Miniature & micro rechargeable Li-ion cells and batteries made in Switzerland Speaker: Marcel Inauen Head of Development

Confidential, no rights for distribution Content of this presentation ▪ Who is Wyon ? ▪ What makes us unique today ? ▪ What can we offer ?

Confidential, no rights for distribution Company | Technology | Products| Summary Who is Wyon ? ▪ Founding in 1999 by the Wyser family (family owned company) ▪ In Appenzell, Switzerland ▪ 110+ employees (30% in R & D) ▪ We develop and manufacture miniature and micro Li-Ion cells and batteries ▪ Over 2 Mio. batteries sold in the medical device field

Confidential, no rights for distribution Company | Technology | Products| Summary Further growth ▪ New building under construction ▪ Double of available space (old 2000 m 2 new 4000 m 2 ) ▪ Move in end of 2017

Confidential, no rights for distribution Company | Technology | Products| Summary R&D capabilities High in house analytical and testing capabilities Own mechanical and prototype toolshop Short development time

Confidential, no rights for distribution Company | Technology | Products| Summary Manufacturing environment ▪ Production volume per cell type starting at 10k up to over 1 million units per year ▪ Full traceability per cell (medical field requirement) ▪ ISO class 7 clean room environment ▪ Production process inside glove boxes (no humidity) ▪ ISO 9001 certified, we develop and manufacture according to ISO 13485

Confidential, no rights for distribution Company | Technology | Products| Summary Certification & approvals • Performance: Capacity / resistance / cycle life / shelf life • Reliability: Ingress protection / drop / chemical resistance / pull force • Safety: IEC 62133 / UN DOT 38.3 • FDA: Approved together with device

Confidential, no rights for distribution Company | Technology| Products| Summary What makes us unique today ? 1. Plastic technology 2. Stack technology 3. Micro technology

Confidential, no rights for distribution Company | Technology| Products| Summary Plastic technology – Basics ▪ Only company in the world using just plastic casing for Li-ion cells ▪ Best customized shape possibilities in the market ▪ Maximum capacity for miniature cells (the smaller the more advantages the Wyon technology has) ▪ Biocompatible (direct contact to skin) ▪ Light weight ▪ No voltage potential on case ▪ Hermetically sealed

Confidential, no rights for distribution Company | Technology| Products| Summary Plastic technology – Benefit: High energy density ▪ Optimized to costumer design or available space ▪ Higher Capacity compared to standard button cell (max. volume used) Loosing space (energy) because of double housing and circular shape: standard button cell optimized Wyon cell

Confidential, no rights for distribution Company | Technology| Products| Summary Stack technology – Basics ▪ Flexible shape possibilities (curved, triangular, ring, etc.) ▪ High capacity achievable (use of free space) ▪ Small housing heights are possible ▪ High reliability and high security (precise alignment of anode/cathode)

Confidential, no rights for distribution Company | Technology| Products| Summary Stack technology – Benefit: High service life Cycle behaviour @ C/2; 100% DoD; RT 120 100 2k Cycle 90% initial C 80 % initial capacity 60 40 20 0 0 500 1000 1500 2000 2500 3000 3500 4000 4500 5000 cycles Test done with Wyon B01 battery

Confidential, no rights for distribution Company | Technology| Products| Summary Micro technology – Customized micro cell ▪ Implantable rechargeable Li-Ion battery for micro implants (under development – well functioning samples are available) 2mm Specification Chemical System LCO/Graphite Voltage Range 4.2 – 3.0 V Rated dis. capacity @ 0.5 C Rate 160 µAh Nominal Voltage 3.7 V Cell design stacked electrodes Weight 0.016 g Case material Titanium Size Ø 2 mm, height 2 mm

Confidential, no rights for distribution Company | Technology| Products| Summary Micro technology – Challenges ▪ Feedthrough ▪ Electrode preparation (cutting, welding) ▪ Separator preparation (cutting, welding) ▪ Reliability and security (precise alignment of anode/cathode) ▪ Stacking process ▪ Electrolyte filling ▪ Sealing ▪ Electrical contact ▪ Cycle life ▪ Deep Discharge Capability

Confidential, no rights for distribution Company | Technology| Products| Summary What can we offer ? 1. Customized rechargeable Li-Ion cells/batteries - miniature - micro 2. Off the shelf rechargeable Li-Ion cells - miniature 3. Services - charger solutions ─ wired and wireless

Confidential, no rights for distribution Company | Technology| Products| Summary Customized – Range Max. charge Max. discharge Chemical System Voltage Capacity Cycle Life Ri [DC] current current >2 ’ 000 0.3 – 5 Ohm LCO/Graphite 4.2 – 3.0 100 μAh – 1 Ah 1C 2C (@ 100% DOD & RT) (depending on C) discharge charge temperature Housing Size Shapes Safety testing Quality temperature 10° to 45° 0° to 50°C Plastic smallest possible desirable UN / IEC approved ISO9001

Confidential, no rights for distribution Company | Technology| Products| Summary Customized – The key points ▪ Cell operating life can be the same as operating life of end device ▪ Cell/battery could be included in device ▪ Fully adapted to customer wish regarding shape, enclosure, contacting, etc. ▪ Protection can be included ▪ Maximum capacity ▪ Traceability per cell ▪ Production possible from 10 ’ 000 up to over 1 million cells/batteries per year

Confidential, no rights for distribution Company | Technology| Products| Summary Customized – Development steps Indicative figures : TIME * 1 Design study 2 weeks or more 2 Feasibility study (including functional samples) 15 weeks or more 3 Development project (ready for production) 30 weeks or more 1. Development 2. Tooling 3. Safety tests (UN, IEC) * Terms depend on complexity

Confidential, no rights for distribution Company | Technology| Products| Summary Off the shelf – Range Specification Chemical System LCO/Graphite LCO/Graphite Voltage Range 4.2 – 3.0 V 4.2 – 3.0 V Rated dis. capacity @ 0.5 C Rate 18 mAh 37 mAh Nominal Voltage 3.7 V 3.7 V Cell design stacked electrodes stacked electrodes Weight 0.5 g 0.9 g Case material plastic plastic Size 9.9 mm x 6.5 mm x 4.0 mm Ø 9.1 mm, height 5.4 mm Volumetric capacity 332 Wh/l 369 Wh/l

Confidential, no rights for distribution Company | Technology| Products| Summary Off the shelf – The key points ▪ Cell operating life can be the same as operating life of end device (no battery replacements needed) ▪ Maximum capacity for miniature cells ▪ no potential on case ▪ Direct mounting in device (no additional housing, gain of space) ▪ Traceability per cell ▪ High volume production possible (fully automated) ▪ Samples are available

Confidential, no rights for distribution Company | Technology| Products| Summary Potential markets Medtec Industrial electronics Consumer electronics Telecommunication Automotive Internet of things Aerospace Veterinary medicine

Confidential, no rights for distribution Company | Technology| Products| Summary Summary ✓ Great knowledge Wyon has many years of experience ✓ Innovation power Unique technologies (plastic, stack, micro) ✓ Various shapes Maximum volume can be used – maximum capacity ✓ Design possibilities Battery can become integral part of the product design ✓ Less prone to error No spring contacts needed ✓ More convenience Good cycle behavior – high service life ✓ Miniaturization New possibilities for innovative products ✓ Economics Short development time, marketable unit prices

Confidential, no rights for distribution Contact information Thank you for your attention Wyon swiss batteries Sägehüslistrasse 15 9050 Appenzell Steinegg Get in touch with : marcel.inauen@wyon.ch www.wyon.ch Tel. +41 71 787 56 85
