Fighting wear, corrosion, galling and fatigue on stainless steel and titanium alloys Agenda 10.10.19 Expanite Introduction From Research to business Facts & Figures Strategy Key pointers Expanite processes. This is how we do it Wear and


  1. Fighting wear, corrosion, galling and fatigue on stainless steel and titanium alloys

  2. Agenda 10.10.19 Expanite Introduction From Research to business Facts & Figures Strategy Key pointers Expanite processes. This is how we do it Wear and Corrosion after… Testing Expanite ExpaniteHard-Ti

  3. University anno 2009 From research to business • Expanite founded in 2010 by • Prof. Marcel Somers Hillerød ultimo 2012 • Ph.D. Thomas L. Christiansen • Ph.D. Thomas Strabo Hummelshøj …but development goes back to 2000! • First major customer early 2012 • Company culture driven by being a game- changer on the following parameters • Speed • Tailoring • Cleanliness • On-site

  4. Expanite as of January 2019 • Primary facility (600m2) in Hillerød, Denmark • R&D facility incl. lab and experimental furnaces • Expanite Treatment Center for production • US treatment facility near Cleveland, Ohio • German treatment facility near Stuttgart • Chinese facility near Shanghai • All sites are ISO9001:2015 certified • 2x yearly growth since 2013 • Approx. 26 employees

  5. Strategy • Two pillars for growth • Expanite Treatment Centers • Establish a global chain of treatment centers to service small to large size customers. • Key benefits are lead-time and quality • On-site installations • Install (standard) furnace with Expanite license for larger customers and or those customers who sees hardening as strategically important to their business • Key benefits are lead-time and cost-savings due to reduced work-in-progress and logistics

  6. Goes beyond the surface to reduce lead time and costs

  7. EXPANITE 3 Challenges This is how we do it

  8. Challenge no 1 – passive oxide layer Expanite gas process N + C not able to removes oxide layer penetrate oxide layer N + C is now able to enter material Expanite patent

  9. Challenge no 2 – Temperatures Expanded austenite CrN Low temperature Too high temperature – supersaturated solid – corrosion resistance lost! solution

  10. Challenge no 3 – Stabil Process = accurate control… ✓ . ✓ . % ✓ . Changing thermodynamical parameters Use a gaseous process !

  11. What is Expanite? A technology = process/recipe = time + temperature + pressure + gas flow + surface physics & chemistry in a furnace = a gas-based diffusion process Expanite� gas� process� N� +� C� not� able� to� removes� oxide� layer� penetrate� oxide� layer� N� +� C� is� now� able� to� enter� material�

  12. ISO9227 168hr salt spray What’s unique? Improving hardness and in the same time improving/restoring corrosion resistance beyond what the market previously has seen Micrographs & hardness profile of part in AISI316 1150� 1050� 950� 0.01]� 850� [HV� 750� Hardness� 650� 550� 450� 350� 250� 150� 0� 50� 100� Distance� from� surface� [ µ m]�

  13. What’s unique? ✓ . ✓ . ✓ . Accurate control • Tailoring • Scalable • Clean • Fast & Cost effective Identical temperature and time – only increasing gas potential Bulk-ware treatment • Homogenous hardening • No post cleaning • Bulk treatment

  14. Product portfolio • Tailoring of four core processes • ExpaniteHigh-T • ExpaniteLow-T • SuperExpanite = ExpaniteHigh-T + ExpaniteLow-T • ExpaniteHard-Ti • Other services include • Material recommendation/selection • Implementation & quality control of Expanite

  15. Temperature in vacuum: 1000-1200C The processes Fast gas quench Adds nitrogen DK: 400x400x600 DE: 400x400x1000

  16. ExpaniteHigh-T Transgranular g Nitrogen in solid solution c Cr 2 N h Grain Boundary Cellular

  17. ExpaniteHigh-T Critical range!! Transgranular g ExpaniteHigh-T applies special gas quench for high interstitial c Cr 2 N contents h High pressure N 2 quench can impair the Grain Boundary corrosion resistance!! Cellular

  18. Conventional Solution Nitriding N 2 cooling compromise corrosion resistance N 2 cooling gas Not N 2 cooling gas Expanite patent Surface decorated with fine surface nitrides

  19. ExpaniteHigh-T Hardness and corrosion resistance increase! Nitrogen martensite Expanded austenite Carbon martensite Austenite + ferrite Duplex stainless steel Martensitic stainless steel

  20. Martensitic stainless steel Treatment: ExpaniteHigh-T 12.5Cr- 0.12C -(1.5Mn+1.0Si max) Case Depth High-T: 0.55 mm Surface hardness: 950 HV0.3 750� 700� 650� 0.3]� 600� [HV� Hardness� 550� 500� 450� 400� 350� 0� 0.4� 0.8� 1.2� 1.6� 2� Distance� from� surface� [mm]�

  21. Temperature in atmospheric environment: The processes 380-470C Adds nitrogen and carbon in solid solution DK: 600x600x1000 DE: 800x800x1000

  22. Carbon and nitrogen – a smooth profile N C

  23. The processes

  24. Wear and Corrosion after….. Testing Expanite

  25. The pain…and the solution! Material� loss� -� accelerated� 6� Untreated� 5� ExpaniteHighT� SuperExpanite� [mg]� 4� Loss� 3� Weight� 2� 1� 0� 0� 20� 40� 60� 80� 100� 120� 140� Time� [min]�

  26. ° ASTM G133 wear test performed on AISI 316 stainless steel with and without “ SuperExpanite ” surface hardening treatment Lubrication: none Ceramic silicon nitride ball Force: 25N Total sliding distance: 100m

  27. Main conclusion: 125 times less wear on SuperExpanite treated plane surface

  28. ASTM G98 galling resistance test on EN 1.4401/AISI 316 Non-treated 316 vs. 316 reference SuperExpanite vs. SuperExpanite Non-treated Expanite-treated 0.5 ksi + no 1 ksi + no 2 ksi + no 5 ksi + no … … … 40 ksi + no

  29. Don’t just take our words for it “I haven’t seen such a solution to galling on 316 in my 15+ years of tribology testing” – Steven Budinski Owner/ Bud Labs

  30. Voltage Improved corrosion resistance 1500� AISI� 316� 1300� Anne aled� ExpaniteHigh -T SuperExpanite 1100� Reference 900� Pitting potential increase: 400mV 700� 500� 300� 100� Current 1E-08� 0.0000001�0.000001� 0.00001� 0.0001� 0.001� 0.01� 0.1� 1� 10� 100� -100� -300� * EN 1.4401 (AISI 316) Pitting resistance in seawater -500�

  31. Improved corrosion resistance Voltage 1200� 1000� AISI� 316� Annealed� 800� AISI� 304� Annealed� 304 ExpaniteHigh-T AISI� 304� ExpaniteHighT� V1� 316 reference 600� 304 reference 400� 200� 0� 1E-08� 0.0000001� 0.000001� 0.00001� 0.0001� 0.001� 0.01� 0.1� 1� 10� 100� Current -200� *EN 1.4401 / EN 1.4301 (AISI 316/304) Pitting resistance in seawater -400�

  32. ExpaniteHard-Ti

  33. Product portfolio – a closer look at ExpaniteHard-Ti ExpaniteHard-Ti

  34. ExpaniteHard-Ti • Gas process <800C • Adds oxygen; no titanium-nitrides • Can be used for: • Alloyed titanium e.g. grade 5 • Pure titanium e.g. grade 2 • Surface hardness: approx. 1000HV • Case depth: 10-50µm

  35. Applications: Watch in titanium • What : all exterior parts (case, bezel, bracelet, back, buckle) from Swiss watch brand Horage • Part are made in titanium grade 5 and then hardened by Expanite (ExpaniteHard-Ti); 30µm and approx. 1000HV. • Benefits: • Unique product with virtually unscratchable surface!

  36. A little summery : Short process time Cleaner Bulk wear Cost effective Improving hardness and in the same time Improving/restoring corrosion resistance Improving wear, galling or corrosion That’s why The future is gas -based diffusion
