Opportunistic Routing in Multi-hop Wireless Networks Sanjit Biswas - PowerPoint PPT Presentation

Opportunistic Routing in Multi-hop Wireless Networks Sanjit Biswas and Robert Morris MIT CSAIL http://pdos.csail.mit.edu/roofnet/ ExOR: a new approach to routing in multi-hop wireless networks 1 kilometer Dense 802.11-based mesh


  1. Opportunistic Routing in Multi-hop Wireless Networks Sanjit Biswas and Robert Morris MIT CSAIL http://pdos.csail.mit.edu/roofnet/

  2. ExOR: a new approach to routing in multi-hop wireless networks 1 kilometer • Dense 802.11-based mesh • Goal is high-throughput and capacity

  3. Initial approach: Traditional routing packet packet A A B B A A B B src src src src dst dst dst dst packet C C C C • Identify a route, forward over links • Abstract radio to look like a wired link

  4. Radios aren’t wires A A B B A A B B src src src src dst dst dst dst 1 2 1 2 3 4 5 6 1 2 3 2 3 4 56 3 5 4 5 6 4 6 1 C C C C • Every packet is broadcast • Reception is probabilistic

  5. ExOR: exploiting probabilistic broadcast packet packet packet packet A A B B A A B B src src src src dst dst dst dst packet packet packet packet packet C C C C • Decide who forwards after reception • Goal: only closest receiver should forward • Challenge: agree efficiently and avoid duplicate transmissions

  6. Outline • Introduction • Why ExOR might increase throughput • ExOR protocol • Measurements • Related Work

  7. Why ExOR might increase throughput (1) src N1 N2 N3 N4 N5 dst 75% 50% 25% Best traditional route over 50% hops: 3( 1 / 0.5 ) = 6 tx • Throughput ≅ 1 / # transmissions • • ExOR exploits lucky long receptions: 4 transmissions • Assumes probability falls off gradually with distance

  8. Why ExOR might increase throughput (2) N1 % 100% 5 2 N2 % 100% 5 2 src dst 100% 25% N3 100% 25% N4 • Traditional routing: 1 / 0.25 + 1 = 5 tx • ExOR: 1 / (1 – (1 – 0.25) 4 ) + 1 = 2.5 transmissions • Assumes independent losses

  9. Outline • Introduction • Why ExOR might increase throughput • ExOR protocol • Measurements • Related Work

  10. ExOR batching rx: 40 rx: 0 rx: 57 rx: 85 tx: 0 N2 N4 tx: ≅ 9 tx: 100 tx: 57 -23 rx: 22 rx: 0 ≅ 24 src dst rx: 99 rx: 88 rx: 23 rx: 53 N1 N3 tx: ≅ 8 tx: 23 • Challenge: finding the closest node to have rx’d • Send batches of packets for efficiency • Node closest to the dst sends first – Other nodes listen, send remaining packets in turn • Repeat schedule until dst has whole batch

  11. Reliable summaries tx: {2, 4, 10 ... 97, 98} summary: {1,2,6, ... 97, 98, 99} N2 N4 src dst N1 N3 tx: {1, 6, 7 ... 91, 96, 99} summary: {1, 6, 7 ... 91, 96, 99} • Repeat summaries in every data packet • Cumulative: what all previous nodes rx’d • This is a gossip mechanism for summaries

  12. Priority ordering N2 N4 src dst N1 N3 • Goal: nodes “closest” to the destination send first • Sort by ETX metric to dst – Nodes periodically flood ETX “link state” measurements – Path ETX is weighted shortest path (Dijkstra’s algorithm) • Source sorts, includes list in ExOR header • Details in the paper

  13. Using ExOR with TCP Web Server TCP TCP TCP TCP TCP TCP Client PC TCP TCP Node Gateway Proxy ExOR Batches (not TCP) ExOR Batches (not TCP) ExOR ExOR Batches (not TCP) Batches (not TCP) Web Proxy ExOR ExOR ExOR ExOR • Batching requires more packets than typical TCP window

  14. Outline • Introduction • Why ExOR might increase throughput • ExOR protocol • Measurements • Related Work

  15. ExOR Evaluation • Does ExOR increase throughput? • When/why does it work well?

  16. 65 Roofnet node pairs 1 kilometer

  17. Evaluation Details • 65 Node pairs • 1.0MByte file transfer • 1 Mbit/s 802.11 bit rate • 1 KByte packets Traditional Routing ExOR 802.11 unicast with link-level 802.11 broadcasts retransmissions 100 packet batch size Hop-by-hop batching UDP, sending as MAC allows

  18. ExOR: 2x overall improvement 1.0 Cumulative Fraction of Node Pairs 0.8 0.6 0.4 0.2 ExOR Traditional 0 0 200 400 600 800 Throughput (Kbits/sec) • Median throughputs: 240 Kbits/sec for ExOR, 121 Kbits/sec for Traditional

  19. 25 Highest throughput pairs 3 Traditional Hops 3 Traditional Hops 3 Traditional Hops 3 Traditional Hops 2 Traditional Hops 2 Traditional Hops 2 Traditional Hops 2 Traditional Hops 1 Traditional Hop 1 Traditional Hop 1 Traditional Hop 1 Traditional Hop 2.3x 2.3x 2.3x 2.3x 1.7x 1.7x 1.7x 1.7x 1.14x 1.14x 1.14x 1.14x 1000 ExOR Throughput (Kbits/sec) Traditional Routing 800 600 400 200 0 Node Pair

  20. 25 Lowest throughput pairs 1000 ExOR 4 Traditional Hops 4 Traditional Hops 4 Traditional Hops 4 Traditional Hops Throughput (Kbits/sec) Traditional Routing 800 3.3x 3.3x 3.3x 3.3x 600 400 200 0 Node Pair Longer Routes Longer Routes Longer Routes Longer Routes

  21. ExOR uses links in parallel Traditional Routing ExOR 3 forwarders 7 forwarders 4 links 18 links

  22. ExOR moves packets farther 58% of Traditional Routing transmissions 58% of Traditional Routing transmissions 58% of Traditional Routing transmissions 58% of Traditional Routing transmissions Fraction of Transmissions 0.6 ExOR Traditional Routing 0.2 25% of ExOR 25% of 25% of 25% of ExOR transmissions ExOR ExOR transmissions transmissions transmissions 0.1 0 0 100 200 300 400 500 600 700 800 900 1000 Distance (meters) • ExOR average: 422 meters/transmission • Traditional Routing average: 205 meters/tx

  23. Future Work • Choosing the best 802.11 bit-rate • Cooperation between simultaneous flows • Coding/combining

  24. Related work • Relay channels [Van der Meulen][Laneman+Wornell] • Flooding in meshes / sensor nets [Peng][Levis] • Multi-path routing [Ganesan][Haas] • Selection Diversity [Miu][Roy Chowdhury][Knightly][Zorzi]

  25. Summary • ExOR achieves 2x throughput improvement • ExOR implemented on Roofnet • Exploits radio properties, instead of hiding them

  26. Thanks! For more information and source code: http://pdos.csail.mit.edu/roofnet/
