green, greener, greenest FERRIES Project ms Groenland Henk Grunstra Damen Ferries 2013 green, greener, greenest FERRIES DAMEN E3 Ferry, an Assessment of Sustainable RoPax Ferry Concepts This work is part of the iTransfer project,


  1. green, greener, greenest FERRIES Project “ms Groenland” Henk Grunstra Damen Ferries 2013

  2. green, greener, greenest FERRIES DAMEN E3 Ferry, an Assessment of Sustainable RoPax Ferry Concepts This work is part of the iTransfer project, which is funded by the North Sea Region programme, part of the EU Inter-regional (Interreg) initiative and the European Regional Development Fund

  3. green, greener, greenest DAMEN E3 Philosophy FERRIES Environmentally Friendly PLANET Efficient in Operation PEOPLE PROFIT Economically Viable

  4. green, greener, greenest DAMEN E3 Projects FERRIES LNG Inland Tanker with air-lubrication Hybrid Tug & LNG Tug PSV with aftertreatment and CD notation

  5. green, greener, greenest Targets FERRIES Less Energy = CO2 reduction No SOX No PM Significant NOX reduction

  6. green, greener, greenest FERRIES

  7. green, greener, greenest PRINCIPAL CHARACTERISTICS FERRIES •Promenade deck outside •120 seats •1 Passenger lift and 1 goods lift •Promenade deck inside •181 seats •Evacuation systems •Bar with bar fixed stools •Store space •Grouped passenger sanitary spaces

  8. green, greener, greenest PRINCIPAL CHARACTERISTICS FERRIES •Family lounge / playground •Catering facilities •Life jackets storage space on both sides •Disabled person toilet •Evacuation system •1 Passenger lift and 1 goods lift •Passenger saloon 417 seats •Central staircase •Passenger entrance •Hospital treatment room on saloon deck •Grouped passenger sanitary spaces

  9. green, greener, greenest PRINCIPAL CHARACTERISTICS FERRIES • A-Deck Level Top Deck • B-Deck Level Wheelhouse Deck • C-Deck Level Promenade Deck • D-Deck Level Passenger Saloon Deck • E-Deck Level Mooring Deck • E-Deck Level Mooring Deck • F-Deck Level Main / Car Deck • G-Deck Level Tank Top / Floor Plate Level

  10. green, greener, greenest PRINCIPAL CHARACTERISTICS FERRIES • F-Deck Level Main / Car Deck • Car Deck Height, free/clear: 3.25 m • Passenger Cars Capacity: 60 in 6 lanes

  11. green, greener, greenest Sustainability @ DAMEN FERRIES

  12. green, greener, greenest Method FERRIES

  13. green, greener, greenest Energy consumption FERRIES MS BENCHMARK Energy consumption 40 35 30 25 20 [%] 15 10 5 0

  14. green, greener, greenest Steel MH → Alu MH → Alu CAT FERRIES Power vs. FnL • -15% Power • (-10%) STEEL MH • -40% • (-30%) ALU MH ALU CAT 0,10 0,15 0,20 0,25 0,30 0,35 0,40 FnL [-] • Desired speed

  15. green, greener, greenest PROPULSION CONCEPTS FERRIES Base: Diesel Direct + generator sets Alt. 1 Diesel Direct + SCR + DPF + generator sets Alt. 2 LNG – Electrical propulsion Alt. 3 LNG direct propulsion

  16. green, greener, greenest Energy Consumption Comparison FERRIES Daily Energy Consumption 140% 120% Relative Energy Consumption 100% Diesel Direct 80% Diesel Direct +SCR+DPF LNG Electric 60% LNG Direct 40% 20% 0%

  17. green, greener, greenest LNG Genset vs Diesel Engine Efficiency FERRIES LNG Engine Diesel Engine MTU 16 V2000 M61 MHI GS 12R-PTK Miller 50% 50% 40% 40% Efficiency Efficiency 30% 30% 20% 20% 10% 10% 0% 0% 0% 20% 40% 60% 80% 100% 0% 20% 40% 60% 80% 100% Power Power •No LNG engines available for Gas-Direct at the time of this project (mid. 2012)

  18. green, greener, greenest Emissions comparison FERRIES •Calculated with Emissions Comparison data available 20 mid. 2012. 18 16 14 12 Mass 10 Diesel Direct 8 Diesel Direct + SCR + DPF LNG Electric 6 LNG Direct 4 2 0 NOX SOX PM CO2 CH4 (x10 CO2, eq (x10 kg) (x0.1 kg) (kg) (ton) kg) (ton) Exhaust Gas Component

  19. green, greener, greenest Green features FERRIES • Aluminum Construction • Light weight interior • Catamaran hull form • Heat insulated windows • Waste heat for heating of the vessel and systems (24/7 self sufficient) • Reduced AC capacity • LED lights • Solar panels

  20. green, greener, greenest Fuel cost today FERRIES • MGO EN 590 = (USD 864/ton) = E 0,137/kWh • HFO 380 = (USD 864/ton) = E 0,084/kWh • LNG = (65% of EN 590) = E 0,089/kWh • Aardgas (NL) = E 0,110/kWh • E-shore supply = E 0,062/kWh Notes • Price level may 2013 • Fuel prices vary +/-25% • LNG is linked to cost of MGO in many cases • E-shore supply based on Delta energy NL. • Aardgas based on retail price and quality “Dutch gas”

  21. green, greener, greenest Life Cycle Cost FERRIES •Cost •CAPEX LNG direct •CAPEX LNG elec •CAPEX DD + SCR+ DPF •CAPEX DD Time , i.e. fuel consumption • Three parameters influence the economical feasability: • (1) Add. investment cost LNG system, (2) Price difference LNG and fuel oil, (3) Operational profile of the vessel.

  22. green, greener, greenest Future of energy FERRIES

  23. green, greener, greenest conclusions FERRIES Think big • Fleet management (2 small vessels instead of 1 large) • Reduce energy demand, decrease speed, decrease weight etc. • Total vessel concept • Fuel consumption and cost is key • LNG direct drive

  24. green, greener, greenest conclusions FERRIES A lot of work to be done • LNG equipment needs further development • LNG cost development(s) uncertain • LNG infrastructure slowly developing but forward • Significant gain can be reached with new ferry concepts that integrate shore logistics and water transport • Electric power from shore supply & energy storage • Battery developments including super capacitors • Waste heat energy

  25. green, greener, greenest FERRIES • CONTACT DETAILS: • Damen Shipyards Gorinchem Phone +31 (0) 183 63 99 11 • PO Box 1 Fax +31 (0) 183 63 95 05 • 4200 AA Gorinchem E-mail ferries@damen.nl • The Netherlands Website www.damen.nll
