Research in electromagnetic engineering at the Silesian University - PowerPoint PPT Presentation

Silesian University of Technology Gliwice, Poland Research in electromagnetic engineering at the Silesian University of Technology, Gliwice, Poland Andrzej Karwowski Silesian University of Technology Department of Electronics 3 rd Cost


  1. Silesian University of Technology Gliwice, Poland Research in electromagnetic engineering at the Silesian University of Technology, Gliwice, Poland Andrzej Karwowski Silesian University of Technology Department of Electronics 3 rd Cost Meeting Action IC0603 “ASSIST” Limassol, Cyprus April 9 – 11, 2008

  2. Silesian University of Technology Gliwice, Poland Who am I ? Andrzej Karwowski, PhD, DSc Member IET, IEEE (AP-S, EMC-S, MTT-S) Professor at SUT Leader of Radioelectronics and Electromagnetic Engineering (EE) Research Team at SUT e-mail: a.karwowski@theiet.org, a.karwowski@ieee.org

  3. Silesian University of Technology Gliwice, Poland Outline Silesian University of Technology (SUT) Key facts Electromagnetic engineering research team What are we doing and how? “Fast” hybrid MoM-PO method Numerical example

  4. Silesian University of Technology Gliwice, Poland Silesian University of Technology (SUT) Upper Silesia Region (Katowice) the greatest industrial region in Poland population 4.9 million Gliwice main location of STU (9 Faculties; 3 in Katowice and Zabrze)

  5. Silesian University of Technology Gliwice, Poland Silesian University of Technology (SUT) Statistics Number of students 32000 Number of academic 1750 teachers Number of employees 3300 Number of graduates 125000 Number of PhD 3500 graduates

  6. Silesian University of Technology Gliwice, Poland Silesian University of Technology (SUT) 12 Faculties Architecture Automatic Control, Electronics and Computer Science Civil Engineering Chemistry Electrical Engineering Mining and Geology Material Science and Metallurgy Energy and Environmental Engineering Mathematics and Physics Mechanical Engineering Organization and Management Transport

  7. Silesian University of Technology Gliwice, Poland Silesian University of Technology (SUT) Faculty of Automatic Control, Electronics and Computer Science Department of Automatic Control Department of Electronics Department of Computer Science Department of Electronics Courses in Electronics and Telecommunications with honors in Electronic equipment, Biomedical electronics, Microelectronics, Telecommunications , Radioelectronics Radioelectronics Electromagnetic Engineering Research Team (5 PhDs permanent)

  8. Silesian University of Technology Gliwice, Poland Electromagnetic Engineering Research Team What are we generally interested in? General Research Interests Computational Electromagnetics (CEM) Development and application of numerical modeling techniques and tools for predicting electromagnetic behavior of radiating and scattering structures. Emphasis placed on the so-called “full-wave” methods. Applications mainly in antennas and electromagnetic compatibility.

  9. Silesian University of Technology Gliwice, Poland Electromagnetic Engineering Research Team What methodologies and tools we employ? MoM – Frequency-domain Integral Equation (MPIE) approach combined with Method-of-Moments for non-penetrable conducting objects involving arbitrary combinations of wires and surfaces FDTD – classical Yee/Taflove approach with necessary modifications/improvements for problems involving non- homogeneous structures with lossy dielectrics Asymptotic Techniques – Asymptotic Waveform Evaluation (AWE), High-Frequency techniques (Geometrical Optics (GO), Physical Optics (PO), Geometrical Theory of Diffraction (GTD)

  10. Silesian University of Technology Gliwice, Poland Electromagnetic Engineering Research Team What methodologies and tools we employ? MBPE – Model Based Parameter Estimation Tools – Commercial full-wave 3D electromagnetic simulators from CST, AWR, selected packages from Mentor Graphics, Matlab. Many in-house codes (the team members are fluent in Fortran programming (Lahey Fortran 77, Lahey Fortran 95).

  11. Silesian University of Technology Gliwice, Poland Electromagnetic Engineering Research Team What are we currently involved in? Computationally Efficient Wideband “Fast” Hybrid Techniques MoM-PO – MoM combined with PO, the impedance matrix interpolation in the frequency domain, and adaptive sampling of the observable MoM-FDTD – …

  12. Silesian University of Technology Gliwice, Poland Fast MoM-PO Method MoM-PO – this hybrid formulation implies decomposition of the structure into MoM region and PO region. The MoM region is handled by MoM, and the effects from the secondary sources in PO region are incorporated in boundary conditions for the em field in MoM region (Jakobus, Landstorfer; 1995) MoM-PO impedance matrix interpolation – the impedance matrices [Z] are precomputed (and stored) at several relatively distant nodes and then interpolation is used to find [Z] at in intermediate frequencies (Newman; 1988) Dynamic adaptive sampling of the observable – initially, the observable is computed at three successive uniformly spaced frequency nodes and then the adaptive sampling based upon bisection is used to find the observable value elsewhere

  13. Silesian University of Technology Gliwice, Poland Fast MoM-PO Method Numerical example Helical antenna driven at the base against a corner PEC platform Geometry of the antenna: 5 loops; diameter 5.1 cm, pitch angle 14 o , wire radius 1mm) The entire structure is subdivided into 4056 triangular patches and 83 linear segments Structure decomposition: MoM region – 179 basis functions PO region – 5910 basis functions A. Karwowski, A. Noga. “Fast MM-PO-based numerical modelling technique for wideband analysis of antennas near conducting objects”, Electronics Letters , vol. 43, no. 9, pp. 486-487, Apr. 2007. A. Karwowski, A. Noga,” On the interpolation of the frequency variations of the MoM-PO impedance matrix over a wide bandwidth”, Microwave and Optical Technology Letters , Vol. 58, No. 3, pp. 738-741, March, 2008

  14. Silesian University of Technology Gliwice, Poland Fast MoM-PO Method Numerical example a) b) 7.772 10 9 Vs -1 � � A 2 � � � � 2 � � ( ) g t t � � v t A t t e 0 3.33 10 9 s -1 � � g 0 1.2 10 � 9 s � � t 0 The antenna is excited at the base by a monocycle in the form of the derivative of the Gaussian pulse

  15. Silesian University of Technology Gliwice, Poland Fast MoM-PO Method Numerical example Current magnitude at the antenna driving-point versus frequency

  16. Silesian University of Technology Gliwice, Poland Fast MoM-PO Method Numerical example For matrix interpolation, the frequency nodes were taken at 200 MHz (11 nodes for 100 MHz to 2100 MHz frequency range). Only 3 nodal matrices and currently evaluated [Z] matrix are stored For adaptive current interpolation , an initial frequency step of 20 MHz was taken. The convergence tolerance of 1% was taken. The adaptive algorithm generated 776 non-uniformly spaced current samples with the initial frequency resolution locally refined by a factor of 512 resulting in frequency step of 39.0625 kHz. To meet the convergence criterion with uniform sampling, 51201 samples would be required.

  17. Silesian University of Technology Gliwice, Poland Fast MoM-PO Method Numerical example Computer resources needed to perform computations of the current at the driving-point of the antenna MoM MoM-PO+I+S time required to compute number of basis a single current sample !!! functions MM region 6089 179 PO region -- 5910 RAM 600 MB 35 MB time 113 min 6.5 min The total execution time required to compute 776 + 11 current samples

  18. Silesian University of Technology Gliwice, Poland THANK YOU FOR YOUR ATTENTION

  19. Silesian University of Technology Gliwice, Poland Numerical results Computer resources needed to perform computations of current at driving-point of the helical antenna MM MM-PO+I+S time of computations number of basis of a single sample !!! functions 6089 179 MM region - 5910 PO region RAM 570 MB 35 MB time 113 min 6.5 min Time required to compute 776 samples and 11 interpolation nodes Time of computations of a single sample directly by MM-PO – 32.8s Time of computations of a single sample by MM-PO+I – 0.04s
