July 2018 1 Purpose of Current Outreach Introduce project - PowerPoint PPT Presentation

July 2018 1 Purpose of Current Outreach Introduce project Describe study process Present initial transit concepts for Valley-Westside Gather feedback on project purpose, transit concepts, and issues of community concern 2 What


  1. July 2018 1

  2. Purpose of Current Outreach  Introduce project  Describe study process  Present initial transit concepts for Valley-Westside  Gather feedback on project purpose, transit concepts, and issues of community concern 2

  3. What We’re Studying  Rail transit concepts between the San Fernando Valley and LAX  Connections to existing/planned transit corridors  Alignments and station locations, including Park & Ride Valley - Westside  Maintenance facility requirements  Study Area divided into two sections: • Valley-Westside • Westside-LAX Westside - LAX 3

  4. Project Purpose and Need Provide a high-quality transit service that effectively serves a large and growing travel market between the San Fernando Valley and the Westside, including the LAX area. For transit to be a competitive travel option that attracts new riders, there is a need to increase the speed, frequency, capacity and reliability of transit service and provide convenient connections to existing and planned transit corridors. 4

  5. Study Process 5

  6. Initial Transit Concepts Valley - Westside 6

  7. Components of a Transit Concept  Type of transit vehicle (e.g., light rail or monorail)  Alignment — the route the transit service follows  Terminus station locations — endpoint or final station for the transit alignment  Intermediate station locations — stations along the alignment and between the endpoints  Vertical configuration (e.g., at grade, underground, aerial) Underground heavy rail station Aerial light rail station 7

  8. Transit Modes Under Consideration  Fully grade separated  Typically on aerial beam  Up to 70 mph  Up to 50 mph  6 to 8 cars per train  Up to 8 cars per train  810 to 1,080 passengers  Up to 480 passengers per per train train  Examples: Metro Red and  Can sustain operations on Purple Lines steep grades  Examples: Las Vegas Monorail Heavy Rail Transit (HRT) Monorail  At grade, underground, or aerial  At grade, underground, or  Up to 50 mph aerial  Up to 9 cars per train  Up to 65 mph  Up to 1,440 passengers per train  3 to 4 cars per train  Can sustain operations on steep  405 to 540 passengers per grades train  Relatively high energy  Examples: Metro Blue, consumption Light Rail Transit (LRT) Rubber Tire Transit Green, Gold, and Expo Lines  Examples: Mexico City Metro 8

  9. Initial Valley-Westside Transit Concepts (All concepts planned to allow extension to LAX) Monorail or Purple Line HRT Concepts LRT Concepts Rubber Tire Extension Concept 1 Concept 2 Concept 3 Concept 4 Concept 5 Concept 6 9

  10. Concept 1 (HRT) Valley Heavy Rail Transit (HRT) 10

  11. Concept 1 (HRT) Westside Heavy Rail Transit (HRT) Alignment options on the Westside are the same for Concepts 1-4 11

  12. Concept 2 (HRT) Valley Heavy Rail Transit (HRT) 12

  13. Concept 3 (LRT) Valley Light Rail Transit (LRT) 13

  14. Concept 4 (LRT) Valley Light Rail Transit (LRT) 14

  15. Concept 5 (Monorail or Rubber Tire) Valley Monorail Rubber Tire Transit 15

  16. Concept 5 (Monorail or Rubber Tire) Westside Monorail Rubber Tire Transit 16

  17. Concept 6 (Purple Line Extensions) Valley Heavy Rail Transit (HRT) 17

  18. Concept 6 (Purple Line Extensions) Westside Heavy Rail Transit (HRT) 18

  19. Station Opportunities Valley Westside 19

  20. Evaluation Criteria Community Input Potential Environmental Effects Compatibility with Local and Reliability Regional Plans Ridership Cost Sustainability Cost-Effectiveness Travel Time Savings 20

  21. Feasibility Study Schedule We are here 21

  22. Connecting with the Community  Project database of 6,900 and growing  Project survey – over 5,000 responses to date  Coordination with commuter services agencies & groups – survey sent to 50,000+ employees in the region  Project video  Project webpage – www.metro.net/projects/sepulvedacorridor/  Community meeting notification • Take One cards – 31,000+ distributed • Targeted Facebook & print advertisements • Media release & The Source posts • Distributions at neighborhood councils and city halls 22

  23. Thank You Questions 23
