. UL 497A – Seconda dary y Prot otect ectors s for Communi unication ation Circuits uits These requirements cover secondary protectors for use in single- or multiple-pair type communications circuits that are intended to be installed in accordance with Article 800 of the National Electrical Code ANSI/NFPA 70. UL 497B – Isolated d Loop Circui uit Prot otectors These requirements cover protectors for data communications and fire alarm circuits. 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Fire Alarm Surge Protection 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Parallel vs. Series 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
DTK-120HW 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
DTK-120HW 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
DTK-120HW 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
DTK-120SRD 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Remote Monitoring SPDT Form 1C contact circuit rated 120V/0.5A 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Multi-Stage vs. Single Stage 20,00 ,000 0 Am Amp Sur urge ge Cur urrent rent Rating ng 2,000 000 Am Amp Sur urge ge Cur urrent rent Rating ing Gas Discharge Tube (GDT) Metal Oxide Varistor (MOV) Silicon Avalanche Diode (SAD) 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
2MHLP-F vs. 2MHLP-B Opens Circuit when compromised Shorts to Ground when compromised 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Field Replaceable Design 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
DTK-TSS Series 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Installation Photos 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Installation Photos 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Installation Photos 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Installation Photos 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Best Practices It is imper erati ative e that at surge ge protecti tection on is inst stalled alled per the guideli delines es set forth rth by the manufac facturer turer. . Improp roperly erly insta talled lled devices es will ll no not perform orm as int nten ended ed and nd cons nseq equently, uently, will l not prote otect ct the equipm ipmen ent. t. 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Installation Rule #1 The conductor tor length gth between een the surge ge protecti tective ve devic ice e (SPD) SPD) and nd the equi uipmen pment t be being ng protec otected ted should uld be be a minimum nimum of 3 f feet t in lengt gth to allow ow enough gh time me for the SPD D to react. ct. The conductors ctors can be greater eater than n 3 f feet t as long g as they y are isolated lated and are not subjec jected ted or directly ectly exposed osed to inter ernally ally- or externally ternally-gener generated ated transient ansient voltage tage spikes kes and/or or surges. ges. 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Example - Incorrect 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
Example - Correct 1-800-753-2345 Technical Support: 1-888-472-6100 DITEKCORP.com
