Summary Brief Information on Nanofibers Electro Hydrodynamic - PowerPoint PPT Presentation

Summary Brief Information on Nanofibers Electro Hydrodynamic Atomization (EHDA) Processes: Electrospinning and Electrospraying Research Statistics Nanofibers in Biomedical Field Market Analysis For Nanofibers In Biomedical Field


  1. Summary  Brief Information on Nanofibers  Electro Hydrodynamic Atomization (EHDA) Processes: Electrospinning and Electrospraying  Research Statistics  Nanofibers in Biomedical Field  Market Analysis For Nanofibers In Biomedical Field  A new Approach: Hybrid Electrospinning Technology

  2. Electrospun Nanofibers Fiber diameter less than 1 µm is mostly defined as nanofiber. Human Hair Nanofibers

  3. Advantages Of Nanofibers Small diameters (10 nm-200 nm) High Surface Area (1-1000 m²/g) High Porosity (ca. 80%) Flexibility

  4. Applications Of Nanofibers

  5. Electro Hydrodynamic Atomization (EHDA) Electrohydrodynamic atomization phenomena is used for building micro- or nanometer architectures, such as fibers and encapsulated particles with a controllable microstructure. Electrohydrodynamic atomization techniques: 1. Electrospraying 2. Electrospinning . Wu, Y., & Clark, R. L. (2008).

  6. Electrospray/Electrospraying The liquid flowing out of a capillary nozzle, which is maintained at high electric potential, is forced by the electric field to be dispersed into fine droplets. Steps of micro- and nanoparticle production via Schematics of setup for electrospraying electrospraying . (Wu Y (2014)) (Jaworek, A., & Sobczyk, A. T. (2008))

  7. Electrospinning Electrospinning is a fiber production method which uses electric force to draw charged threads of polymer solutions or polymer melts up to fiber diameters in the order of some hundred nanometers. Morota, K and others (2004) A basic electrospinning system mainly consists of three parts;  polymer feeding unit,  high voltage power supply  collector

  8. Electrospinning vs Electrospraying The difference between the electrospinning and electrospraying techniques lies in the chain entanglement density of the polymer solution. Surface SEM images of electrospun thin films from polymer solution (URL-1 Electrospinning Cost Action MP1206) with various concentrations at 4.5 kV: (a) 5, (b) 10, (c) 20, (d) 30, (e) 40, (f) 50, (g) 60, and (h) 70 g / L. Morota, K and others (2004)

  9. Research Interest in Nanofibers 7573 8000 7002 6325 7000 6019 5733 6000 PAPERS PUBLISHED 4913 4300 5000 3975 4000 3181 2820 2400 3000 1835 1493 2000 1067 709 1000 388 266 153 71 33 50 0 1998 1999 2000 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 YEARS Data Generation Date: 07 October 2019 Data is generated on SCOPUS database Keywords: electrospinning OR nanofibers OR electrospun OR nanofiber Searched In: TITLE-ABSTRACT-KEYWORDS

  10. Number Of Patents By Year 2500 2074 1749 2000 1472 1323 PATENTS 1500 1079 1010 821 1000 644 617 476 419 324 500 258 160 121 71 57 17 0 2001 2002 2003 2004 2005 2006 2007 2008 2009 2010 2011 2012 2013 2014 2015 2016 2017 2018 YEARS Data was taken from ESPACENET Worldwide by Searching «nanofiber or electrospinning» in «Title or Abstract» for 2001 to now. Data Generation Date: 07 October 2019

  11. Nanofibers in Filtration

  12. Nanofibers applications in tissue engineering • Bone tissue regeneration • Cartilage tissue regeneration • Muscle tissue regeneration • Tendon/ligament tissue regeneration • Nerve tissue regeneration • Heart valve tissue regeneration • Dental regeneration • Skin tissue regeneration

  13. Drug Delivery Applications • Controlled release, • Slow delivery, • Targeted delivery are the benchmarks for designing efficient drug delivery carriers Factors to be considered for designing efficient drug delivery systems. Ramakrishna, S. (2017).

  14. Advantages of nanofibers as drug delivery systems For drug delivery applications, The main mechanism of the drug release from electrospinning is the most actively nanofibre matrices is; • desorption from the nanofibre surface, employed method for fabricating • diffusion through the channels and pores of drug-loaded nanofibers, due to; • its high loading capacity, nanofibres or matrix degradation • high encapsulation efficiency, • a combination of them. • simultaneous delivery of diverse therapies, • ease of operation, • cost effectiveness (Zamani et. al., 2013)

  15. Nanofibers for Wound Healing Applications Representation of the properties that electrospun membranes must display to be used as wound dressings. Correia, I. J. (2018).

  16. Vascular Tissue Engineering The use of electrospun nanofibers for arterial tissue engineered vascular graft fabrication is common and attractive because it provides; • ease of construction, • biocompatibility, • favorable cellular interactions, • adequate mechanical properties such as high durability and compliance. Nanofibrous tubular vascular scaffold produced using Inovenso NS24

  17. Market Size of Nanofiber Based Biomedical Materials 250 35 227.45 Market Size (USD millions) 200 182.54 Growth Rate (%) 30 147.62 150 119.71 97.44 100 79.82 25 24.6 50 23.66 23.31 22.86 22.07 0 20 2016 2017 2018 2019 2020 2021 Market Size Growth Rate The global nanofiber materials market for the biomedical industry was valued at $79.82 million in 2016 and is estimated to reach $227.45 million by 2021, growing at a CAGR of 23.3%.

  18. Global Market For Biomedical Industry By Application 2016 and 2021 ($ millions) TYPE 2016 2021 Filters and membranes 35,12 106,26 Medical textiles and wound dressings 20,75 60,66 2016 Tissue engineering 12,77 34,2 2021 Others Drug delivery 6,39 15,57 Others 6% Drug delivery Drug delivery 5% 8% Others 4,79 10,76 7% Filters and Tissue engineering ue engineering membranes 15% Filters and 16% 44% membranes 47% Other applications of nanofibers in the Medical textiles biomedical industry include biosensors, and wound Medical textiles dressing and wound dental fixtures, and stem cell therapy 26% dressing 26%

  19. A New Approach to the Technology: Hybrid Electrospinning

  20. A new Approach : Hybrid Electrospinning Technology Conventional needle-based Systems Inovenso’s Hybrid Electrospinning Needleless Electrospinning systems Systems Easy to set-up Easy to set-up Complex set-up procedure All polymers can be used, but fast Possible to work with all kinds of Not possible to work with fast evaporating solvents can cause polymer solutions. No clogging evaporating solvents. needle clogging. problem. Low electrical power. 10 – 30 KV Relatively higher power Up to 50KV Very high electrical power. 80 – 120 KV Uniform jet distribution Uniform and stable jet distribution Non-controllable jet during the operation Low production rate High production rate High production rate Full control of the process Precise and full control of the Hard to control the process process parameters Defectless Nanofibers Defectless Nanofibers Beaded and defected structures Uniform fiber morphology Uniform morphology Non-uniform morphology

  21. A new Approach : Hybrid Electrospinning Technology Hybrid Electrospinning Head / Standard Syringe Nanofiber comparison Hybrid Nozzle Hybrid Nozzle Hybrid Nozzle 14G 14G 14G

  22. Single Hybrid Nozzle

  23. Multi Hybrid Nozzle

  24. Inovenso researches, develops, designs and produces high quality electrospinning machines and offer services related to Nanofibers- Based products development and contract manufacturing. Inovenso’s Founders started their researches under structure of Nanofiber Membrane Group of Istanbul Technical University (ITU) in 2005 and commercialized their activities under Inovenso in ITU Technology Development Center in Istanbul, Turkey in 2010. Inovenso US Company is established in Boston/Massachusetts in 2017 both for the US based and Canadian Customers, also for the potential collaborations and projects with academia.

  25. Strengths • More than 10 years experience on electrospinning technology. • Worldwide operation from 2 official offices in Istanbul, Boston and 5 distributors. • Patent owning for the most effective method of electrospinning, Hybrid Technology. • Over 10 succesfuly completed national and international projects.

  26. References
