Key Concept #2: Dumb Network • Original Internet design: interior nodes (“routers”) have no knowledge* of ongoing connections going through them • Not : how you picture the telephone system works – Which internally tracks all of the active voice calls • Instead: the postal system! – Each Internet message (“packet”) self-contained – Interior routers look at destination address to forward – If you want smarts, build it “ end-to-end ”, not “hop-by-hop” – Buys simplicity & robustness at the cost of shifting complexity into end systems * Today’s Internet is full of hacks that violate this 44
Key Concept #3: Layering • Internet design is strongly partitioned into layers – Each layer relies on services provided by next layer below … – … and provides services to layer above it • Analogy: – Consider structure of an Code You Write application you’ve written Run-Time Library and the “services” each System Calls layer relies on / provides Magnetic Domains } Device Drivers Fully isolated Voltage Levels / from user programs 45
Internet Layering ( “ Protocol Stack ” ) Note on a point of potential confusion: these diagrams are always drawn with lower layers below higher layers … 7 Application But diagrams showing the layouts of packets 4 Transport are often the opposite , with the lower layers at the top since their headers precede those 3 (Inter)Network for higher layers 2 Link 1 Physical 46
Horizontal View of a Single Packet First bit transmitted (Inter)Network Transport Application Data: structure Link Layer Layer Header Layer depends on the application Header (IP) Header … 47
Vertical View of a Single Packet Link Layer Header First bit transmitted (Inter)Network Layer Header (IP) Transport Layer Header Application Data: structure depends on the application . . . . . . 48 .
Internet Layering ( “ Protocol Stack ” ) 7 Application 4 Transport 3 (Inter)Network 2 Link 1 Physical 49
Layer 1: Physical Layer 7 Application 4 Transport Encoding bits to send them over a single physical link 3 (Inter)Network e.g. patterns of 2 Link voltage levels / photon intensities / 1 Physical RF modulation 50
Layer 2: Link Layer Framing and transmission of a collection of bits into individual messages sent across a single 7 Application “subnetwork” (one physical technology) 4 Transport 3 (Inter)Network Might involve multiple physical 2 Link links (e.g., modern Ethernet) 1 Physical Often technology supports broadcast transmission ( every “node” connected to subnet receives) 51
Layer 3: (Inter)Network Layer (IP) Bridges multiple “subnets” to provide end-to-end internet connectivity between nodes 7 Application • Provides global addressing 4 Transport Works across different link 3 (Inter)Network technologies } 2 Link Different for each Internet “hop” 1 Physical 52
Layer 4: Transport Layer End-to-end communication between processes 7 Application Different services provided: TCP = reliable byte stream 4 Transport UDP = unreliable datagrams 3 (Inter)Network ( Datagram = single packet message) 2 Link 1 Physical 53
Layer 7: Application Layer Communication of whatever you wish 7 Application Can use whatever transport(s) is convenient 4 Transport 3 (Inter)Network Freely structured 2 Link E.g.: 1 Physical Skype, SMTP (email), HTTP (Web), Halo, BitTorrent 54
Internet Layering ( “ Protocol Stack ” ) } Implemented only at hosts, 7 Application not at interior routers 4 Transport (“dumb network”) 3 (Inter)Network 2 Link 1 Physical 55
Internet Layering ( “ Protocol Stack ” ) 7 Application 4 Transport } 3 (Inter)Network 2 Link Implemented everywhere 1 Physical 56
Internet Layering ( “ Protocol Stack ” ) 7 Application 4 Transport } 3 (Inter)Network ~Same for each Internet “hop” } 2 Link Different for each Internet “hop” 1 Physical 57
Hop-By-Hop vs. End-to-End Layers Host A communicates with Host D Host C Host D Host A Router 1 Router 2 Router 3 Router 5 Host B Host E Router 7 Router 6 Router 4 58
Hop-By-Hop vs. End-to-End Layers Host A communicates with Host D Host C Host D Host A E.g., Ethernet Router 1 Router 2 Router 3 E.g., Wi-Fi Router 5 Host B Host E Router 7 Router 6 Router 4 Different Physical & Link Layers (Layers 1 & 2) 59
Hop-By-Hop vs. End-to-End Layers Host A communicates with Host D Host C Host D Host A Router 1 Router 2 Router 3 Router 5 E.g., HTTP over TCP over IP Host B Host E Router 7 Router 6 Router 4 Same Network / Transport / Application Layers (3/4/7) (Routers ignore Transport & Application layers) 60
Layer 3: (Inter)Network Layer (IP) Bridges multiple “subnets” to provide end-to-end internet connectivity between nodes 7 Application • Provides global addressing 4 Transport Works across different link 3 (Inter)Network technologies 2 Link 1 Physical 61
IP Packet Structure 4-bit 8-bit 4-bit 16-bit Total Length (Bytes) Header Type of Service Version Length (TOS) 3-bit 16-bit Identification 13-bit Fragment Offset Flags 8-bit Time to 8-bit Protocol 16-bit Header Checksum Live (TTL) 32-bit Source IP Address 32-bit Destination IP Address Options (if any) Payload
IP Packet Structure 4-bit 8-bit 4-bit 16-bit Total Length (Bytes) Header Type of Service Version Length (TOS) 3-bit 16-bit Identification 13-bit Fragment Offset Flags Specifies the length of the entire 8-bit Time to IP packet: bytes in this header 8-bit Protocol 16-bit Header Checksum Live (TTL) plus bytes in the Payload 32-bit Source IP Address 32-bit Destination IP Address Options (if any) Payload
IP Packet Structure 4-bit 8-bit 4-bit 16-bit Total Length (Bytes) Header Type of Service Version Length (TOS) 3-bit 16-bit Identification 13-bit Fragment Offset Flags Specifies how to interpret the start of the Payload , which is 8-bit Time to 8-bit Protocol 16-bit Header Checksum the header of a Transport Live (TTL) Protocol such as TCP or UDP 32-bit Source IP Address 32-bit Destination IP Address Options (if any) Payload
IP Packet Structure 4-bit 8-bit 4-bit 16-bit Total Length (Bytes) Header Type of Service Version Length (TOS) 3-bit 16-bit Identification 13-bit Fragment Offset Flags 8-bit Time to 8-bit Protocol 16-bit Header Checksum Live (TTL) 32-bit Source IP Address 32-bit Destination IP Address Options (if any) Payload
IP Packet Header (Continued) •Two IP addresses – Source IP address (32 bits) – Destination IP address (32 bits) •Destination address – Unique identifier/locator for the receiving host – Allows each node to make forwarding decisions •Source address – Unique identifier/locator for the sending host – Recipient can decide whether to accept packet – Enables recipient to send a reply back to source 66
Postal Envelopes: (Post office doesn’t look at the letter inside the envelope) 67
Analogy of IP to Postal Envelopes: IP source address IP destination address (Routers don’t look at the payload beyond the IP header) 68
IP: “ Best Effort ” Packet Delivery •Routers inspect destination address, locate “next hop” in forwarding table – Address = ~unique identifier/locator for the receiving host •Only provides a “ I’ll give it a try ” delivery service: – Packets may be lost – Packets may be corrupted – Packets may be delivered out of order source destination IP network 69
“ Best Effort ” is Lame! What to do? •It’s the job of our Transport (layer 4) protocols to build services our apps need out of IP’s modest layer-3 service 70
Layer 4: Transport Layer End-to-end communication between processes 7 Application Different services provided: TCP = reliable byte stream 4 Transport UDP = unreliable datagrams 3 (Inter)Network ( Datagram = single packet message) 2 Link 1 Physical 71
“ Best Effort ” is Lame! What to do? •It’s the job of our Transport (layer 4) protocols to build services our apps need out of IP’s modest layer-3 service •#1 workhorse: TCP ( Transmission Control Protocol ) •Service provided by TCP: – Connection oriented (explicit set-up / tear-down) o End hosts (processes) can have multiple concurrent long-lived communication – Reliable , in-order, byte-stream delivery o Robust detection & retransmission of lost data 72
TCP “ Bytestream ” Service Process A on host H1 Byte 0 Byte 1 Byte 2 Byte 3 Byte 80 Hosts don’t ever see packet boundaries, lost or corrupted packets, retransmissions, etc. Process B on host H2 Byte 0 Byte 1 Byte 2 Byte 3 Byte 80 73
Bidirectional communication: Process B on host H2 Byte 0 Byte 1 Byte 2 Byte 3 Byte 73 There are two separate bytestreams , one in each direction Process A on host H1 Byte 0 Byte 1 Byte 2 Byte 3 Byte 73 74
TCP Header Source port Destination port Sequence number Acknowledgment Advertised window HdrLen Flags 0 Checksum Urgent pointer Options (variable) Data 75
TCP Header Ports are Source port Destination port associated with OS Sequence number processes Acknowledgment Advertised window HdrLen Flags 0 Checksum Urgent pointer Options (variable) Data 76
(Link Layer Header) TCP Header (IP Header) Ports are Source port Destination port associated with OS Sequence number processes Acknowledgment IP source & destination Advertised window HdrLen Flags 0 addresses plus TCP source and destination Checksum Urgent pointer ports uniquely identifies a TCP connection Options (variable) Data 77
TCP Header Ports are Source port Destination port associated with OS Sequence number processes Acknowledgment IP source & destination Advertised window HdrLen Flags 0 addresses plus TCP source and destination Checksum Urgent pointer ports uniquely identifies a TCP connection Options (variable) Some port numbers are “well known” / reserved Data e.g. port 80 = HTTP 78
TCP Header Source port Destination port Starting sequence Sequence number number (byte offset) of data Acknowledgment carried in this Advertised window HdrLen Flags 0 packet Checksum Urgent pointer Options (variable) Data 79
TCP Header Source port Destination port Starting sequence Sequence number number (byte offset) of data Acknowledgment carried in this Advertised window HdrLen Flags 0 packet Checksum Urgent pointer Byte streams Options (variable) numbered independently in each direction Data 80
TCP Header Source port Destination port Starting sequence Sequence number number (byte offset) of data Acknowledgment carried in this Advertised window HdrLen Flags 0 packet Checksum Urgent pointer Byte stream Options (variable) numbered independently in each direction Data Sequence number assigned to start of byte stream is picked when connection begins; doesn’t start at 0 81
TCP Header Source port Destination port Sequence number Acknowledgment gives seq # just Acknowledgment beyond highest Advertised window seq. received in HdrLen Flags 0 order . Checksum Urgent pointer If sender sends Options (variable) N bytestream bytes starting at Data seq S then “ack” for it will be S+N . 82
Sequence Numbers Host A ISN (initial sequence number) Sequence ACK sequence TCP TCP Data HDR number from A number from B = 1 st byte of = next expected data byte TCP TCP Data HDR Host B 83
TCP Header Source port Destination port Sequence number Uses include: Acknowledgment acknowledging Advertised window data (“ ACK ”) HdrLen Flags 0 Checksum Urgent pointer setting up (“ SYN ”) and closing Options (variable) connections (“ FIN ” and “ RST ”) Data 84
Establishing a TCP Connection B A SYN Each host tells its Initial Sequence SYN+ACK Number (ISN) to the other host. ACK D a (Spec says to pick based t a D on local clock) a t a •Three-way handshake to establish connection – Host A sends a SYN (open; “synchronize sequence numbers”) to host B – Host B returns a SYN acknowledgment ( SYN + ACK ) – Host A sends an ACK to acknowledge the SYN + ACK 85
Timing Diagram: 3-Way Handshaking Passive Different starting Open initial sequence Active numbers (ISNs) in Server Open each direction listen() Client (initiator) connect() SYN, SeqNum = x SYN + ACK, SeqNum = y, Ack = x + 1 ACK, Ack = y + 1 accept() 86
Layer 7: Application Layer Communication of whatever you wish 7 Application Can use whatever transport(s) is convenient 4 Transport 3 (Inter)Network Freely structured 2 Link E.g.: 1 Physical Skype, SMTP (email), HTTP (Web), Halo, BitTorrent 87
Web (HTTP) Request Method Resource HTTP version Headers GET /index.html HTTP/1.1 Accept: image/gif, image/x-bitmap, image/jpeg, */* Accept-Language: en Connection: Keep-Alive User-Agent: Mozilla/1.22 (compatible; MSIE 2.0; Windows 95) Host: www.example.com Referer: http://www.google.com?q=dingbats Blank line Data (if POST; none for GET) GET: download data. POST: upload data.
Web (HTTP) Response HTTP version Status code Reason phrase Headers HTTP/1.0 200 OK Date: Sun, 19 Apr 2009 02:20:42 GMT Server: Microsoft-Internet-Information-Server/5.0 Connection: keep-alive Data Content-Type: text/html Last-Modified: Sat, 18 Apr 2009 17:39:05 GMT Set-Cookie: session=44eb; path=/servlets Content-Length: 2543 <HTML> Some data... blah, blah, blah </HTML>
Host Names vs. IP addresses •Host names – Examples: www.cnn.com and bbc.co.uk – Mnemonic name appreciated by humans – Variable length, full alphabet of characters – Provide little (if any) information about location •IP addresses – Examples: 64.236.16.20 and 212.58.224.131 – Numerical address appreciated by routers – Fixed length, binary number – Hierarchical, related to host location 90
Networking Attacks: Link-, IP-, and TCP-layer attacks
General Communication Security Goals: CIA •Confidentiality: – No one can read our data / communication unless we want them to •Integrity – No one can manipulate our data / processing / communication unless we want them to •Availability – We can access our data / conduct our processing / use our communication capabilities when we want to 92
No security built in at the network level •Everything you have seen in this lecture is just plaintext, to integrity attached to it so an attacker can easily spoof packets at multiple levels •TLS will give application level security 93
Link-layer threats • Confidentiality: eavesdropping (aka sniffing) • Integrity: injection of spoofed packets • Availability: delete legit packets (e.g., jamming) 94
Layers 1 & 2: General Threats? Framing and transmission of a collection of bits into individual messages sent across a single 7 Application “subnetwork” (one physical technology) 4 Transport 3 (Inter)Network 2 Link Encoding bits to send them over a single physical link 1 Physical e.g. patterns of voltage levels / photon intensities / RF modulation 95
Eavesdropping • For subnets using broadcast technologies (e.g., WiFi, some types of Ethernet), eavesdropping comes for “free” – Each attached system’s NIC (= Network Interface Card) can capture any communication on the subnet – Some handy tools for doing so o tcpdump / windump (low-level ASCII printout) o Wireshark (GUI for displaying 800+ protocols) 96
TCPDUMP: Packet Capture & ASCII Dumper 97
Wireshark: GUI for Packet Capture/Exam. 98
Wireshark: GUI for Packet Capture/Exam. 99
Wireshark: GUI for Packet Capture/Exam. 100
