November 2, 2009 Wii Remote Power Requirements Indoor Positioning - PowerPoint PPT Presentation

November 2, 2009 Wii Remote Power Requirements Indoor Positioning System Tasks for this week Hard to find source code or MicroCART program which gives raw Wii Weekly Meeting data for testing purposes. Agenda Wii connects


  1. November 2, 2009

  2.  Wii Remote  Power Requirements  Indoor Positioning System  Tasks for this week

  3.  Hard to find source code or MicroCART program which gives raw Wii Weekly Meeting data for testing purposes. Agenda  Wii connects to computers in Lab 2018 currently, and this  Wii Remote lab has many remotes which  Power Requirements can be used for testing as well  Indoor Positioning Systems as charging stations.  Tasks for this week  Our Wii remote has been successfully disassembled this week  Net weight without case=22g  Need to find a way to incorporate IR pass filter into mechanical design.

  4.  Helicopter MicroCART  Requires 7.4VDC  Motors are easily the largest Weekly Meeting current draw out of the onboard components Agenda  Wiimote  Wii Remote  Requires 3VDC max  Normally takes 2 AA batteries  Power Requirements  Each AA supplies 1.5V with capacity of 2700 mAh  Indoor Positioning Systems  2AA in series provide 3V with capacity of 5400 mAh  Tasks for this week  Wiimote will last around 25 hours using both the accelerometer and IR sensor  5400 mAh/25 h = 216 mA average current  Voltage divider will therefore need a power rating of (7.4V- 3V)*0.216A = 0.95 W

  5.  Innovision Tracking Systems MicroCART  MaxTRAQ Weekly Meeting  Basic 3D System  Either 60 Hz or 120 Hz Agenda  $5000 to $5500  Wii Remote  MaxPRO  Power Requirements  Upgraded Motion Capture Software  Indoor Positioning  Can reach 250 Hz Systems  $9000 - $28000  Tasks for this week  WorldViz PPT Links  Very Precise and Fast  http://www.innovision-  Has option of additional systems.com/Products/Systems.ht sensors that measure roll ml  http://www.worldviz.com/prod pitch and yaw ucts/ppt/pptx.html  $10000 - $30000

  6.  Mike MicroCART  Review and edit testing Weekly Meeting documents for the Wii remote as needed Agenda  Begin testing Wii remote  Wii Remote  Kollin  Power Requirements  ??  Indoor Positioning Systems  Matt  Tasks for this week  Review and edit testing documents for the Wii remote as needed  Begin testing Wii remote  Alex  ??
