FIRST FLOOR PLAN- ELEV. A DINING 12'-0"x9'-8" DINING - PowerPoint PPT Presentation

OPT. WORK O. BATH 5'-4"x5'-8" OWNER'S SUITE 14'-0"x15'-9" DINING 12'-0"x9'-8" GREAT ROOM 23'-3"x16'-4" GARAGE HIS HERS 21'-4"x20'-8" FOYER LAU. KITCHEN PATIO / OPT. COVERED / SCREEN PORCH FIRST FLOOR PLAN- ELEV. A

DINING 12'-0"x9'-8" DINING 12'-0" x 9'-8" PORCH FOYER STOOP FOYER FIRST FLOOR PLAN - ELEV. A-1 FIRST FLOOR PLAN - ELEV. B

DINING DINING 12'-0" x 9'-8" 12'-0" x 9'-8" PORCH PORCH FOYER FOYER FIRST FLOOR PLAN - ELEV. C FIRST FLOOR PLAN - ELEV. D

BEDROOM 3 BATH 2 LOFT 11'-4" x 10'-4" 19'-0"x10'-2" BEDROOM 4 13'-0" x 10'-2" BEDROOM 2 12'-4" x 13'-1" SECOND FLOOR PLAN- ELEV. A, B, C

LOFT 19'-0"x10'-2" BEDROOM 4 13'-0" x 10'-2" SECOND FLOOR PLAN - ELEV. D

GARAGE 21'-4"x20'-8" SCREEN PORCH 8'-0"x18'-8" SCREEN PORCH FIRST FLOOR PLAN

SCREEN PORCH RIGHT ELEVATION SCREEN PORCH REAR ELEVATION

FRONT ELEVATION A FRONT ELEVATION A OPT. EXTENDED OWNER'S SUITE

FRONT ELEVATION A-1 FRONT ELEVATION A-1 OPT. EXTENDED OWNER'S SUITE

FRONT ELEVATION B

FRONT ELEVATION C

FRONT ELEVATION D
