Installation Process Level granular bedding foundation Set screed - PowerPoint PPT Presentation

Installation Process Level granular bedding foundation Set screed boards allowing 1 all around foundation Installation Process Top to 1 should be concrete sand leveled by using straight screed- Note the screed boards set level on a


  1. Installation Process Level granular bedding foundation Set screed boards allowing 1’ all around foundation

  2. Installation Process Top ½” to 1” should be concrete sand leveled by using straight screed- Note the screed boards set level on a minimum of two sides

  3. Partially screeded after base rock is complete

  4. Level boards set and top 1/2" to 1" finished with concrete sand and screeded level.

  5. Sand screeded level and strings set. Ready for blocks to be set

  6. Installation Process Unload trucks using slings

  7. Installation Process Set blocks per the installation details The picture can't be displayed.

  8. Installation Process Execute Post- Tensioning Sequence The picture can't be displayed.

  9. Installation Process Execute Post- Tensioning Sequence The picture can't be displayed.

  10. Execute Post- Tensioning Sequence

  11. GET IN, GET OUT, GET CONNECTED
