PGE Salem Smart Power Center Demonstrations and Studies of Utility Scale Energy Storage Kevin Whitener, Project Manager Dispatchable Standby Generation September 22, 2017 Salem Smart Power Center 5 MW Power Capacity 1.25 MWh


  1. PGE Salem Smart Power Center Demonstrations and Studies of Utility Scale Energy Storage Kevin Whitener, Project Manager – Dispatchable Standby Generation September 22, 2017

  2. Salem Smart Power Center • 5 MW Power Capacity • 1.25 MWh Energy Capacity 2

  3. South Salem – Oxford and 22 nd St. SE Portland General Electric 3

  4. 20 Eaton Inverters – 250kW each Portland General Electric 4

  5. 2,440 Li Ion Battery Modules ( ∼ 500Wh each) Portland General Electric 5

  6. How Do We Control It? Three Programmable Logic controllers (PLC’s) • Schneider • Allen Bradley • Cooper Power Systems Dell PC running Archestra provides the HMI Portland General Electric 6

  7. Use Cases • Use cases can be classified as PGE Power being energy System- Local Use Case or use cases or wide Benefits power use Energy Benefits cases  Transactive Node Energy • Use cases  Reliability Power can benefit PGE’s   Solar Integration Both overall system   Demand Response Energy operations  or local Non-Spinning Reserve Energy conditions  Frequency Response Power such as voltage and   Power Factor Control N/A power factor  Voltage Control N/A Portland General Electric 7

  8. Noise on DC Side of Inverter Portland General Electric 8

  9. Typical Solar Day in May Portland General Electric 9

  10. Typical Load Curve in July Portland General Electric 10

  11. Integration of Solar and Load Portland General Electric 11

  12. Volt/VAr Control Portland General Electric 12

  13. Volt/VAr Control – Inner Loop Portland General Electric 13

  14. Volt/VAr Control – Outer Loop Portland General Electric 14

  15. Frequency Response Portland General Electric 15

  16. Portland General Electric 16
