showers with LOFAR Laura Rossetto 35 th ICRC July 13 th 2017 - PowerPoint PPT Presentation

Characterisation of radio frequency spectrum emitted by high energy air showers with LOFAR Laura Rossetto 35 th ICRC July 13 th 2017 Bexco, Busan, South Korea The LO LOw w F Frequency requency AR ARray ray The M. van Haarlem


  1. Characterisation of radio frequency spectrum emitted by high energy air showers with LOFAR Laura Rossetto 35 th ICRC – July 13 th 2017 – Bexco, Busan, South Korea

  2. The LO LOw w F Frequency requency AR ARray ray The M. van Haarlem et al., A&A 556, A2, 2013 → 50 stations in Northern Europe: The Netherlands, France, Germany, Ireland, Poland, Sweden, and UK → 24 stations ( ~ 2 km radius) located in Northern Netherlands form the LOFAR core → 6 stations ( ~ 320 m diameter) form the LOFAR “Superterp” 2 2 Laura Rossetto – 35 th Laura Rossetto – 35 th ICRC – July 13 ICRC – July 13 th th 2017, Busan 2017, Busan

  3. The LO LOw w F Frequency requency AR ARray ray The Each Dutch station has: → 96 Low Band Antennas (LBAs) frequency = 10 – 90 MHz → two orthogonal dipole arms with orientation NE – SW and NW – SE → 48 High Band Antennas (HBAs) frequency = 110 – 240 MHz 3 3 3 3 Laura Rossetto – 35 th Laura Rossetto – 35 th ICRC – July 13 ICRC – July 13 th th 2017, Busan 2017, Busan

  4. The LO LOw w F Frequency requency AR ARray ray The Posters id 402 id 413 → the six central stations are instrumented with 20 scintillators which give the main trigger for Cosmic Ray event detection → cosmic ray E = 10 16 – 10 18 eV S. Thoudam et al., Nucl. Inst. Meth. A 767, 339, 2014 4 3 4 3 Laura Rossetto – 35 th Laura Rossetto – 35 th ICRC – July 13 ICRC – July 13 th th 2017, Busan 2017, Busan

  5. Radio emission processes of EAS Radio emission processes of EAS Geomagnetic synchrotron emission Charge excess emission → separation of charged particles due to → negative charge excess produced at the geomagnetic field the shower front A. Nelles et al., JCAP 05, 18, 2015 O. Scholten et al., PRD 94, 103010, 2016 3 5 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 5 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  6. Frequency spectrum study Frequency spectrum study GOALS: → to characterise the pattern of radio signals in the frequency–domain → to improve the reconstruction of the showers, i.e. position of the shower axis at ground, energy and mass composition of primary particle ANALYSIS: → Analysis applied to data collected by LOFAR since 2011 and CORSIKA/CoREAS simulated showers D max = 3.6 km D max = 5.9 km D max = 6.1 km 6 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 6 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  7. Frequency spectrum study: the method Frequency spectrum study: the method 1. Signal in the time–domain has been converted to the frequency–domain by applying a Fast Fourier Transform on Δ t = 128 samples = 640 ns (1 sample = 5 ns) 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  8. Frequency spectrum study: the method Frequency spectrum study: the method 1. Signal in the time–domain has been converted to the frequency–domain by applying a Fast Fourier Transform on Δ t = 128 samples = 640 ns (1 sample = 5 ns) 2. |FFT| 2 Signal → evaluated on Δ t = [ t 0 – 240 ns , t 0 + 400 ns ] where t 0 = time of the pulse–peak 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  9. Frequency spectrum study: the method Frequency spectrum study: the method 1. Signal in the time–domain has been converted to the frequency–domain by applying a Fast Fourier Transform on Δ t = 128 samples = 640 ns (1 sample = 5 ns) 2. |FFT| 2 Signal → evaluated on Δ t = [ t 0 – 240 ns , t 0 + 400 ns ] where t 0 = time of the pulse–peak 3. |FFT| 2 Background → evaluated on 400 sub-windows outside the pulse region 7 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 7 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  10. Frequency spectrum study: the method Frequency spectrum study: the method 1. Signal in the time–domain has been converted to the frequency–domain by applying a Fast Fourier Transform on Δ t = 128 samples = 640 ns (1 sample = 5 ns) 2. |FFT| 2 Signal → evaluated on Δ t = [ t 0 – 240 ns , t 0 + 400 ns ] where t 0 = time of the pulse–peak 3. |FFT| 2 Background → evaluated on 400 sub-windows outside the pulse region 4. |FFT| 2 = |FFT| 2 Signal – |FFT| 2 Background 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  11. Frequency spectrum study: the method Frequency spectrum study: the method 1. Signal in the time–domain has been converted to the frequency–domain by applying a Fast Fourier Transform on Δ t = 128 samples = 640 ns (1 sample = 5 ns) 2. |FFT| 2 Signal → evaluated on Δ t = [ t 0 – 240 ns , t 0 + 400 ns ] where t 0 = time of the pulse–peak 3. |FFT| 2 Background → evaluated on 400 sub-windows outside the pulse region 4. |FFT| 2 = |FFT| 2 Signal – |FFT| 2 Background 5. linear fit applied to log 10 |FFT| 2 in the range ν = 33 – 70 MHz log 10 |FFT| 2 = a + slope · ν 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 3 7 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  12. Real data results Real data results → Event selection criteria: 1) at least 1 station with half antennas having signal > 10 σ → 142 events 2) events with at least 10 antennas with | FFT( ν i ) | 2 > RMS ( | FFT( ν i ) | 2 B ) → 103 events → Linear–fit applied to all antennas of each selected event 8 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 3 8 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  13. Real data results – Shower axis distance Real data results – Shower axis distance → Event selection criteria: 1) at least 1 station with half antennas having signal > 10 σ → 142 events 2) events with at least 10 antennas with | FFT( ν i ) | 2 > RMS ( | FFT( ν i ) | 2 B ) → 103 events → Linear–fit applied to all antennas of each selected event → the slope–parameter shows a E = 1.7 · 10 17 eV parabolic distribution as function of X max = 757 g/cm 2 distance to the shower axis 3 9 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 3 9 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  14. Real data results – Shower axis distance Real data results – Shower axis distance → Event selection criteria: 1) at least 1 station with half antennas having signal > 10 σ → 142 events 2) events with at least 10 antennas with | FFT( ν i ) | 2 > RMS ( | FFT( ν i ) | 2 B ) → 103 events → Linear–fit applied to all antennas of each selected event syst. unc. → comparison to simulations X max (sim) = 755 g/cm 2 → maximum around 100 m in agreement X max = 757 g/cm 2 with the Cherenkov ring region 3 9 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 9 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  15. Real data results – D max correlation Real data results – D max correlation Slope at 180 m ( MHz –2 ) Slope at 220 m ( MHz –2 ) 33/103 events 22/103 events D max (km) D max (km) → the slope parameter depends on the geometrical distance of the observer from X max (i.e. D max ) α → at fix distances from the shower axis: slope ( D max )= D max )−γ 1 + exp (−β⋅ 10 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 10 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan

  16. Conclusions Conclusions • Radio frequency spectrum has been studied in the range 30 – 70 MHz • linear–fit applied to real data detected by LOFAR since 2011, and to corresponding CORSIKA/CoREAS simulated showers • clear dependence of the frequency spectrum as function of distance to the shower axis has been obtained → this can be used as an independent method to reconstruct the position of the shower axis at ground Poster id 402 • At fixed distances from the shower axis, the frequency spectrum depends also on the geometrical distance to X max → independent method for X max reconstruction 11 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan 11 3 Laura Rossetto – 35 th ICRC – July 13 th 2017, Busan
