Structured Sets CS1200, CSE IIT Madras Meghana Nasre April 21, - PowerPoint PPT Presentation

Structured Sets CS1200, CSE IIT Madras Meghana Nasre April 21, 2020 CS1200, CSE IIT Madras Meghana Nasre Structured Sets Structured Sets Relational Structures Properties and closures Equivalence Relations Partially


  1. Structured Sets CS1200, CSE IIT Madras Meghana Nasre April 21, 2020 CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  2. Structured Sets • Relational Structures • Properties and closures � • Equivalence Relations � • Partially Ordered Sets (Posets) and Lattices • Algebraic Structures • Groups and Rings CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  3. Partially Ordered Sets • S 2 – all subsets of { a , b , c } . • S 1 – all words in English dictionary. • Relation R 2 on S 2 : • Relation R 1 on S 1 : • ( X , Y ) ∈ R 2 if X ⊆ Y . • ( w 1 , w 2 ) ∈ R 1 if w 1 = w 2 or w 1 appears before w 2 in dictionary. Defn: If R on set S is reflexive, and anti-symmetric, and transitive, then R is a partial ordering on set S . Set S along with R is known as a partially ordered set or poset. a � b is used to denote ( a , b ) ∈ R when R is reflexive, anti-symmetric and transitive. Examples: • “divides” on a set { 1 , 2 , 3 , 6 , 9 , 12 , 15 , 24 } . • x is older than y on a set of people. • ≤ on the set Z + . CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  4. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  5. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } Adv. Algo R.P. Adv. DS Algo PDS Adv. Prob. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  6. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } • Comparable elements. • Minimal elements. Adv. Algo • Least element (if exists). R.P. Adv. DS • Chain and Anti-chain. Algo PDS Adv. Prob. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  7. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } • Comparable elements. • Minimal elements. Adv. Algo • Least element (if exists). R.P. Adv. DS • Chain and Anti-chain. • Length of Longest Chain: Algo Minimum number of semesters needed to complete the course PDS work. Adv. Prob. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  8. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } • Comparable elements. • Minimal elements. Adv. Algo • Least element (if exists). R.P. Adv. DS • Chain and Anti-chain. • Length of Longest Chain: Algo Minimum number of semesters needed to complete the course PDS work. Adv. Prob. • Length of Longest Anti-chain: Maximum number of courses Disc. Maths Prob. Th. that one can take simultaneously (without violating pre-req). CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  9. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } Adv. Algo R.P. Adv. DS Algo PDS Adv. Prob. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  10. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } Adv. Algo R.P. • Qn: Is there a total order on Adv. DS the courses “compatible” with Algo the given partial order? PDS Adv. Prob. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  11. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } Adv. Algo R.P. • Qn: Is there a total order on Adv. DS the courses “compatible” with Algo the given partial order? An ordering: Disc. Maths, Prob. PDS Th., PDS, Adv. Prob., Adv. DS, Algo, RP, Adv. Algo Adv. Prob. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  12. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } Adv. Algo R.P. • Qn: Is there a total order on Adv. DS the courses “compatible” with Algo the given partial order? An ordering: Disc. Maths, Prob. PDS Th., PDS, Adv. Prob., Adv. DS, Algo, RP, Adv. Algo Adv. Prob. • Is this order unique? Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  13. Example: Course pre-requisite structure List of courses to be completed to graduate. S = { c 1 , c 2 , c 3 , . . . , c n } . R = { ( c i , c j ) | ( c i = c j ) or c i is a pre-requisite for c j } Adv. Algo R.P. • Qn: Is there a total order on Adv. DS the courses “compatible” with Algo the given partial order? An ordering: Disc. Maths, Prob. PDS Th., PDS, Adv. Prob., Adv. DS, Algo, RP, Adv. Algo Adv. Prob. • Is this order unique? No. Write down another order. Disc. Maths Prob. Th. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  14. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  15. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  16. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. Adv. Algo R.P. Adv. DS Algo PDS Adv. Prob. Disc. Maths Prob. Th. Prob. Th. � t Disc. Maths � t PDS � t Adv. Prob. � t Adv. DS � t Algo � t Adv. Algo � t RP CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  17. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. Adv. Algo R.P. Adv. DS Algo PDS Adv. Prob. Disc. Maths Prob. Th. Prob. Th. � t Disc. Maths � t PDS � t Adv. Prob. � t Adv. DS � t Algo � t Adv. Algo � t RP � Prob. Th. � t Disc. Maths � t Algo � t Adv. Prob. � t Adv. DS � t PDS � t Adv. Algo � t RP CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  18. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. Adv. Algo R.P. Adv. DS Algo PDS Adv. Prob. Disc. Maths Prob. Th. Prob. Th. � t Disc. Maths � t PDS � t Adv. Prob. � t Adv. DS � t Algo � t Adv. Algo � t RP � Prob. Th. � t Disc. Maths � t Algo � t Adv. Prob. � t Adv. DS � t PDS � t Adv. Algo � t RP × CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  19. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  20. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. Qn: How to construct the total order? CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  21. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. Qn: How to construct the total order? Topological sorting of a partial order. CS1200, CSE IIT Madras Meghana Nasre Structured Sets

  22. Total ordering of a partial order For a poset ( S , � ), the relation � t is said to be a total order on S if a � b implies a � t b . Note: it is not an iff statement. A total order is also called as a linearization of the partial order. Qn: How to construct the total order? Topological sorting of a partial order. Claim: Every finite poset ( S , � ) has at least one minimal element. CS1200, CSE IIT Madras Meghana Nasre Structured Sets
