I 2 C-bus Elements SASE March 2010 SASE- March 2010 Alix Maldonado - - PowerPoint PPT Presentation

I2C-bus Elements SASE March 2010 SASE- March 2010

Alix Maldonado -Technical Marketing Manager Product Line System Management Business Line Interface Products

Agenda

I2C-bus Protocol Electrical Characteristics Electrical Characteristics Measurements with an Oscilloscope Resources Questions

2

I2C - Protocol

IIC - Inter-Integrated Circuit g

Logic

This means:

• Decreased number of wires (reduced PCB area)
• Reduced number of chip pins

Logic

p p

• Remove glue logic
• Clip many devices on to the bus
• Modular design: Time-to-Market

V

I2C-bus

VCC

Invented by NXP! (Philips Semiconductors) I2C-bus developed in the late 1970’s for Philips consumer products (e.g. TVs) Worldwide industry standard and used by all major IC manufacturers (Philips Semiconductors) Worldwide industry standard and used by all major IC manufacturers

3

I2C - Protocol

Hardware architecture

VDD

Pull up resistors SDA SDA SCL Data out Data in Clock out Clock in Data out Data in Clock out Clock in

2 wire bus: – SDA: Serial Data Line

Device 1 Device 2

SDA: Serial Data Line – SCL: Serial Clock Line Open-drain or open-collector output stages: wired-AND function

4

I2C - Protocol

Hardware architecture (2)

Master2 Slave2

VDD

SDA SCL

Multiple master

Master1 Slave1

Multiple slave Bi-directional – Master-transmitter – Master-receiver – Slave-transmitter – Slave-receiver Data collision is taken care off Data collision is taken care off

5

I2C - Protocol

Addressing / device selection

Each device is addressed individually by software New devices or functions can be easily “clipped" on to an existing bus! 112 different addresses max with the 7-bit format (others reserved); additional 1024 with ( ) 10-bit format Address allocation coordinated by the I2C-bus committee Programmable pins means that several of the same devices can share the same bus f f Unique address per device: fully fixed or with a programmable part through hardware pin's) 10-bit format use a 2 byte message: 1111 0A9A8R/W + A7A6A5A4A3A2A1A0

V

Master1 Slave1

VDD

SDA SCL

VDD

1 1 1 Fixed Hardware Programmable

Address register A6 A5 A4 A3 A2 A1 A0 6

I2C - Protocol

Communication

Master

Communication must start with: START condition Start bit is always followed by slave address Sl dd i f ll d b READ NOT WRITE bit

Slave Master or Slave

Slave address is followed by a READ or NOT-WRITE bit The receiving device (either master or slave) must send an ACKNOWLEDGE bit Communication must start with: STOP condition

START SLAVE ADDRESS[7] R/W ACK DATA[8] ACK STOP

Example:

START SLAVE ADDRESS[7] ACK DATA[8] ACK STOP

Transmit (0 = Write)

DATA[8] ACK

Example:

START SLAVE ADDRESS[7] 1 ACK DATA[8] ACK STOP

Receive (1 = Read)

DATA[8] ACK 7

I2C - Protocol

START & STOP conditions

Start condition - a HIGH to LOW transition on the SDA line while SCL is HIGH Stop condition - a LOW to HIGH transition on the SDA line while SCL is HIGH

8

START Timing Diagram

START condition is a high to low transition on the SDA line while SCL is high

START Slave Address R/W ACK DATA NACK

… DATA

ACK RE- START/ STOP

9

STOP

STOP Timing Diagram

STOP condition is a low to high transition on the SDA line while SCL is high

START Slave Address R/W ACK DATA NACK

… DATA

ACK RE- START/ STOP

10

STOP

RE-START Timing Diagram

RESTART diti i hi h t l t iti th SDA li hil SCL i RESTART condition is a high to low transition on the SDA line while SCL is high, exactly the same as the START

START Slave Address R/W ACK DATA NACK

… DATA

ACK RE- START/ STOP

11

STOP

I2C - Protocol

Bit transfer

During data transfer, SDA must be stable when SCL is High

12

I2C - Protocol

Data transfer

Each byte has to be followed by an acknowledge bit Number of data bytes transmitted per transfer is unrestricted If a slave can’t receive or transmit another complete byte of data, it can hold the clock line SCL LOW (clock stretching) to force the master into a wait state

13

I2C - Protocol

Acknowledge / NOT-Acknowledge

I2C specification: Data transfer with acknowledge is obligatory. The receiver must pull down the SDA line during the acknowledge clock pulse so that it remains stable LOW d i th HIGH i d f thi l k l during the HIGH period of this clock pulse. Scenarios with a NOT-acknowledge (NACK) (SDA staying HIGH): 1. A receiver with the address is not present in the I2C bus. 2 The receiver is performing real-time tasks and it cannot process the received I2C 2. The receiver is performing real time tasks and it cannot process the received I C information. 3. The receiver is the master and wants to take control of SDA line again in order to generate a STOP command. The slave transmitter MUST then release the SDA line when it sees the NACK so the master can send the STOP command

14

line when it sees the NACK so the master can send the STOP command.

I2C - Protocol

Arbitration procedure p

Two or more masters may generate a START condition at the same time Arbitration is done on SDA while SCL is HIGH - Sl i l d

VDD

SDA

Slaves are not involved

DATA1 SDA DATA2 SDA Master 1 Master 2

Summary: The master that first sends a “1” while the other sends a “0” loses control (arbitration)

15

I2C - Protocol

Clock synchronization during the arbitration procedure y g p

VDD

SCL

Internal counters of masters count the LOW and HIGH times (TL1, TH1) and (TL2, TH2)

CLK1 SCL CLK2 SCL SCL Master 1 SCL Master 2 T T

Wired-AND SCL connection: TL= longest TL= max (TL1, TL2 ,TLn) T shortest T min (T T T )

TL1 TH1 TL2 TH2

TH= shortest TH= min (TH1, TH2,THn)

T T

L2 H2

16

TL TH

I2C - Protocol

Modes

Standard Mode Fast Mode Fast Mode Plus (FM+) High Speed Mode (FM+) Bitrate (kBit/s) 0 – 100 0 – 400 0 – 1000 0 – 1700 0 – 3400 Address (bits) 7 (10) 7 (10) 7 (10) 7 (10) 7 (10) Capacitive Bus Load (pF) 400 400 550 400 100

Fast mode Plus (FM+):

Increased bandwidth

Sink current (mA) 3 3 20 3 3

– Increased bandwidth – Increased transmission distance (at reduced bandwidth: >> 550 pF bus load)

17

I2C - Protocol

Modes: Electrical specification

Standard Mode Fast Mode Fast Mode Plus (FM+) Bitrate (kBit/s) 0 – 100 0 – 400 0 – 1000 0 – 1700 0 – 3400 High Speed Mode Address (bits) 7 (10) 7 (10) 7 (10) 7 (10) 7 (10) Capacitive Bus Load (pF) 400 400 4000 400 100 Sink current (mA) 3 3 20 3 3 Trise: Rise time (ns) 1000 300 120 160 80 Trise: Rise time (ns) 1000 300 120 160 80 trise V Vcc Vbus (V) VIH V 0.7 * VDD 0 3 * V t (s) VIL VOL 0.3 VDD 0.4 V @ 3 mA sink current 0 4 V @ 20 mA sink current (FM+) gnd t1 t2

18

0.4 V @ 20 mA sink current (FM+)

I2C - Protocol

Summary

START HIGH to LOW transition on SDA while SCL is HIGH STOP LOW to HIGH transition on SDA while SCL is HIGH DATA 8-bit word, MSB first (Address, Control, Data):

• Must be stable when SCL is HIGH
• Can change only when SCL is LOW
• Number of bytes transmitted is unrestricted

D h 9th l k l d i th HIGH i d ACKNOWLEDGE

• Done on each 9th clock pulse during the HIGH period
• The transmitter releases the bus - SDA goes HIGH
• The receiver pulls DOWN the bus line - SDA goes LOW

CLOCK

• Generated by the Master(s)
• Maximum speed: (100, 400, 1000, 3400 kHz) but NO min

CLOCK p ( )

• A receiver can hold SCL low when performing another function (transmitter in a Wait state)
• A master can slow down the clock for slow devices

ARBITRATION

• Master can start a transfer only if the bus is free
• Several masters can start a transfer at the same time

A bit ti i d SDA li

• Arbitration is done on SDA line
• Master that lost the arbitration must stop sending data

19

START and STOP Conditions START and STOP Conditions

Q estion What is rong ith this fig re? Question: What is wrong with this figure?

20

Data Transfer

Acknowledge Data

• During data transfer SDA must be stable when SCL is High
• Each byte has to be followed by an acknowledge bit
• Number of bytes transmitted per transfer is unrestricted

During data transfer, SDA must be stable when SCL is High

• If a slave can’t receive or transmit another complete byte
• f data, it can hold the clock line SCL LOW to force the

master into a wait state

21

master into a wait state

I2C-bus Slave Address (1)

Two formats of I2C slave address: 7-bit or 10-bit address 7-bit Slave address is most popular, allows up 111(27 = 128 devices 128 – 17 reserved ) 10-bit slave address may accommodate up to 210 = 1024 devices on the same bus Devices that supports either 7 bit or 10 bit address may co exist on the same Devices that supports either 7-bit or 10-bit address, may co-exist on the same bus

Reserved Addresses

START Slave Address R/W ACK DATA NACK

…

DATA ACK RE- START/ STOP START Slave Address R/W ACK DATA NACK

…

DATA ACK RE- START/ STOP ACK/

22

STOP STOP

I2C-bus Slave Address (2)

µcon- t ll I/O A/D LCD RTC µcon- t ll II SCL troller SDA D/A troller II

1 0 1 0 A2A1A0R/W 1 0 1 0 0 1 1

New devices or

EEPROM

A0 A1 A2

• Each device is addressed individually by software

Fixed Hardware Selectable

New devices or functions can be easily “clipped” on to an existing bus!

U i dd d i f ll fi d ith bl t

• Programmable pins mean that several of the same devices can share

the same bus

• Unique address per device: fully fixed or with a programmable part

through hardware pin(s)

• 112 different addresses max with the 7-bit format (others reserved)
• Address allocation coordinated by the I2C-bus committee
• 10-bit format use a 2 byte message: 1111 0A9A8R/W + A7A6A5A4A3A2A1A0

23

10 bit format use a 2 byte message: 1111 0A9A8R/W + A7A6A5A4A3A2A1A0

I2C Slave Address – 7bit Format

Consist of fixed address and hardware selectable address (optional), a total of 7-bit R/W bit is sometimes included as part of the address, and is called read or write address)

X X X X A2A1A0 R/W ACK S

p , )

Fixed Hardware Selectable pins Only the addressed slave device acknowledges 7-bit address R/W bit is included result in: odd address is always the “read” address, even address is always the “write” address

START Slave Address R/W ACK DATA NACK

…

DATA ACK RE- START/ STOP START Slave Address R/W ACK DATA NACK

…

DATA ACK RE- START/ STOP

1 1 0 0 0 0 0 W

ACK/

24

STOP STOP

I2C Slave Address – 10bit Format

1 1 1 1 0 A A 0 ACK C

Consist of fixed command, 11110 and 10-bit address (fixed or hardware selectable) A write operation takes up two bytes

1 1 1 1 0 A9A8 0 A7A6A5A4A3A2A1A0 ACK ACK S

Command Any 10-bit address slave devices may acknowledge Only the addressed slave device acknowledges Write

A read operation requires a two byte for write followed by a 1 byte read

1 1 1 1 0 A9A8 1

A read operation requires a two byte for write, followed by a 1 byte read

ACK 1 1 1 1 0 A9A8 0 A7A6A5A4A3A2A1A0 ACK ACK Sr S

Write operation Command p Any 10-bit address slave devices may acknowledge Only the addressed slave device acknowledges

25

1st Clock Timing Diagram

First clock cycle is clock cycle after the START bit START First Clock

26

First Clock

SCL, Serial Clock Timing Diagram

Falling edge of SCL signals the requirement to provide data on SDA Rising edge of SCL signals the need to hold that data bit g g g Clock period (T) = tCYCLE = 1/fSCL = tLOW + tHIGH + tf + tr

27

Key numbers to keep in mind

F t Hi h Standard Mode Fast Mode Fast Mode Plus High Speed Mode Bit Rate ( kb/ s) 0 to 100 0 to 400 0 to 1000 0 to 1700 0 to 3400 ( kb/ s) Max Load ( pF) 400 400 550 400 100 Rise tim e ( ns) 1000 300 120 160 80

Rise Time

( ns) Noise filter ( ns)

• 50

10 10 10

VDD VIH 0.7xVDD

Rise Time

GND VIL 0.3xVDD 0.4 V @ 3 mA Sink Current VOL 0.4 V @ 30 mA Sink Current (Fm+)

28

GND

SDA, Serial Data Timing Diagram

Normal data transition occurs when SCL is low Data is evaluated when SCL is high g

SDA data changing state SDA evaluated

29

Acknowledge (ACK)

Acknowledge bit occurs on the 9th SCL clock pulse The transmitter and receiver behave as follows: The transmitter and receiver behave as follows:

• 1. Transmitter releases SDA line after the 8th clock pulse
• 2. Receiver acknowledges by pulling SDA low on the 9th clock pulse
• 3. Transfer is aborted if SDA does not go low (no ACK)

g ( )

SDA

No ACK

HIGH

SDA SCL

ACK

LOW

9th SCL 8th SCL

30

Acknowledge Example

31

Not Acknowledge (NACK)

Three Scenarios where there is no acknowledge taking place 1. The receiver being addressed is not present on the I2C bus g p 2. The receiver is busy (cannot process the receiving information) 3. The master receiver wants to take control of SDA line

NACK

HIGH

SDA SCL

ACK

LOW

9th SCL 8th SCL

32

Not Acknowledge Example

33

Clock Stretch

A clock stretch is defined as the SCL line being pulled low – stretched – longer than its intended clock low period Why a device stretches the clock?

– A master performs clock stretch when it needs to slow down the clock in order to accommodate a slower slave device A slave performs clock stretch when it needs to perform other function – A slave performs clock stretch when it needs to perform other function

Data is “DON’T CARE” when the clock is low

SDA SCL DON’T CARE SCL

Clock stretch

34

Multi-master S h i ti /A bit ti Synchronization/Arbitration

35

Clock Synchronization & Bus Arbitration

Multi-master environment requires clock synchronization and data arbitration Masters synchronize on clock line

– Result in new clock frequency = longest low + shortest high

Masters arbitrate on data line

– Result in the losing master stop sending data – Losing master can continue to send SCL until the end the byte – Losing master can continue to send SCL until the end the byte – Data is not corrupted

VCC

Master#2

VCC

Master#2

Rpu Rpu

Master#1

Slave Address#1 Slave Address#2

Master#1

Slave Address#1 Slave Address#2

36

Address#1 Address#2 Address#1 Address#2

Clock Synchronization Timing Diagram

LOW period determined by the longest clock low period

Vd Vdd CL CLK 1 1 CL CLK 2 2 Ma Mas ter 1 1 Mas ter 2 Vd Vdd Vd Vdd CL CLK 1 1 CL CLK 1 1 CL CLK 2 2 CL CLK 2 2 Ma Mas ter 1 1 Mas ter 2

HIGH period determined by shortest clock high period

CL CLK 1 1 CL CLK 2 2 S C S CL CL CLK 1 1 CL CLK 1 1 CL CLK 2 2 CL CLK 2 2 S C S CL

1 2 3 4 2 3

37

Arbitration Timing Diagram

Two or more masters may generate a START condition at the same time Arbitration is done on SDA while SCL is high - Slaves are not involved

Master 1 loses arbitration DATA1 ≠SDA

Start command “1” “0” “0” “1” “0” “1”

38

Bus Recovery Method

Problem: Typical case is when a master fails during reading the slave device Typical case is when a master fails during reading the slave device The SDA line is stuck low because the slave is stuck in the transmitter mode Solution Three methods to recover the bus:

1) Use a hardware reset pin to reset the slave device (assuming the device ) p ( g has a reset pin) 2) Use a hardware self-timeout function such as SMBus timeout 3) Use an I2C-bus recovery sequence to leave the “Slave-Transmitter” mode ) y q

39

I2C-bus Recovery Sequence

An I2C-bus recovery sequence is done as follows:

1) Send 9 clock pulses on SCL line while the master “keeps” the SDA line high until the “Slave Transmitter” releases it including the time for the ACK high until the “Slave-Transmitter” releases it including the time for the ACK

• peration. “Keeping” SDA high during the ACK means that the “Master-

Receiver” does not acknowledge the previous received byte 2) The “Slave-Transmitter” then goes in an idle state (mandatory when no acknowledge is received) 3) The master then sends a STOP command to initialize the bus

Slave releases SDA line Slave held the line low Slave releases SDA line Slave becomes idle

40

Multi Master Mode - Clock Synchronization

Vdd Master 1 Master 2

TL1 TH1 T1 CLK 2 TL2, TH2 CLK 1 TL1, TH1 SCL TL, TH

T2

TL2 TH2

H1

Internal Counters count the Low and High times (TL1, TH1) and (TL2,

Count TH1 Count TL1

Counting TL1 done Wait State TL2 still counting

CLK1 TH2)

Count TH2

Count TL2

CLK2

Reset Counter High TH2 Start Counting TL2

2

Counting TL2 done Start Counting TH2 SCL goes High

3 4 2 3 4

SCL

TL = TL2 TH = TH1

• TL = longest TL = max (TL1, TL2 ,TLn )

T = shortest T = min (T T T )

Counting TH1 done Start Counting TL1 SCL goes Low

1

Start Counting TH1 Counting TH1 done Start Counting TL1 SCL goes Low

1 4

41

• TH = shortest TH = min (TH1, TH2,THn )

Multi Master Mode - Arbitration

• Two or more masters may generate a START condition at the same time
• Arbitration is done on SDA while SCL is HIGH - Slaves are not involved

Master 2 loses arbitration because DATA2 ≠ SDA

DATA1

Master 2 loses arbitration because DATA2 ≠ SDA

“0” “1”

DATA2 SDA

1 “0”

SCL SDA

SUMMARY: the master that sends a “1” while the other sends a “0” loses the arbitration

START

“1” “0” “0” “1” “1” “0” 42

the arbitration

I2C b El i l Ch i i I2C-bus Electrical Characteristics

Subject / Department / Author Subject / Department / Author -

43

SDA/SCL Driver Architecture

SDA and SCL are open drain/collector

– Required pull-up resistors to pull the line to logic “1”

Clock stretch is possible when a device is busy

Requires pull-up resistors 2k 10 k 2k to 10 kΩ Open drain structure and bidirectional for SDA and/or SCL

SCL

SCL

10 pF Max

44

Max

Key Electrical Parameters

Standard Mode Fast Mode Fast Mode Plus High Speed Mode Bit Rate 0 t 100 0 t 400 0 t 1000 0 t 1700 0 t 3400 Bit Rate ( kb/ s) 0 to 100 0 to 400 0 to 1000 0 to 1700 0 to 3400 Max Load ( pF) 40 400 560 400 100 Rise tim e 1000 300 120 160 80

Rise Time

( ns) 1000 300 120 160 80 Noise filter ( ns)

• 50

10 10 10

VDD VIH 70%VDD

Rise Time

GND VIL 30%VDD 0.4 V @ 3 mA Sink Current VOL

45

GND

Calculating Pull-up Resistors

1) RMIN < RPU < RMAX

VCC

Master#2

VCC

Master#2

RPU

VDDMAX VOLMAX RMIN IOLMAX = 3mA IOLMAX = 6mA* IOLMAX = 30mA**

2) RMIN = (VDDMAX - VOLMAX) / IOLMAX

VCC Rpu

Master#2 Master#1

Slave Address#1 Slave Address#2 VCC Rpu

Master#2 Master#1

Slave Address#1 Slave Address#2

3.6 V 0.4 V 1.1 kΩ 533 Ω 106 Ω 5.5 V 0.4 V 1.7 kΩ 850 Ω 170 Ω Glossary RPU: Pull-up resistor

Address#1 Address#2 Address#1 Address#2

*With a buffer; **Fast mode Plus

PU

p RMIN: Minimum pull-up resistor RMAX: Maximum pull-up resistor VDDMAX: Maximum supply rail VOLMAX: Maximum output voltage low MODE Frequency tr CMAX RMAX

3) RMAX * CMAX = 1.18*tr

With a buffer; Fast-mode Plus

VOLMAX: Maximum output voltage low IOLMAX: Maximum sink current CMAX: Maximum load capacitance tr: Rise time Standard 100 kHz 1000 ns 400 pF 2.96 kΩ Fast Mode 400 kHz 300 ns 400 pF 885 Ω Fast Mode Plus 1000 kHz 120 ns 560 pF 252 Ω

46

How to calculate I2C Pull-up Resistors?

Minimum value Minimum value

There is a minimum resistor value determined by the I²C spec limit of 3 mA. R = (Vddmax – Volmax)/ 0.003A Example: using a 5±0 5 V bus: R (5 5V 0 4V)/ 0 003A 1 7 kΩ Example: using a 5±0.5 V bus: R = (5.5V – 0.4V)/ 0.003A = 1.7 kΩ

Maximum value

Determined by the I²C-bus rise time requirements: Determined by the I C bus rise time requirements: V(t1) = 0.3*Vdd = Vdd (1–1/et1/RC); then t1 = 0.3566749*RC V(t2) = 0.7*Vdd = Vdd (1–1/et2/RC); then t2 = 1.2039729*RC t t2 t1 0 8472979*RC t = t2–t1 = 0.8472979*RC For standard-mode I²C-bus: t = rise time = 1000ns (1 µs) so RC = 1180.2 ns Example: at a bus load of 400 pF: Rmax = 2.95 kΩ For fast-mode: I²C-bus rise time = 300 ns @ 400 pF: Rmax = 885 Ω

47

@ p

max

How Do You Derive Rise Time for I2C-bus

I²C-bus rise time is determined as in the following :

1)

V(t1) = 0.3*VDD = VDD (1–1/et1/RC) t1 = 0.3566749*RC ( EQ1)

2)

V(t2) = 0.7*VDD = VDD (1–1/et2/RC) t2 = 1.2039729*RC ( EQ2)

3)

Subtract EQ1 from EQ2 t rise time = t2–t1 = 0.8472979*RC or R*C = 1 18*t R*C = 1.18*t rise time VDD V(t2)

Rise Time

70%VDD V(t1) 30%VDD 0.4 V @ 3 mA Sink Current VOL

t1 t2 Time

48

Effects of Pull-up Resistors

Minimum pull-up resistor limits the maximum current sink that affects the voltage output low (VOL). the voltage output low (VOL).

– Increasing pull-up resistor above RMIN leads to decreasing VOL and higher noise margin Decreasing pull up resistor below R leads to increasing V and lower – Decreasing pull-up resistor below RMIN leads to increasing VOL and lower noise margin

Maximum pull-up resistor affects the rise time and speed p p p

– Increasing pull-up resistor above RMAX leads to slower/possible rise time violation or lower speed – Decreasing pull-up resistor below RMAX leads to faster rise time and speed Decreasing pull up resistor below RMAX leads to faster rise time and speed

49

Measurements using an Oscilloscope

50

Using Cursors to make measurements

Allows one to make i k t quick measurements for

and

V ∆

t ∆

Handy in making rough Handy in making rough rise time measurements for I2C-bus

51

Effects of Pull-up Resistors

Rise time for SDA and SCL lines using 9K pull up resistors

52

Effects of Pull-up Resistors

Rise time for SDA and SCL lines using 2.2K pull up resistors

53

Effects of Pull-up Resistors

Side by side comparison of the difference in rise time using two different pull-up resistor values

54

Effects of Pull-up Resistors

Rise time for SDA and SCL lines using 100K pull up resistors Slow rise time, no stable logic high state.

55

Probing your I2C-bus

56

Passive Probe Basics

Passive probes make an attenuator circuit with the probe impedance and scope impedance

Probe 9 MΩ Scope 1 MΩ 1 MΩ Attenuation ratio 1 M Ω /(9 MΩ +1MΩ) ( ) = 1/10

57

Importance of Oscilloscope Coupling

Signal is attenuated too much if the coupling is set incorrectly

P b Scope Attenuation ratio 50 Ω /(9M Ω +50 Ω) Probe 9 M Ω Scope 50 Ω 50 Ω /(9M Ω 50 Ω) = 1/180,001

Most modern passive probes have a probe sense pin that mates with a probe sense ring on the pin that mates with a probe sense ring on the

• scilloscope – this automatically sets the correct

coupling and attenuation factor

58

Scope/Probe Impedance Matching

Passive probes have an adjustment that allows the user to tweak the impedance of the passive probe to match the impedance of the scope it is connected to, this low frequency adjustment results in improved pulse shapes on the oscilloscope display pulse shapes on the oscilloscope display

59

Passive Probe Adjustment

All oscilloscopes have a “Cal Out” which provides a clean square wave for passive probe adjustment and compensation Adjusting the capacitor in the Adjusting the capacitor in the probe allows the probe to be tuned for that scope and resulting in the good pulse shape resulting in the good pulse shape shown below

60

Importance of ground lead length while probing

Pulse measured with

Not having proper ground connection, shows distorted signal

÷10 passive Probe

A: Without Ground Lead B: 50 cm Ground Lead C: 10 cm Ground Lead C G D: BNC Direct Cable Connection (true signal shape) (true signal shape)

61

Exercise 1

Verify understanding of the I²C bus protocol y g p

Subject / Department / Author Subject / Department / Author -

62

I2C-bus Building Blocks

I/O `Expander` LED Blinker/ Dimmer DIP Switch AD/DA Converter Other Slave Color Mixing LED Driver Bus Buffer, Voltage Translator, Extender

VCC4 VCC5 VCC0

µC

I²C in hardware

• r software

emulation

µC

Bus C Master Selector Multiplexer& Switch

8

VCC2 VCC1

Functions with I2C I2C Bus Architecture Devices Custom I2C

EEPROM LCD Driver Real Time Clock / Calendar Temperature Sensor

µC

Controller

V

Custom I C hardware or software emulated Other hardware

I2C

Bridge

SPI UART

VCC3

63

Which tools to help you win ? y

I2C Demoboards

Demo and Evaluation Boards

65

Evaluation/Demo Board List

OM# Description OM# Description OM6270 SPI/I2C to UART Bridge Demoboard (SC16IS750) OM6271 SPI to I2C Master Bridge Demoboard (SC18IS600) OM6272 UART to I2C Master Bridge Demoboard (SC18IM700) OM6273 SPI/I2C to Dual UART/IRDA/GPIO Demoboard (SC16IS752) OM6274 I2C to SPI Master Bridge Demoboard (SC18IS602) OM6275 I2C 2005-1 Demo Board (15 I2C devices w/USB control & GUI) OM6276 PCA9633 Demo Board (Four Color PWM LED Control with Microcontroller) OM6277 PCA9564 Eval Board (I2C Master) OM6278 I2C 2002-1A Eval Board (11 I2C devices w/printer port control & GUI) OM6279 LED Dimmer Demo Board OM6279 LED Dimmer Demo Board OM6281 PCA9698 Demo Board (Advanced 40-bit GPIO with PCA9530 LED blinker) OM6276 PCA9633 Demo Board (Four Color PWM LED Control) OM6285 I2C 2002-1A Eval Board (without/printer port control & GUI) ( p p ) OM6290 I2C –bus LCD driver evaluation board OM10088 PCF8562 LCD Segment Display

More information: www ics nxp com/support/tools/interface More information: www.ics.nxp.com/support/tools/interface

NXP Bridge IC – Demo Board Kits

I2C/SPI slave to UART UART to I2C master SPI t I2C t I2C t SPI t I2C/SPI slave to UART UART to I2C master SPI to I2C master SC16IS7xx SC18IM700 SC18IS600 I2C to SPI master SC18IS602 Kit i l d Kits include Kit i l d Kits include

• Sample code: RS232

and NXP I2C devices

• User Manual

Kits include Key Benefit

• Sample code: SPI and

NXP I2C devices

• User Manual

Kits include Key Benefit

• Sample code: RS232,

RS485, and IrDA

• User Manual

Kits include Key Benefit

• Sample code: I2C and

NXP SPI devices

• User Manual

Kits include Key Benefit y

Easy interface to UART host and various I2C and GPIO

• devices. On-board I2C

y

Easy interface to SPI host and various I2C and GPIO

• devices. On-board I2C

EEPROM and I2C LED

y

Easy interface to I2C/SPI host and IrDA, RS232/RS485, and GPIO devices. Selectable I2C or SPI-

y

Easy interface to I2C host and SPI and GPIO devices. Up to 4 SPI chip selects EEPROM and I2C LED Dimmer Dimmer bus interface

Up to 5Mbps!

OM6270 – SC16IS750 OM6273 – SC16IS752 OM6271 OM6272 Up to 4 SPI chip selects OM6274 OM6273 – SC16IS752

Experience the variety of I²C peripherals with the latest I²C Training Board g

Fifteen different I²C devices on one board allows easy experimentation and training.

(PCA9531, PCA9536, PCA9538, PCA9540B, PCA9541, PCA9543A, PCA9551, PCF8563, PCF8574, PCF85116-3, SA56004, SE98)

Add Extra I/O Ports, Temperature Sensors, LED Drivers, Real-time Clock, I²C Bus S it hi Switching USB Connection to trial version (only devices on board and that fixed address is

• perational) Graphics Interface for Windows PC/Laptop

www.ics.nxp.com/support/boards/i2c20051/ p pp Target Board & USB based GUI (400 kHz) #OM6275

Get the color right with the single chip four color LED driver (R G B ?) four color LED driver (R G B ?)

Individual and Global PWM to set your perfect color and brightness or blink I²C interface for easy connection to Micro or Baseband IC Demo board with on board micro (LPC900) and FETs #OM6276 Stand alone demo Board #OM6282

www.ics.nxp.com/support/boards/pca9633/ www.ics.nxp.com/support/boards/pca9633/

Blink an LED without bit banging Dim and LED without burning a PWM on the MCU Dim and LED without burning a PWM on the MCU

Two PWMs to map across 2,4,8,16 outputs

– 25 mA per pin

I²C interface for easy connection to Micro or Baseband IC Demo Board with on board micro #OM6279

– PCA9533, PCA9531 PCA9533, PCA9531 – On-board NXP MCU demonstrates capabilities – www.ics.nxp.com/support/boards/leddemo

Easily Test and Demonstrate the PCA9698 40-Bit GPIO

Demonstrates a wide range of functions 1MHz Fast-mode Plus I2C-bus serial interface with 30mA drive 2.3 to 5.5V operation with 5.5V-tolerant I/O 40 configurable I/O pins that default to inputs at power-up Designed for live insertion in PICMG applications Designed for live insertion in PICMG applications Onboard PCA9530 LED dimmer/blinker for LED applications Low standby current Demo board #OM6281

www.ics.nxp.com/support/boards/pca9698/

Train on many I²C peripherals using parallel printer port to PC printer port to PC

Eleven different I²C devices on one board allows easy experimentation and training (LM75A, P82B96/PCA9600, PCA9501, PCA9515, PCA9543, PCA9550, PCA9551, PCA9554, PCA9555, PCA9561, PCF8582C-2) Add Extra I/O Ports, Temperature Sensors, LED Drivers, I²C Bus Switching Add Extra I/O Ports, Temperature Sensors, LED Drivers, I C Bus Switching I²C Bus adapter uses parallel printer port for connection to full version (all devices and addresses operational) of Graphics Interface for Windows PC/Laptop www.ics.nxp.com/support/boards/i2c20021/ Target Board plus parallel printer port control (100 kHz) & GUI #OM6278 Target Board plus parallel printer port control (100 kHz) & GUI #OM6278 Target Board only #OM6285

NXP I2C-bus LCD driver evaluation board (OM6290)

Th NXP I2C b LCD h th di l h t ll d b I2C b LCD The NXP I2C-bus LCD has three displays each controlled by an I2C-bus LCD driver. The segment display has a backlight driven by LED driver PCA9633. The board includes an NXP ARM7 microcontroller LPC2148 Demo board #OM6290

Easily drive a LCD Segment Display with a very small MCU and PCF8562 small MCU and PCF8562

Good for a User Interface at the front panel of a system Scalable to match the complexity of the LCD display Simple code using industry-standard 8051 core Easily reprogram micro via USB adapter (#OM10083) http://www.teamfdi.com/products/lcddemo/lcddemo.shtml Demo Board with on board micro #OM10088

MCU PCF 8562 LCD “Glass”

I²C

MCU LCD Driver Glass

I C

COG i ti COG is an option

Easy Access to I2C Technical Help

Three easy ways to ask technical questions and obtain answers Access I2C Discussion Forum from > www.nxp.com/i2c CONTACT link on every Product Information Page www nxp com/support www.nxp.com/support Send e-mail directly to I2C.Support@nxp.com

75

pp @ p

I2C Device Data Sheets, IBIS models Application Notes and Other Information Notes and Other Information

Product family Product family descriptions line cards cross reference data sheets data sheets Link to app notes models models user guides PLL design software datasheets

www.nxp.com/i2c or www.nxp.com/i2clogic

datasheets

76

Interface Products Internet Support

General: http://www.nxp.com/support I2C Control: http://www.nxp.com/i2c I2C.Support@nxp.com (E-mail Support) http://forums nxp com/forums (Forum) http://forums.nxp.com/forums (Forum) All other Interface Products http://www.ics.nxp.com/interface/ Interface.Support@nxp.com

77

Questions? Questions?

78
