Ribs Wing Structures Aerospace Structures Function of Ribs - PowerPoint PPT Presentation

Ribs Wing Structures Aerospace Structures Function of Ribs Maintain aerodynamic profile of wing Transfer aerodynamic & fuel loads on skin to structure Provide stability against panel buckling Function of Ribs Introduce local load into


  1. Ribs Wing Structures Aerospace Structures

  2. Function of Ribs Maintain aerodynamic profile of wing Transfer aerodynamic & fuel loads on skin to structure Provide stability against panel buckling

  3. Function of Ribs Introduce local load into the structure • i.e. landing gear, engines, flaps, ailerons, etc Sealing the integral fuel tank • Fuel surge/splashing

  4. Function of Ribs No ribs: Crushing Not enough ribs: Rib pitch: Buckling Typically 0.2 - 1 m

  5. Selection of Ribs & Manufacturing Method Depends on: • Loads • Design philosophy • Available equipment and experience • Costs

  6. Types of Ribs & Manufacturing Method Form & plate ribs • Stiffening profile • Low loads Forged or machined ribs • Very high loads

  7. Rib-stringer intersections Three general solutions: – Both rib and stringer not interrupted – Stringer interrupted – Rib interrupted

  8. Rib-stringer intersections Three general solutions – Both rib and stringer not interrupted – Stringer interrupted – Rib interrupted

  9. Rib-stringer intersections Three general solutions – Both rib and stringer not interrupted – Stringer interrupted – Rib interrupted
