烟台恒道齿轮有限公司 Hindle Group Ltd Hindle Gears China Ltd Caledonia Street 15# South Beijing Road, Yantai Bradford Economic & Tech Development Area, BD5 0EL Yantai, Shandong Province, China Tel: +44 (0) 1274 72 72 34 +86 535 695 2958

烟台恒道齿轮有限公司

烟台恒道齿轮有限公司 Our Range Upto 1000mm, 0.5m – 18m, ISO1328 Grade 3

烟台恒道齿轮有限公司 Motorsport

烟台恒道齿轮有限公司 Reverse Engineering – Lotus Evora Gearbox

烟台恒道齿轮有限公司 Jaguar XJ220

烟台恒道齿轮有限公司 Terex TR100 dump truck

烟台恒道齿轮有限公司 Terrier Military Vehicle Transmission

Precision Slew Gears Al.

烟台恒道齿轮有限公司 Subcontract Design Bulldog Hybrid Drive

烟台恒道齿轮有限公司 Pump timing gears 10,000+ per year ISO1328 Grade 5, Fr < 10um

烟台恒道齿轮有限公司 Planet Carriers

烟台恒道齿轮有限公司 Pump Gear Crank Gear Cam Gear Crank Gear

烟台恒道齿轮有限公司 650mm Annulus Compound Gear Compound Gear with Ground Bush Internal Helical

烟台恒道齿轮有限公司 Pinion Gear Printing Gear Annulus Water Pump Gear

烟台恒道齿轮有限公司 Assembled Epicyclic Annulus Aero Space Pump Gear Special machining

烟台恒道齿轮有限公司

烟台恒道齿轮有限公司 Wind Turbine Planet Gear Engine Cam Gear

烟台恒道齿轮有限公司 Brake Disc Housing

烟台恒道齿轮有限公司 Manufacturing Plan • Raw Material is procured from local Chinese source. • Rolled rings manufactured in Wuxi, PRC. • Rings are turned at Hindle Gears Yantai, PRC. • Gears rings are finish machined at Hindle Gears UK. • The finished gears are sold to Terex at the UK Rolled Ring Material Price.

烟台恒道齿轮有限公司 Production Control  Integrated MRP II system  KanBan and Line-side supply  4 customers on daily scheduling  Batch sizes from 1 to 4000

烟台恒道齿轮有限公司 Manufacturing Capabilities Turning 1600mm Dia * 800mm Width Okuma, Mori-Seiki & Deideshiem Milling 1800mm * 800mm * 800mm 0.002mm Accuracy 2 Okuma & 3 Cincinnati FTV

烟台恒道齿轮有限公司 Sub Contract Heat-Treatment We have very close relationships with a number of specialist in this field. Grinding (Internal & External) 750 Dia * 750 long Cincinnati, 2 Danobat, Lumsden, 2 Heckert, Hans Sieleman

烟台恒道齿轮有限公司 Gear Grinding 3 Reishauer CNC Generators 400mm Dia * 180mm width 10mm Module, Quality DIN 4 Höfler CNC Profile Grinder 1000mm Dia * 650mm width 18mm Module, Quality DIN 3+

烟台恒道齿轮有限公司 Planned Investment 2019 Internal Gear Grinding

烟台恒道齿轮有限公司 Metrology General geometry is Gear Geometry is measured measured using Mitutoyo using Klingelnberg P100 ZME 1200

Our Investment in China  We are globally competitive  We can reduce costs significantly  We manufacture ground gears <400mm, ISO Grade 5

烟台恒道齿轮有限公司 • Extensive Network of approved suppliers. • TS16949 • AS9100 • ISO9001

烟台恒道齿轮有限公司  Based in Yantai 烟台 Northern China  Owned and managed from UK  Manned solely by skilled Chinese operatives  Room for expansion  Will invest for growth  Typical savings of 40%  ISO Registered
