HH 24: Multiplicity and Jet Formation Bo Reipurth Institute for - PowerPoint PPT Presentation

HH 24: Multiplicity and Jet Formation Bo Reipurth Institute for Astronomy University of Hawaii Notwithstanding, in this talk I will argue that if we do not understand binary formation we do not understand star formation. Larsons conjecture:


  1. HH 24: Multiplicity and Jet Formation Bo Reipurth Institute for Astronomy University of Hawaii

  2. Notwithstanding, in this talk I will argue that if we do not understand binary formation we do not understand star formation.

  3. Larson’s conjecture: all stars are formed in unstable systems that break up, forming the field star population The multiplicity frequency declines through the protostellar and pre-main sequence phases due to breakup of small multiple systems

  4. Disintegration of Multiple Systems • • Non-hierarchical systems are unstable and oscillate between two phases: interplay and close triple approach , and the latter can lead to ejection . Reipurth 2000

  5. Numerical Simulations • Code developed by Seppo Mikkola in Turku • Newborn triple system inside cloud core • Stars gain mass through Bondi-Hoyle accretion • Cloud core loses mass from accretion to stars and from evaporation • Extinction of stars calculated continuously Reipurth et al. 2010

  6. Only two stars are seen, because the binary is unresolved on this scale One second of the movie corresponds to 30,000 years

  7. A sample of 100 simulations of three 0.5 Msun stars with initial mean separations of 100 AU emerging from a 3 Msun core Red: ejections leading to escapes Blue: ejections that remain bound Numerous stellar seeds escape very early, producing brown dwarfs

  8. A sample of 100 simulations of three 0.5 Msun stars with initial mean separations of 100 AU emerging from a 3 Msun core Class 0 Class 1 Prediction: Excess of wide companions at early ages Red: ejections leading to escapes Blue: ejections that remain bound

  9. Do we see an excess of distant companions around embedded young stars? Samples of near-infrared adaptive optics observations of newborn embedded stars Connelley et al. 2008

  10. The answer is ‘YES’ Binary separation distribution function 2000 AU 5000 AU

  11. The number of distant companions decreases with age: they are released once the envelopes are dispersed Spectral index is a proxy for age

  12. Orphaned Protostars An ‘orphan’ is a protostar which has been ejected from deep inside its nascent cloud core. This ejection may be into a loosely bound orbit, which will (briefly) bring it back into the core, or into an escape. By identifying orphans, we are thus able to directly observe a protostar at near-infrared or even at optical wavelengths! T Tauri itself is a prime example of an orphaned protostar

  13. L1630 HH 24 1 hr Ha + 1 hr [SII] with Subaru 8m telescope

  14. Six jets G C J E X L Subaru Ha - [SII]

  15. HH 24 with HST Dominant emission is [FeII] 1.65 micron Outflow cavities Destruction of cloud core STScI

  16. The many jets in the HH 24 complex are driven by a non-hierarchical multiple system of at least 6 embedded protostars . This is a situation we would expect should lead to a number of very low mass orphans. Class 0/I sources S HST K-band Stellar density 1000 times that Gemini JHK in the center of a globular cluster

  17. Single Spectroscopic binary Wide binary AU Single 5 arcsec Single Single

  18. Ha1 Ha2 Loosely tethered orphaned protostars Ha3 and brown dwarfs Ha4 Ha5

  19. 850 micron Loosely tethered Ha1 Ha2 orphaned protostars Ha3 Orphans located far outside and proto brown dwarfs the dense cloud core are located far outside the dense cloud core Ha4 Ha5 Data from Kirk et al. 2016

  20. Binaries from triple decays have highly eccentric orbits Courtesy Moeckel & Bally If a companion moves in an eccentric orbit it can lead to serious disturbance of the disk Disk disturbances lead to sudden increases in accretion onto the star Accretion again leads to mass loss and outflow activity

  21. The close fly-by of a star induces mass and angular momentum loss in protoplanetary disks. This is shown here for the case of a 1 M ⊙ star surrounded by a 100 AU disk encountered by another star with 1 M ⊙ and an encounter periastron of 100 AU. Courtesy Susanne Pfalzner

  22. Only a minor part of the disk reaches escape speed and it soon reassembles Because of such interactions the binary starts to spiral in Courtesy Susanne Pfalzner

  23. HH jet structure and binary evolution Triple disintegration event First periastron passage Binary in-spiral phase Spectroscopic binary? Merger? FUor eruption?

  24. HH jet structure and binary evolution Triple disintegration event First periastron passage Binary in-spiral phase Spectroscopic binary? Merger? FUor eruption?

  25. HH jet structure and binary evolution Triple disintegration event First periastron passage Binary in-spiral phase Spectroscopic binary? Merger? FUor eruption?

  26. Knots are not regularly spaced at each periastron passage because disk needs to reassemble 5” HH 24 jet E HST [FeII] 1.65 micron

  27. HH 24 ALMA channel maps in H2CO V_hel 8 - 12 km/s Each panel is color coded with velocity Reipurth, Bally et al., in prep.

  28. ALMA Field of View 09:4 km/s 12.18 12.35 12.01 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  29. H2CO 09:4 km/s 12.18 12.35 12.01 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  30. 09:4 km/s 11.67 11.84 11.51 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  31. 09:4 km/s 11.17 11.34 11.00 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  32. 09:4 km/s 10.67 10.84 10.50 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  33. 09:4 km/s 10.16 10.33 10.00 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  34. 09:4 km/s 9.66 9.83 9.49 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  35. 09:4 km/s 9.16 9.33 8.99 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  36. 09:4 km/s 8.65 8.82 8.49 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  37. 09:4 km/s 8.15 8.32 7.98 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  38. ALMA Field of View 09:4 km/s 12.18 12.35 12.01 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  39. H2CO 09:4 km/s 12.18 12.35 12.01 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  40. 09:4 km/s 11.67 11.84 11.51 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  41. 09:4 km/s 11.17 11.34 11.00 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  42. 09:4 km/s 10.67 10.84 10.50 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  43. 09:4 km/s 10.16 10.33 10.00 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  44. 09:4 km/s 9.66 9.83 9.49 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  45. 09:4 km/s 9.16 9.33 8.99 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  46. 09:4 km/s 8.65 8.82 8.49 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  47. 09:4 km/s 8.15 8.32 7.98 45.0 50.0 55.0 -0:10:00.0 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  48. ALMA Field of View 09:4 km/s 12.18 12.35 12.01 45.0 50.0 55.0 -0:10:00.0 “Hubble” flow: explosion! 05.0 10.0 15.0 09.5 5:46:09.0 08.5 08.0 07.5

  49. Tube caused by explosive event Cavities carved out by jets and wideangle winds

  50. Stellar merger? Low mass counterpart to the ‘fingers’ in Orion

  51. The Promise of JWST

  52. The JWST Dream The dream (dream on ….)

  53. The JWST Dream JWST will provide key information on multiple systems: 1) provide the first meaningful look at a jet engine and jet structure 2) provide jet proper motions to a few km/sec 3) resolve binaries down to <25 AU at 400 pc 4) image major disk disruptions from encounters 5) allow accurate determination of individual SEDs of components in multiple systems Perhaps something like this?

  54. Scientific biography can be downloaded at http://www.ifa.hawaii.edu/SP1

  55. If you wish to receive an alert every month when a new issue of the Star Formation Newsletter appears, just send an email to: reipurth@hawaii.edu
