CurrentRF On-Chip Super Capacitor IP (Power Optimizer) Michael Hopkins Founder and CEO IP Product Offerings Patent Pending Super Capacitor IP Test Chip (Theory) + Patent Pending Super Capacitor IP Test Chip(Example) Minimum Total Efectve


  1. CurrentRF On-Chip Super Capacitor IP (Power Optimizer) Michael Hopkins Founder and CEO

  2. IP Product Offerings Patent Pending

  3. Super Capacitor IP Test Chip (Theory) + Patent Pending

  4. Super Capacitor IP Test Chip(Example) Minimum Total Efectve Minimum 11uF Capacitance Increase-- 22uF Increase + 11uF Patent Pending The Efectve Capacitance Increase Follows the Base Input Capacitance

  5. CC_100 Super Capacitor IP (Theory) + Patent Pending

  6. CC_100 Super Capacitor IP (Example) Minimum Total Efectve Capacitance Increase– 32pF Minimum 16pF Increase + 16pF Patent Pending The Efectve Capacitance Increase Follows the Base Input Capacitance

  7. RF Amplifier Sensitivity Enhanced with the CC_100 Super Capacitor IP Patent Pending

  8. Super Capacitor IP Integration

  9. CC_100 Super Cap IP Benefits/Features • Energy Harvesting (Up to 20% Reduction in Dynamic Current) • RF Emissions Reduction(Up to 20% over Standard DCAPs) • At least a 2X Effective Capacitance increase over standard DCAPs • A 25% reduction in Effective Series Inductance (ESL) • Enhanced System PSRR(Cleaner System Spectral Outputs) • Draws No Operational DC Power • CC_100 IP can be shaped into any form factor • CC_100 IP used as a standard DCAP • Customizable Design

  10. CC_100 IP Equals PowerStic/Exodus

  11. CC-100 IP Dynamic Power and Emissions Reduction

  12. CC-100 IP High Frequency Dynamic Emissions Reduction

  13. CC_100 IP Low Frequency Dynamic Emissions Reduction 20% Dynamic Power Reducton

  14. CC_100 Flash Memory Power and Emissions Reduction

  15. CC_100 IP S11 Input Reflection Performance o Almost Perfect S11 Refecton Performance— SWR=1.00 o Lowest Impedance Point-370 Mhz o Tracks an 11uF Capacitve Impedance Curve

  16. CC_100 IP S11 Total Reflection Performance o Network Analyzer Detectors Actvated By CC_100 IP Return Current— o Slight Reducton In Overall SWR o Lowest Impedance Point-170 Mhz o Tracks a 22uF Capacitve Impedance Curve

  17. CC_100 IP System PSRR Enhancement o Same Dynamic Current Reducton o Spectral Bandwidth Noise Reducton With Multple CC_100 IP Super Capacitor Cells.
