SANReN Network overview. Ntuthuko Sambo CSIR Meraka Institute 3 July 2012 Roles Vision and funding: Ministry of Science and Technology Design and build: CSIR Meraka Insitutute Operate: TENET (university owned ISP) Use: Beneficiary

  1. SANReN Network overview. Ntuthuko Sambo CSIR Meraka Institute 3 July 2012

  2. Roles Vision and funding: Ministry of Science and Technology Design and build: CSIR Meraka Insitutute Operate: TENET (university owned ISP) Use: Beneficiary institutions Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 2 / 18

  3. Team TENET: based in Cape Town and Johannesburg (about 12 people) SANReN: based in Pretoria (about 14 people) Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 3 / 18

  4. Scope and objectives Connect HEI and Research councils (DST list) Establish national back-bone to interconnect major cities Build metro networks to connect end sites to PoPs (1Gbps or 10Gbps) Extend network to smaller towns and cities Develop and deliver services over SANReN Interconnect internationally Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 4 / 18

  5. SANReN map Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 5 / 18

  6. Design Mixture of MPLS and Metro-Ethernet Core: Cisco CRS-1 Distribution: Cisco 7600 and ASR9K Access: Cisco ME4924 and ALU 7210SAS-M Optical Transmission/Access: Cisco DWDM (ONS15454 MSTP) Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 6 / 18

  7. Core Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 7 / 18

  8. Core+Edge Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 8 / 18

  9. Core+Edge+Grey Rings Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 9 / 18

  10. Core+Edge+Grey Rings+DWDM sites Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 10 / 18

  11. L2 configuration Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 11 / 18

  12. L3 configuration Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 12 / 18

  13. Optical transmission Large research sites on dedicated 10G ports: DWDM: TUT, UP, UNISA, UJ, UCT, UWC, SUN, iThemba Labs Directly connected: WITS, CSIR, UFS, CHPC Backbone is still shared! Interface: 10GBase-LR Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 13 / 18

  14. Grey rings Shared 10Gbps rings (1Gbps customer ports) Interface: 1000Base-X (T, LX, SX) Can bond multiple 1Gbps interfaces, or provision them independently Alcatel accepts module for additional two 10Gbps ports if required Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 14 / 18

  15. Services available TENET Internet access Highly available gateway address: static routing or BGP Layer 3 VPN (no takers yet) Layer 2 VPN Point-to-point: Pseudo-wires, aka Ethernet-over-MPLS (the workhorse) Multi-point: VPLS (virtual Ethernet switching - no takers yet) VPN services can be used in different ways: Replace physical WAN circuits to SANReN-connected remote sites Private interconnection between institutions (DR agreements, research projects) Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 15 / 18

  16. Focus of our services effort Idea is to help institutions leverage the network Requirements depend on who is asking: IT departments are proxies for their customer’s needs (needs: cloud computing, DR, identity federation, mail filtering, etc) Research communities are special customers (support SAGrid, dedicated circuits for science (light-paths), etc) Some are low hanging fruit (Eduroam) Others are non-trivial, and maybe not worthwhile (VoIP?) Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 16 / 18

  17. Focus of our services effort cont Federated Identity (FID) Work in progress, work group project managed by Siju Mammen (smammen@csir.co.za) Perfsonar Has solved a lot of bottlenecks on the network, most times from the client’s side of the network Helps us help the customer Lead by Roderick Mooi (rmooi@csir.co.za) CSIRT (Security Incidence Response Team), some call it CERT Work in progress, security initiative led by Roderick Mooi as well Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 17 / 18

  18. Conclusion Questions? nsambo@csir.co.za Ntuthuko Sambo (CSIR Meraka Institute) SANReN 3 July 2012 18 / 18
