NoHo Historic District Extension Location Map NoHo Historic District Extension Map 54 BOND STREET 54 Bond Street Information LANDMARK TYPE | INDIVIDUAL LANDMARK BOND STREET SAVINGS BANK | LP-0192 DESIGNATION DATE | JANUARY 10, 1967 ARCHITECT | HENRY ENGELBERT CONSTRUCTION DATE(S) | 1873 - 1874 CURRENT ZONING DISTRICT | C6-1 HISTORIC ZONING DISTRICT | M1-5 RETAIL SIGNAGE INSTALLATION SITE INFORMATION 54 BOND STREET, NEW YORK, NY S1 29 NOVEMBER 2016

RETAIL TENANT RETAIL TENANT LOCATION VIEW LOOKING WEST DOWN BOND STREET RETAIL SIGNAGE INSTALLATION SITE PHOTOS 54 BOND STREET, NEW YORK, NY S2 29 NOVEMBER 2016

LOCATION OF EXISTING RETAIL SIGNAGE EXISTING RETAIL SIGNAGE RETAIL SIGNAGE INSTALLATION SITE PHOTOS 54 BOND STREET, NEW YORK, NY S3 29 NOVEMBER 2016

B O W E R Y S T R E E T PROPOSED BLADE SIGN - SEPARATE FILING NOT YET INSTALLED PROPOSED POLE MOUNTED BLADE SIGN PROPOSED FENCE MOUNTED SIGN B O N D S T R E E T RETAIL SIGNAGE INSTALLATION SITE PLAN 54 BOND STREET, NEW YORK, NY S4 29 NOVEMBER 2016

EDGE OF FACADE PROPOSED BRACKET SIGN ON FLUTED POLE WITH DECORATIVE FINIAL WHITE PAINTED DECORATIVE FINAL FLAT BLACK PAINTED BRACKET PROPOSED SIGN ON PREVIOUSLY APPROVED FENCE RETAIL SPACE DESIGN FLOOR LEVEL POLE SUPPORT BRACKETS EPOXY BOLTED INTO NON- HISTORIC MASONRY AND CONCRETE 3/8” DEEP BRONZE LETTERS ON 1/4“ EXISTING AREAWAY STANDOFFS ATTACHED TO FLAT BLACK PAINTED WOOD SIGN. SIGN CON- STRUCTED WITH TWO LAYERS MARINE GRADE PLYWOOD WITH 3/4” THICK SOLID WOOD EDGE. 3” DIA. WHITE PAINTED FLUTED POST FRONT ELEVATION SIDE ELEVATION PARTIAL SECTION 1 1/2” = 1’ - 0” 1 1/2” = 1’ - 0” 1/4” = 1’ - 0” RETAIL SIGNAGE INSTALLATION POLE MOUNTED BLADE SIGN 54 BOND STREET, NEW YORK, NY S5 29 NOVEMBER 2016

LOCATION OF PROPOSED LOCATION OF POLE LOCATION OF POLE POLE MOUNTED BLADE SIGN SUPPORT BRACKETS SUPPORT BRACKET RETAIL SIGNAGE INSTALLATION POLE MOUNTED BLADE SIGN 54 BOND STREET, NEW YORK, NY S6 29 NOVEMBER 2016

3/8” DEEP BRONZE LETTERS ON 1/4“ STANDOFFS ATTACHED TO FLAT BLACK PAINTED WOOD SIGN. SIGN CONSTRUCTED WITH TWO LAYERS MARINE GRADE PLYWOOD WITH 3/4” THICK SOLID WOOD EDGE. SIGNAGE SECURED TO FENCE WITH RINGS ATTACHED TO REAR OF SIGN. STAIR TO RETAIL SPACE FRONT ELEVATION PARTIAL SECTION 1” = 1’ - 0” 1” = 1’ - 0” RETAIL SIGNAGE INSTALLATION FENCE MOUNTED SIGN 54 BOND STREET, NEW YORK, NY S7 29 NOVEMBER 2016

METAL RINGS SECURED TO METAL FENCE AND ATTACHED TO BACK OF METAL FENCE WOOD SIGN PAINTED STEEL RING ATTACHMENT PAINTED STEEL 5/8” STEEL TUBE RING ATTACHMENT PAINTED STEEL BRACKET W/ TAMPER PROOF SCREWS PAINTED STEEL WOOD SIGN BRACKET W/ TAMPER PROOF SCREWS ELEVATION DETAIL AT MOUNTING BRACKET REAR ELEVATION SECTION DETAIL AT MOUNTING BRACKET NTS NTS NTS RETAIL SIGNAGE INSTALLATION FENCE MOUNTED SIGN 54 BOND STREET, NEW YORK, NY S8 29 NOVEMBER 2016

PROPOSED NEW FENCE SIGN PROPOSED NEW APPROVED NEW BLADE SIGN FENCE DESIGN - NOT YET INSTALLED RETAIL SIGNAGE INSTALLATION PHOTO MONTAGE 54 BOND STREET, NEW YORK, NY BILLY REID SIGNAGE S9 29 NOVEMBER 2016

PROPOSED NEW BLADE SIGN - SEPARATE FILING NOT YET INSTALLED PROPOSED NEW BLADE SIGN PROPOSED NEW FENCE SIGN APPROVED NEW FENCE DESIGN - NOT YET INSTALLED RETAIL SIGNAGE INSTALLATION PHOTO MONTAGE 54 BOND STREET, NEW YORK, NY ALL PROPOSED SIGNAGE S10 29 NOVEMBER 2016
