S E A T T L E A R E N A Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016

PUBLIC BENEFITS OVERVIEW L E G E N D Publicly Accessible Open Space & Living Machine 1 3rd Ave S S Mass. St ROW Improvements & Curbless Street 2 1st Ave S Enhanced ROW Improvements 3 S Holgate St Enhanced ROW Improvements 4 4 Public Art Program 5 Bike Facilities 6 Off-Site Wayfinding 7 S Holgate St 5 Ped/Bike Bridge Amtrak Office Safeco Garage Parking Garage Surface Parking Occidental Ave S Occidental Ave S ARENA 5 S Walker St 2 1 5 4 3 5 7 3 7 1st Ave S S Mass. St 6 6 Utah Ave S Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 2

SITE PLAN - ENLARGEMENT Project Proposal Pedestrian Bridge Access Road Safeco Garage Service Player/Staff Entrance Safeco Access Drive Parking Parking Garage Public Restrooms Plaza Storage Bike Shop/Valet Ticket Reception Office S Holgate St ARENA Occidental Ave S Occidental Ave S Public Open Space & Living Machine S Massachusetts St Lobby Krispy Lobby Year Round Team Kreme Restaurant Store Stairs Stairs 1st Ave S 0 65 130 N Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 3

1- PUBLIC OPEN SPACE & LIVING MACHINE Site Plan Public Restroom Storage Bike Shop Ticket Office Reception / Valet 3 L E G E N D 2 Living Machine Gardens 1 1 Livi ng Machine Markers & Access S Massachusetts St 2 Hatches Interactive Display Panel 3 1 Water Feature 4 Programmable Community Area 5 2 Daytime Loading Zone 6 S. Mass. Curbless Street 7 Lobby 7 6 Significant Artwork 8 4 5 8 4 2 N 1st Ave S Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 4

1- PUBLIC OPEN SPACE & LIVING MACHINE Comparable Public Open Spaces 24,500 18,000 SF SF Pioneer Square Hing Hay Park 31,800 SF 35,000 SF Arena Public Open Space 35,000 SF Westlake Park Occidental Park Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 5

1- PUBLIC OPEN SPACE & LIVING MACHINE Event Programming Outdoor Market / Art Fair Educational Tour / Outdoor Classroom Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 6

1- PUBLIC OPEN SPACE & LIVING MACHINE Living Machine LIVING MACHINE • A Living Machine is an ecological sewage treatment facility that will enable a 99% reduction in wastewater • It will remove 4 million gallons of wastewater each year from the overflowing combined sewer 1 system (not required by code) • Treated water will be re-used in the building for toilet flushing, landscape irrigation and other potentail re-use. 7 2 6 • The system is scalable and allows for a district opportunities 3 • The system is educational opportunities and can be incorporated into the public open space 2 program • The sytems is the first of its kind among North 8 2 American sports facilities 4 LEGEND Settling Tank 1 Equalization & 2 Recirculation Tank Stage 1 Treatment Cells 3 5 Stage 2 Treatment Cell 4 Arena building edge Reuse Tank 5 Potential Reuse: toilets, irrigation hockey rink ice 6 Interactive Display Panel 7 Garden Beds at Public Open Space 8 Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 7

1- PUBLIC OPEN SPACE & LIVING MACHINE View of Living Machine Gardens Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 8

2 - S MASSACHUSSETTS ST ROW IMPROVEMENTS Existing Condition Occidental Future Development Ave S Safeco Access Drive Curbless Street Loading Public Utah Ave 1st Ave S Open Space Proposed Street Alignment and Improvements N Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 9

2 - S. MASSACHUSSETTS ST ROW IMPROVEMENTS Street Section Private Arena Property Public 24’ 10’ 34’ 12’ Open Space Planting / Furn. Zone Loading Drive Lanes Sidewalk 80’ ROW S Massachussets St east of 1st Ave S. Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 10

3 - 1 ST AVE S. ROW IMPROVEMENTS S Massachussets St to S Holgate S (Arena Frontage) ARENA B A Clear Zone Rain Garden S Holgate St S MasS St 1st Ave S 23’ min 23’ min A B Clear Zone Drive Lanes Clear Zone Drive Lanes Rain Garden Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 11

3 - 1 ST AVE S. ROW IMPROVEMENTS Edgar Martinez Dr S to S Massachussets St (block north of Arena site) ARENA Private Property Ped Zone A B Rain Garden Edgar Martinez Dr S S MasS St 1st Ave S 16’-0” 16’-0” Existing Existing A B Ped. Zone Ped. Zone Parking Lot Drive Lanes Rain Garden Drive Lanes Building Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 12

3 - 1 ST AVE S. ROW IMPROVEMENTS 1 Ave S. looking south Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 13

4 - S. HOLGATE ST ROW IMPROVEMENTS Existing Condition N 3rd Ave S 4th Ave S 1st Ave S Proposed Arena Rail Corridor Wells Pedestrian Fargo Bridge S Holgate St Occ. Ave S Krispy Proposed Arena Jack In Amtrak Kreme Parking Garage The Box Proposed Street Alignment and Improvements Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 14

4 - S. HOLGATE ST ROW IMPROVEMENTS Section at Pedestrian Bridge 11’ 30’ 3’ Planting Sidewalk Rain garden / Vertical circulation Setback Drive Lanes Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 15

4 - S. HOLGATE ST ROW IMPROVEMENTS Pedestrian Bridge 4th Ave S. 3 r d A v e S . East Landing & Ramp Direct Connection to Arena West Landing Rail Corridor & Ramp S. Holgate St. O c 1st Ave S c . A v e S . Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 16

4 - S. HOLGATE ST ROW IMPROVEMENTS Pedestrian Bridge West Landing & Ramp 1st Ave S Rail Corridor S. Holgate St. 3rd Ave S. East Landing & Ramp Wells Fargo Bank Drive Thru Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 17

5 - PUBLIC ART Access Road P U B L I C A R T L O C AT I O N S A Significant Artwork for Public Open Space D B Temporary Artworks C Integrated Artworks in ROW S Holgate St D Pedestrian Bridge Occidental Ave S Occidental Ave S S Massachusetts St A B C C 1st Ave S 0 65 130 N Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 18

6 - BICYCLE FACILITIES Existing and Planned Mountain to Sound Greenway Connection to Holgate Ramp (SDOT) Airport Way Cycle Track S. Lander St. Holgate Multi-Use Trail (SDOT) S. Holgate St. 6th Ave S. 4th Ave S. E. Martinez Dr. S. Pedestrian / Bike Bridge Century S. Jackson St. Link Field Safeco Field Holgate Multi-Use Trail Occidental Ave S. 1st Ave S. S. Atlantic St. Existing Utah Greenway Waterfront Trail Atlantic Multi-Use B I K E FA C I L I T I E S Trail Connection P R O P O S E D B Y A R E N A L E G E N D Off Street 0 600 1200 Cycle Track N In Street Alaskan Way Greenway Cycle Track Shared-Use Street Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 19

6 - BICYCLE FACILITIES Arena Bike Parking Access Road Garage Bike Staff Parking Bike Parking Valet Bike Parking S Holgate St Occidental Ave S Occidental Ave S Holgate Pronto! Station S Massachusetts St Holgate Bike Plaza Racks Pronto! Station 1st Ave Bike Racks 1st Ave S 0 65 130 N Seattle Arena Public Benefits Review | City Council Sustainability & Transportation Committee | April 19, 2016 20
