Location Key Facts Core Business Design and manufacture management of heavy machined steel structures and components for steel mill industry. Sales up to 40 MLN Staff 190 person Area of shops 35.000 m (covered),


  1. Location

  2. Key Facts • Core Business Design and manufacture management of heavy machined steel structures and components for steel mill industry. • Sales up to 40 MLN € • Staff 190 person • Area of shops 35.000 m² (covered), Tot. Over 80.000 m² • Max. lifting capacty up to 100 tons / pieces • Max hight 10 mt under the crane hook • Weld Thickness up to 450 mm

  3. PARTNERS and RESPONSABILITIES Fiscal Offices: Milan Plant Offices: Buia Employees: 70 person Departmens: Design; Ndt; Production Pwht; managment; Sandblasting Cutting; Painting Welding; Assembly Board: 80% Pelfa Board: 100% Pelfa Fiscal Offices: Brescia Fiscal and Plant Offices: Cuneo plant Offices: Buja Employees: 40 person Employees: 40 person Departmens: Cutting Departmens: Machining Welding Dimensional inspection Machining Sandblasting Painting Assembly

  4. PELFA GROUP - Organization Chart BOARD Fabbro Redento (P) Fabbro Daniele Safety & Accident Quality Prevention Forgiarini Andrea Control Bertino Alessandro Fabbro Indira Purchasing Commercial Project Administration Department Department Management Offices PRODUCTION • CUTTING • PWHT • ASSEMBLY • BENDING • MACHINING • WELDING • DIMENSIONAL INSPECTION • NDT

  5. AERIAL VIEW OF PELFA GROUP SRL assembly & light machining heavy machining testing forming & welding gas cutting

  6. AERIAL VIEW OF CSP SRL

  7. Our Experience since more than 35 years • Design and manufacture new plant or equipment • Revamping/Modernisation of an Existing Plants • Supply parts and components in small or large quantities on turn-key basis • Components and Spare Parts • Training and Consulting Services EQUIPMENT FOR ROLLING MILL: MELT SHOP: CONTINUOUS CASTING: • Scrap bucket • Ladle turret and components • Kick In / Kick Off • Tilt frame • Moulds • Reheating furnace – Walkinghearts Furnace • EAF Furnace • Tundish – Walking beam Furnace – Upper sheel • Ingot mould • Rolling mill – Lower sheel • Oscillating work bench – Cooling pannel (copper and steel) • Convertable rolling mill stands • Casting segments – Elbow and roof • Roughing stands • Segments with special rollers • Roof lifting system • Cooling beds • Straightener units • Electrode arm, holder and column • Component and spare parts • Roller way • Oxygen lance SECONDARY METALLURGY: • Cooling beds • Steel ladles up to 150 Ton • Billet transfer • Vacuum tank and cover • Ladle cars • Casting cladded rolls • Vacuum cover lifting system • Shears • VD/VOD cover transfer car CRANE • Component and spare parts • Oxygen lance • Gantry cranes • Water cooling system • EOT cranes • Platforms • Teeming cranes HYDRO PLANTS • Ladle Furnaces • Hydro plant and equipment • Hydraulic and electric control system FORGING • AOD • Design and supply complete plant • Component and spare parts • Parts for presses and manipulator

  8. GAS CUTTING: 3.500 m 2 AREA Cutting equipment GAS: Max. cutting thickness 450 mm • 100% Material traceability PLASMA: Max. cutting thickness 20 mm • Material certificate 3.1 or 3.2 • Stock of plate for quick job startup (Ex: S355J2 from Thk. 5 to 200mm, S460ML, S690QL) • 100% Qualified supplyer • Materials puarchased directly from rolling mills.

  9. BENDING and SAWING MACHINE AREA Press equipment Bending equipment (MG Callender) • Up to 1000 Tons • *Range of plate Thk: 5mm ÷ 150mm • *Max. Whide: 3100mm • *Max. Hight Diameter: 6mt (*: bending radius depend of measure W, L, Thk) Sawing equipment (Mep) • Max. Plate Whide: 300mm • Max. Diameter: 300mm

  10. Quality system according: WELDING: 5.000 m 2 AREA EN 1090-2 (EXC4), UNI EN ISO 3834-2, EN 15085 CL.1 Procedure Welders NDT • Welding Procedure • Qualified personnel • Personnel Qualified EN473 Specification according EN 287-1 – Level. 2 and SNTC • EN ISO 15614-1 • VT – Level 2 (MIG/MAG, TIG, SAW) • LP – Level 2 • MT – Level 2 Equipment • UT – Level 2 • More than 50 Welding • RX – Level 2 machine • All calibrated equipment • 3 Submerged Arc • All calibrated welding equipment Spiral case under tack weld Consumables • Welding wire Certified 3.1 CE Overlay Welding Bottom part of furnace

  11. Heavy machining: VERTICAL LATHE » Ø MAX: 8000 mm » MAX. HIGHEST: 4000 mm » AXIS RANGE: X1 - X2: 6500 Z1 - Z2: 2000 » CROSS BEAM W1a – W2b: 3000 » PLATEAU Ø 6300 CNC: SIEMENS 840D SPINDLE SPEED: 0 - 50 TILTING HEAD AXIS A + B CU1: CHANGING TOOL “TURNING” 6 pos. CU2: CHANGING TOOL “MILLING” 16 pos. MAX. WEIGH ACCEPTED 150 TON 13

  12. Heavy machining: GANTRY ZAYER Main measure: ZAYER Gantry milling machine 3 axis 16000 x 4500 x h4000 ZAYER Gantry milling machine 5 axis 1500 x 1000 x h800 CNC boring machine 16000 x 3500 x h1700 CNC boring machine 8000 x 2000 x h1500 CNC horizontal lathe D 1800 x 12000 CNC horizontal lathe D 1800 x 12500 CNC horizontal lathe D 600 x 6000 CNC vertical lathe D 8000 x h4000 CNC vertical lathe D 2600 x h1600

  13. Heat treatment Oven Technical Specification: Charge dimension: 9x9x6 Mt Max capacity: 100 Ton Heating rate: 0÷160°C/h programmable Cooling rate: 0÷80°C/h programmable

  14. Our main references

  15. Our Quality certification UNI EN ISO 9001:2008 EN 1090-2 – Class EXC 4 UNI EN ISO 3834-2 EN 15085 – Class 1 UNI EN ISO 9001:2008 EN 1090-2 UNI EN ISO 3834-2 EN 15085 – Cl. 1
