Optical Spectrum Services OSA ADVA FSP 3000 31 January 2012 Robust design and superior coverage, backed by experts Openreach makes every effort to ensure the information in this report is accurate at the time of compilation, however, Openreach does not represent that it is complete and Communications Providers should check with Openreach for the latest available information. Openreach reserves the right to modify delivery criteria and delivery dates.

The OSA FSP 3000 is supplied in association with ADVA Optical Networking About ADVA ADVA Optical Networking equipment provides Openreach with unparalleled flexibility in multiplexing, transporting and protecting high-speed data, storage and video applications. It has a long established working relationship with the BT Group and Openreach in particular, and continues to develop joint solutions to address the future market needs around high-speed Ethernet, cloud, storage and infrastructure services. www.advaoptical.com

ADVA FSP 3000 - Overview  Enhanced optical terminating equipment from ADVA Optical Networking  Supersedes the ADVA FSP 2000  Attractive entry level prices  Commercial & technical flexibility (via Slimline 1U & 7U chassis)  Route distance range - up to 100km available  Significant space and power savings  Wide range of flexible options for design  Additional resilience capability for RO1 circuits  Improved management and availability of technical data for customers. System latency Lead times Initial view available targeted at 35 at pre design stage working days with actuals upon for forecast orders installation

ADVA FSP 3000 - chassis A fully featured, high capacity chassis, with slimline (1U) and 7U options which provides the flexibility to meet an extensive range of needs at a great price. Slimline 1U chassis  1U has a double card slot capability. This can run either without filters (max 1 wavelength) or with an additional 1U passive filter shelf (max 4 wavelengths)  Standard and RO2 bearer options  Ideal to deliver higher volumes of 1Gig services Standard 7U chassis  Chassis capacity - 12 channels, less if double-width transponders or RO1 used. Bearer will have capacity for 32 optical channels, in most cases this will require 3 chassis, but could be more if double-width cards are used  Standard, RO1* and RO2 bearer options Future FSP 3000 developments – mid point amps, and rings &  chains * RO1 uses a protection module known as the VSM card. This will protect against fibre breaks only and will use one wavelength on the bearer, leaving 31 for customer use.

ADVA FSP 3000 New slim line 1U chassis Single (1 slot) – with RO2 option  1U chassis offers a choice of configurations and a low entry price  1U high chassis for a single wavelength (all card product to meet light initial types) requirements.  Compact service option  Can be upgraded by adding expansion  Uses less space in the exchange  filters and chassis. and provides an ideal solution where Standard (2 slots) – with RO2 option there is limited space to terminate an Optical service.  Enables the build of a mini Optical system to cater for up to four wavelengths  The single (1 slot) option allows you  Can be grown by adding extra modules. to start small with lower risk.  Choosing an additional filter pack (standard option) will enable you to grow capacity easily (up to 4 1U wavelengths) and at your own pace. chassis 2 slots Passive shelf required for filters

ADVA FSP 3000 7U high chassis option A fully featured, high capacity chassis which provides the flexibility to meet an extensive range of needs at a great price.  16 slots available for all card types including transponders, filters, protection cards and optical supervisory cards  12 channel chassis capacity (less if double-width transponders or RO1 used)  32 optical channel** bearer capacity (in most cases this will require 3 chassis, more if double-width cards are used)  Resilient options RO1 and RO2.

ADVA FSP 3000 v FSP 2000 FSP 2000 features NEW FSP 3000 features Approx. 51-55 km max radial distance. 103km 35 km radial distance route distance 57 days lead time 35 days lead time (for forecast orders) 5U chassis Choice of 1U and 7U chassis Chassis Capacity – 12 channels, less if double- Chassis capacity - slot capacity for 8 single-width width transponders or RO1 used. Bearer has transponders. To support 32 optical channels, 4 capacity for 32 optical channels, in most cases chassis are required this will require 3 chassis, but could be more if double-width cards are used. 2.5Gb, 4Gb or 10Gb or a combination of both on 2.5Gb or 10Gb or a combination of both on each each bearer, depending on fibre characteristics bearer, depending on fibre characteristics and the and the overall distance between the sites to be overall distance between the sites to be connected connected Resilience Options 1 and 2 (RO1 and RO2) Resilience Options 1 and 2 (RO1 and RO2) available on unamplified section of circuit available over full length of circuit Full Enterprise Certification (Brocade, HP , IBM, Fujitsu, Hitachi, EMC2, NEC and Juniper Networks) Five hour guaranteed repair time Proactively monitored with optional fibre and wavelength protection Subject to design considerations, existing wavelengths can be easily upgraded and interfaces can be changed to keep up with changing customer demands Low latency Secure un-contended bandwidth A choice of 1, 3 or 5 year minimum periods

Distance support The FSP 3000 provides increased distance support by means of end point optical amplifiers. Distances of up to 103km route (approx 50-55km radial) will be supported. It has been agreed that planning rules will be introduced so that 4Gig cards can be deployed with a shorter reach. 2.5Gb & 10Gb Enterprise & 4Gb Core Cards 10Gb 10Gb Access Cards 5 Port D09534 Access Card Core Card Service offering 4 Port D09529 10 Port D09532 Dual Port D09533 Dual Port D09531 4 Port D09530 Single Port D09526 (km) (km) (km) Single Port D09527 Dual Port D09528 (km) OSA RO1 with booster + 50 64 71 100 pre-amp OSA standard & RO2 with 66 72 76 103 booster + pre-amp

ADVA FSP 3000 – card options Card D-code Bandwidth Protocols options Single port D09527 2.5Gb STM16, STM-4, STM-1, OTU1 cards D09526 10Gb STM64, 10GbE WAN, 10GbE LAN and 10G FC, OTU2 Multi-port cards 4 port (Data) D09529 4Gb GEx4, 1Gb FCx4, 2Gb FCx2, 4Gb FC, 2G Coupling Link 4 port (TDM) D09530 4Gb STM1x4, STM4x4, 1GEx4 10 port D09532 10Gb GEx9, 1Gb FCx10, 2Gb FCx5, 4Gb FCx2, STM1x10, STM4x10, STM16x3 2 port D09528 2.5Gb STM16, 1GFCx2 GbEx2, OTU1 2 port D09531 10Gb STM64, 10GbE WAN, 10GbE LAN, 4Gb FC 8Gb FC, OTU2 (10GFC not supported) 2 port D09533 10Gb STM64, 10GbE WAN, 10GbE LAN, 4Gb FC, 8GFC, OTU2 (10GFC not supported) *Low latency card* 5 port D09534 Max 10Gb 1Gb/2Gb/4Gb/8Gb/10Gb FC, GE, 10GE (LAN PHY only)

A quality service from a credible supplier   True resilience – our resilient paths Experts backed by experts - solutions use dedicated fibre too , so you’ll never designed by highly qualified teams and supported by our equipment vendors, have to compromise should the worst ensure they are the very best that can happen be provided  Range of service interfaces – to  Your promises are our promises – meet any customer requirement circuits that are installed on time, every time so you can keep your promises to  UK wide coverage – expand to new your customers sites later without the worry of being off net, incurring extra charges or  Dedicated fibre – avoid the hidden risks finding you can’t of a shared infrastructure and get exactly what you pay for with full control  Choice of minimum period options - on additional bandwidth/wavelength one, three or five years. requirements

Our commitment to you We will We will make sure you We will always make sure we understand the We know that make sure we offer you the solution we are one size does understand solution that offering and not fit all what you best meets we’ll help you need your individual brief your needs colleagues We reserve fibre We will show The delivery capacity for you you how date is our when we quote, what we are promise to you so that you know – we’ll even try offering helps its available you save or to beat it and when you place make money often we do an order

Expert advice that really counts To ensure your optical network investments work as hard for you as possible we’ll help you:  Make choices that meet your longer term requirements  Avoid solutions that will restrict your ability to expand  See through solutions that are cheap at first, but force you to invest again later Understand exactly what you’ll be risking if you choose a shared infrastructure.  If you’re new to Optical solutions, or need our advice, we’ll help you understand:  When it makes sense to switch from multiple circuits  How to add optical circuits to improve business continuity in your existing network  How optical solutions can help you save thousands of pounds on space and power.
