Presentation to the 5th Meeting of the EMRAS II Working Group Urban Areas Simulation of Kamenna RDD field tests with the RDD_MCC computer code Juraj ran, Department of Accident Management and Risk Assessment VUJE Inc., Trnava,


  1. Presentation to the 5th Meeting of the EMRAS II Working Group “Urban Areas” Simulation of Kamenna RDD field tests with the RDD_MCC computer code Juraj Ď úran, Department of Accident Management and Risk Assessment VUJE Inc., Trnava, Slovak Republic 24-28 January 2011, Vienna, Austria 1/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  2. CONTENTS 1. Introduction 2. Mathematical model 3. Uncertainties 4. Input data 5. Preliminary results of comparison 6. Conclusion 2/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  3. 1. INTRODUCTION • Simulations for Test1 and Test2 • Calculations were carry out with RDD_MMC computer code (Method Monte Carlo) • Main task for present time – to find an appropriate model for volume source term and distribution of particles • Assumptions – model and its validation will be completed to end of June 3/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  4. 2. MATHEMATICAL MODEL Model approach • Lagrangian particle model • Simulation of fluctuation by the Monte Carlo method • Fortran 77 code Meteorological wind field (time independent) • homogenous wind field • computer code CALMET • computer code MATHEW 4/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  5. 2. MATHEMATICAL MODEL Source term • Initial volume of source term can be composed from up to 8 independent volumes • Up to 8 diameter of particles (aerosols) • Each diameter of particle have own density • Initial distribution of particles in sources (random, hat, gaussian) Removal processes • Gravitational settlement, Dry and wet deposition, Radioactive decay 5/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  6. 2. MATHEMATICAL MODEL Dose rate • Calculation for 1 mono-energetic photon emission • Dose rate [Gy/h] in air from ground exposure • Numerical integration of contribution from all area (step 1 x 1 m) • Berger form of a build-up factor • Energy of gamma rays, E = 0.140510 MeV 6/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  7. 3. UNCERTAINTIES • Meteorological uncertainties – wind speed, wind direction, category of stability • Geometric shape and dimension of initial clouds • Distribution of volume activity in initial clouds • Distribution of the activity as function of the aerosol (particle) diameters • Distribution of particles with different diameter as function of the height • Density for each diameter of aerosols (particles) 7/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  8. 4. INPUT DATA We suppose that geometrical shape of initial source term is composed from 2 independent volumes Table: Simulation of source term volumes for Test2 Center of volume Length, Wide, Thickness Fraction of emission No. X,Y,Z [m] [m] [-] 1 0.0, 0.0, 1.0 13.0, 6.0, 2.0 0.20 2 0.0, 0.0, 3.5 4.0, 2.0, 3.0 0.80 8/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  9. 9/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  10. Measured and used meteorological input data Date Explosion time Wind speed Wind direction * Stability category 06-12-2007 12:45 pm 4.00 m/s SW C (ETE) 15-05-2008 11:30 am 0.59 m/s S A (ETE) 05-05-2009 12:22 pm 1.30 m/s WNW B (ETE) 14-07-2010 12:42 pm 0.20 m/s S A (estimate) 05-05-2009 – data from 1 st meteorological station, * measured value, for calculation was used the direction South + 10 degrees ETE – meteorological station near to NPP Temelin 10/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  11. List of simulated particles parameters Dry deposition Fraction of Density [g/cm 3 ] No. Diameter [µm] velocity [m/s] emission [-] 1 0.2 1.0 5.0E-03 0.20 2 1.0 1.0 1.5E-04 0.15 3 8.0 1.5 1.0E-03 0.50 4 20.0 2.0 8.0E-03 0.15 11/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  12. Calculated deposition for TEST 1 3.00E+07 2.50E+07 2.00E+07 1.50E+07 1.00E+07 5.00E+06 0.00E+00 -5 0 5 10 15 20 25 30 35 40 45 12/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  13. Calculated deposition for TEST 2 1.20E+08 1.00E+08 8.00E+07 6.00E+07 4.00E+07 2.00E+07 0.00E+00 -5 0 5 10 15 20 25 30 35 40 45 13/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  14. 5. PRELIMINARY RESULTS OF COMPARISON • Test 1 – result for deposition are in approximately agreement with measurements (max. value ≈ 10 7 Bq/m 2 ) • Test 2 – result for deposition are not in agreement with measurements (max. value ≈ 10 5 Bq/m 2 ) • Main task for present time – to find an appropriate model for volume source term and distribution of particles • Assumptions – model and its validation will be completed to end of June 14/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia

  15. Thank you for your attention 15/28 WG 9 “Urban Areas” VUJE, Inc. Okružná 5, 918 64 Trnava, Slovakia
