KITE PRESENTATION Kite Research Research Most Common Designs Most - PowerPoint PPT Presentation

Team 2: Zachary Stewart, Brian Moore, Noah Hanahan, Becca Poling KITE PRESENTATION Kite Research Research Most Common Designs Most Important: Application, Altitude, Stability Least Important: Aesthetics Brainstorming Ideas


  1. Team 2: Zachary Stewart, Brian Moore, Noah Hanahan, Becca Poling KITE PRESENTATION

  2. Kite Research  Research Most Common Designs  Most Important: Application, Altitude, Stability  Least Important: Aesthetics

  3. Brainstorming Ideas Application or Task: Successfully fly with one or more signal lights attached. Desired Objectives Use for a Task Suitable for Task Helps Manage Resources Tecnology Feasible Possible Cost Safety Weight Factors Use for a Task 0 1 0 1 1 3 0.214285714 Suitable for Task 1 1 0 0 1 2 0.142857143 Helps Manage Resources 0 0 0 0 0 0 0 Tecnology Feasible 1 1 1 1 1 5 0.357142857 Possible Cost 0 1 1 0 1 3 0.214285714 Safety 0 0 1 0 0 1 0.071428571 Comparison/Criteria Weight Factors Box Delta Sled Parachute Use for Task 0.214285714 1.285714286 1.285714286 1.285714286 1.285714286 Suitable for Task 0.142857143 0.714285714 0.428571429 0.571428571 0.857142857 Helps Manage Resources 0 0 0 0 0 Technology Feasible 0.357142857 1.071428571 0.714285714 1.785714286 1.428571429 Possible Cost 0.214285714 0.428571429 0.75 1.071428571 1.071428571 Safety 0.071428571 0.285714286 0.357142857 0.285714286 0.428571429 Total 1 3.785714286 3.535714286 5 5.071428571 Task: flashlight signal Final Concept: Parachute

  4. Prototype Phase  Paper prototype was not sufficient  Not very stable

  5. Final Product  Plans A-E were not sufficient  We decided a different idea…

  6. Flying and Testing  When flying, the kite was successful at times.  However, the kite still lacked stability  Ran line to add stability

  7. Final Remarks  Pros of Design: Flew, Accomplished Task of Signal  Cons: Would have liked to have more stability  Block Flow-  http://www.personal.psu.edu/zts5064/Zachar y/teamwebsite.htm
