Kirtland Air Force Base Fuel Leak Cleanup Presenters: Kathryn - PowerPoint PPT Presentation

Kirtland Air Force Base Fuel Leak Cleanup Presenters: Kathryn Lynnes, Air Force Dennis McQuillan, NMED Bulk Fuels Facility Update October 17, 2018 Middle Rio Grande Basin Jemez Mts. Alluvial Fan Ancestral Rio Grande Sediments Santa Fe


  1. Kirtland Air Force Base Fuel Leak Cleanup Presenters: Kathryn Lynnes, Air Force Dennis McQuillan, NMED Bulk Fuels Facility Update October 17, 2018

  2. Middle Rio Grande Basin Jemez Mts. Alluvial Fan Ancestral Rio Grande Sediments Santa Fe Gp., undivided Xsec from Connell, 2006

  3. Site Geology Alluvial Fan Interbedded Coarse and Finer Grained Sediments Anisotropy – Physical Properties Vary with Direction Ancestral Rio Grande Sediments Water Table Outcrop of sediment similar to what is at fuel spill site 3

  4. Cross Section ~ West-East Along Gibson Alluvial Fan Sediments Ancestral Rio Grande Sediments EDB 4

  5. Rio Grande Braided Stream Channel Belt Rio Grande Braided Stream Shallow EDB Plume In Albuquerque South Valley Paleo Active Channel Belt Channel Belt 5

  6. Conceptual Site Model • Define effect of water table fluctuations on locations and amounts of residual LNAPL • Identify natural degradation processes and potential opportunities for enhancement through engineered cleanup technologies Residual LNAPL Hydrocarbon oxidation in soil and groundwater Conceptual Site Model Before Interim Corrective Measures Reductive debromination of EDB comingled with EDB hydrolysis hydrocarbons 6

  7. EDB Plume Over Time 7

  8. EDB Plume Over Time 8

  9. EDB Plume Over Time 9

  10. EDB Plume Over Time • Diagram at top illustrates EDB plume thickness • Beginning to see evidence of plume collapse • Pumped approximately 500 million gallons as of October 2018 • Treated effluent is non-detect for all fuel constituents 10

  11. Response to Water Level Rise • 6 new monitoring well locations • First effort focused on new monitoring wells to fill data gaps that resulted from unexpected rapid rise in water table in first half of 2017 11

  12. Response to Water Table Rise • 8 soil cores to be drilled to determine extent of On-base Randolph Road remaining LNAPL in the source area • 1 background location • 3 optional locations that may be drilled pending results of other cores • 5 drilled boreholes will be completed as groundwater monitoring wells and 2 boreholes will be completed for soil vapor monitoring 12

  13. Groundwater Treatment System 13

  14. MORE THAN JUST GROUNDWATER Pilot Test Community TREATMENT Implementation Outreach GWTS Expansion Monitoring Program 14

  15. How do I get more information? Contact NMED: Communications (505) 827-0314 Katy.Dougherty- Katy Diffendorfer Lead Diff@state.nm.us (505) 827-2140 Dennis.mcquillan@state.nm Dennis McQuillan Chief Scientist .us NMED Website and Listserv: www.env.nm.gov/kafbfuelplume Contact the Air Force: Kathryn Lynnes Senior Advisor (505) 846-8707 kathryn.lynnes@us.af.mil Air Force Installation and Mission AFIMSC.PA.Workflow@us.af (866) 725-7617 Support Center Public Affairs .mil Kirtland AFB Public Affairs (505) 846-5991 377ABW.PA@us.af.mil Kirtland AFB website: www.kirtland.af.mil in the Environmental Issues section for Public Records 15
