PTT 207 Biomolecular and Genetic Engineering Semester 2 2013/2014 BY: PUAN NURUL AIN HARMIZA ABDULLAH Introduction A central event in gene expression is the copying of the sequence of the template strand of a gene into a complementary


  1. PTT 207 Biomolecular and Genetic Engineering Semester 2 2013/2014 BY: PUAN NURUL AIN HARMIZA ABDULLAH

  2. Introduction • A central event in gene expression is the copying of the sequence of the template strand of a gene into a complementary RNA transcript. • The regulatory mechanisms that have been developed by bacteria to control transcription are complex and highly variable.

  3. Mechanism of transcription • RNA polymerase is the enzyme that catalyzes RNA synthesis. • Using DNA as a template, RNA polymerase joins, or “ polymerizes ,” nucleoside triphosphates ( NTPs ) by phosphodiester bonds from 5' to 3'.

  4. • In bacteria, transcription and translation are coupled ―they occur within a single cellular compartment. • As soon as transcription of the mRNA begins, ribosomes attach and initiate protein synthesis . • The whole process occurs within minutes .

  5. Transcription and Translation are coupled in bacteria.

  6. • Minimal requirements for gene transcription. 1. Gene promoter 2. RNA polymerase • Additional factors are required for the regulation of transcription.

  7. 1. Bacterial promoter structure • RNA polymerase binds to a region of DNA called a promoter . • Bacterial promoters are not absolutely conserved but they do have a consensus sequence .

  8. • Conserved sequence: When nucleotide sequences of DNA are aligned with each other, each has exactly the same series of nucleotides in a given region. • Consensus sequence: there is some variation in the sequence but certain nucleotides are present at high frequency .

  9. Bacterial promoters have 2 distinct consensus sequences.

  10. • The σ subunit of prokaryotic RNA polymerase recognizes consensus sequences found in the promoter region upstream of the transcription start sight. • The σ subunit dissociates from the polymerase after transcription has been initiated.

  11. Promoter strength • The relative frequency of transcription initiation . • Related to the affinity of RNA polymerase for the promoter region. • The more closely regions within the promoter resemble the consensus sequences, the greater the strength of the promoter.

  12. 2. Structure of bacterial RNA polymerase • Comprised of a core enzyme plus a transcription factor called the sigma factor (  ) . • Together they form the complete, fully functional enzyme complex called the holoenzyme .

  13. Holoenzyme

  14. The core enzyme • The core enzyme catalyzes polymerization. • High affinity for most DNA. • The sequence, structure, and function are evolutionarily conserved from bacteria to humans. • X-ray crystallographic studies revealed a crab claw-like shape.

  15. Sigma factor • The sigma (  ) factor decreases the nonspecific binding affinity of the core enzyme. • Binding results in closing of the core enzyme “pincers.” • Primarily involved in recognition of gene promoters.

  16. • In E. coli the most abundant  factor is  70 . • For expression of some genes, bacterial cells use alternative  factors.

  17. Initiation of transcription Initiation consists of three stages: 1.Formation of a closed promoter complex. 2.Formation of an open promoter complex. 3.Promoter clearance.

  18. 1. Closed promoter complex • RNA polymerase holoenzyme binds to the promoter at nucleotide positions  35 and  10. • The DNA remains double-stranded. • The complex is reversible.

  19. 2. Open promoter complex • ~18 bp around the transcription start site are melted to expose the template strand DNA. • AT rich promoters require less energy to melt. • Transcription is aided by negative supercoiling of the promoter region of some genes. • The open complex is generally irreversible.

  20. • Transcription is initiated in the presence of NTPs. • No primer is required for initiation by RNA polymerase.

  21. 3. Promoter clearance •  factor does not completely dissociate; some domains are displaced. • The displaced domains allow the nascent RNA to emerge from the RNA exit channel.

  22. Elongation • After about 9-12 nt of RNA have been synthesized, the initiation complex enters the elongation stage. • Transcription bubble - unwinds the strands at the front and rewinds them at the back

  23. • One strand of DNA acts as the template for RNA synthesis by complementary base pairing. • Transcription always proceeds in the 5′→3′ direction.

  24. • The catalytic site of the polymerase has both: • a substrate-binding subsite, at which the incoming NTP is bound to the polymerase and to the complementary nucleotide residue of the template, and • a product-binding subsite , at which the 3’ terminus of the growing RNA chain is positioned (figure).

  25. • Completion of the single nucleotide addition cycle. • Shift of the active site of the RNA polymerase by one position along the template DNA.

  26. Which moves – the RNA polymerase or the DNA? Two models • Model 1: RNA polymerase moves along and the DNA rotates. – This is the more widely accepted model. • Model 2: RNA polymerase remains stationary, and the DNA moves along and rotates.

  27. PROOFREADING 1. Short (~5bp) backtracking motion to upstream. • The movement is directed upstream in the opposite direction to transcriptional elongation (3 ’  5 ’) . • This backward motion carries the 3 ’ end of the nascent RNA transcript away from the enzyme active site.

  28. PROOFREADING 2. Nucleolytic cleavage – cleave and discard the mismatched base by nuclease activity. • Occurs after a variable “pause” of the polymerase. • In its backtracked state, the polymerase is able to cleave off and discard the most recently added base(s) by nuclease activity. • In this process, a new 3 ’ end is generated at the active site, ready for subsequent polymerization onto the nascent RNA chain.

  29. RNA Polymerase Proofreading

  30. TERMINATION  The RNA polymerase core enzyme moves down the DNA until a stop signal/terminator sequence is reached.  There are 2 types of terminators: 1. Rho-dependent  Requires Rho protein to stop the transcription read- through.  Rho = Spider = “trap first, kill later ” Rho-independent – intrinsic terminator 2.  They cause termination of transcription in the absence of any external factors.

  31. Rho-independent

  32. Rho-dependent

  33. The End Thank You
