FanFold-D V5 The Affordable Departmental Embosser Fast Reliable - PowerPoint PPT Presentation

Oct 30, 2023 •358 likes •630 views

FanFold-D V5 The Affordable Departmental Embosser Fast Reliable Embossers Encourage Accessibility to Braille on Paper Science tells us that a combination of reading on paper and reading electronically (refreshable braille or recorded

  1. FanFold-D V5 The Affordable Departmental Embosser

  2. Fast Reliable Embossers Encourage Accessibility to Braille on Paper Science tells us that a combination of reading on paper and reading electronically (refreshable braille or recorded content) together make optimum results in comprehension and pleasure F rom 7 Scientific Benefits of Reading Printed Books

  3. FanFold-D V5 01 What is a Departmental Embosser ? 02 Who Needs Departmental Embosser ? 03 Why Choose FanFold-D V5 ? 04 What Makes Index Quality?

  4. What Is A Departmental Embosser ? A departmental embosser is one that serves many users from a central location with speed, efficiency and reliability.

  5. Who Needs FanFold-D V5 ? Government School Districts Libraries Transportation Utility Companies Production

  6. Why Choose FanFold-D V5 ? Advanced Technology Safety Easy Maintenance Affordability Quality

  7. Advanced Technology

  8. Advanced Technology The Braille App Firebird Graphics Direct Braille

  9. Next Generation Application • Print without a traditional braille editor • Literary (G1) or contracted (G2) braille • Preview the file in text or as braille-dots • Edit the translated braille file • Browse for source file docx, doc and pdf on your desktop • Browse from USB memory inserted in the printer • Monitor and control printer icons • Install Firmware upgrade • Bluetooth • Wi-Fi • Wired network • USB memory inserted on the printer • Embosser status

  10. Modern V5 User Interface Easy to Operate Index V5 Interface • Speech feedback in 19 languages • Speaker embedded in control panel • Labelled in braille and text • LED lighted text and icon feedback

  11. Safety Features

  12. Safety Features The FanFold-D V5 comes with its own sound enclosure and operates at 63 dB compared to 80dB of a desktop unit

  13. Sound Comparison Document: John F Kennedy’s Inauguration speech January 20 th , 1961 2732 words 15,365 characters with spaces. 6 pages long. Printed from MSWord using Direct Braille in the Windows file tree. FanFold-D V5 Sample Link Juliet120 Sample Link Sound: 60+decibels Sound: 80+decibels Print time: 1 minute 19.11 seconds Print time: 3 minutes.59.71 seconds Click on underlined links to follow

  14. Easy Paper Access Easy to maneuver gliding shelves on both sides to prevent twisting and reaching in to lift

  15. Easy Maintenance

  16. Modular Design • The complete print assembly can be removed by end user with a call to technical support • Only four hand tightened wingnuts to remove print assembly for cleaning or repair • The three print head modules can be easily and individually replaced • A spare module can be ordered separately and kept at customer site for redundancy

  17. User Friendly • Replacement of modules is quick and requires minimum training • Mechanics can be shipped for repair without cabinet • Frequent firmware upgrades made available by Index to improve operation automatically • New generation solenoid design released January 2020 has access for cleaning and increased warranty period

  18. Superior Usability • No need for a separate braille editor • Support all operating systems • Supports booklet (vertical) printing • Easy to use Index BrailleApp • USB Host port for printing from a USB memory • High resolution tactile graphics • Acapela speech guides the user • Remote support via Internet • Liblouis text-to-braille translation is included • More than 150 languages • Literary (G1) and contracted (G2) braille

  19. Easy to Access Connections are conveniently placed on the back of the cabinet • Connect by host USB port or by Wi-Fi antennae • Network port • Serial Number Clearly Posted • Bluetooth capable • Standard USB Port • Easy to reach power port

  20. Affordability

  21. Price Comparison FanFold-D V5 $16,995 Brand X $23,000 Meets all Braille Authority dot height standards Meets all Braille Authority dot height standards Prints both 6 and 8 dot braille Prints both 6 and 8 dot braille Interpoint / Single-side Interpoint / Single-side 330 CPS (1000) pages per hour) 300 CPS (900 pages per hour) 63dB 69dB Superior braille quality and reliability Superior braille quality and reliability New age modular design for easy maintenance Legacy design Extensive reference list Extensive reference list Braille App, Direct Braille and Firebird Included Duxbury Braille Translator included Easy to setup & easy to service Easy to setup, only factory service Wi-Fi, Ethernet and USB connections Wi-Fi, Ethernet and USB connections Comes with stand and cart Stand and cart extra

  22. Index Quality Delivers

  23. Index Superior Dots Round dot follows the surface of the sphere with no holes or cracks Dot Dimensions • Height 0.5 mm • Diameter of dot base 1.6 mm • Diameter of the sphere 1.7 mm Braille cell size • Distance within the cell 2.5 mm • Distance between the cells 3.5 mm • Placed in a perfect grid

  24. Print Assembly Built to Last • FanFold-D V5 is 100% constructed by award winning Index manufacturer • The modular design is engineered for durability and superior quality. • Globally recognized design team Solenoid

  25. Exclusivity Humanware and Humanware Dealers are the Sole US Source for Index Embossers 25 Humanware/ Confidential

  26. Thank You For more information, contact:
