Exploring ENRON Email with NetLens Catherine Plaisant, Benjamin B. - PowerPoint PPT Presentation

Joint Institute for Knowledge Discovery Exploring ENRON Email with NetLens Catherine Plaisant, Benjamin B. Bederson Hyunmo Kang, Bongshin Lee Human-Computer Interaction Laboratory University of Maryland Our research focus Alternatives UI to


  1. Joint Institute for Knowledge Discovery Exploring ENRON Email with NetLens Catherine Plaisant, Benjamin B. Bederson Hyunmo Kang, Bongshin Lee Human-Computer Interaction Laboratory University of Maryland

  2. Our research focus Alternatives UI to Graph Visualization how to avoid this … Node-Link diagrams have many limitations. Not readable, may show clusters but not much else, do not scale well.

  3. NetLens Iterative Exploration of Content-Actor Network Data � User Interface for exploratory search � Generalizable to a variety of data � Provide consistent interface � Easy to learn and use Kang et al. Proc. of Visual Analytics Science and Technology Conference (VAST 06) Kang and al. Poster/Demo at Joint Conference in Digital Libraries, 2006

  4. NetLens Iterative Exploration of Content-Actor Network Data � Paired networks of Content and Actors, e.g. � Paired networks of Papers and Authors Papers refers to other papers � Authors have advisors � � Paired networks of Emails and People Email respond to or include emails � People have assistants who send email for them � � Paired networks of Products and Companies Products replace or integrate products � Companies are bought or merge �

  5. Content-actor model Relationship Self-relationship Self-relationship Entity E1 Entity E2 Examples for scientific papers:

  6. Toward SCALABILITY Total Enron email (non duplicate) 249,760 emails, 87,673 people

  7. Email People (addresses) Overview by years Overview by Domain

  8. Alternative overviews: emails by People by: day of the week, grouped by year connectance magnitude (Low medium high)

  9. Multiple email search capabilities 1- Keyword Search Here a search on “ California ” 2- Similarity Search Find emails similar to one or more selected emails Result set loaded in “ My list ” (with Doug Oard ’ s team)

  10. Social network analysis: - Number of neighbors - Connectance - Centrality - Average Path Length - Here selected people with high connectance With Jen Golbeck

  11. Social network analysis: - Number of neighbors - Connectance - Centrality - Average Path Length - Here selected people with high connectance With Jen Golbeck Explanations of the meaning of the attributes

  12. People bios � Using signatures and directory info with Jen Golbeck �

  13. Integrated Phone calls Replay Separate conversations Direct access to mentions of : subject, names, keywords (with Carol Espy ’ s team)

  14. Thread Summaries -List of emails in same thread -Access to thread -Access to thread summary With Bonnie Dorr and Doug Oard ’ s teams

  15. TreePlus to browse subset of network connections

  16. TreePlus - Visualizing Graphs as Trees � Plant a seed and watch it grow � Faster, more accurate, preferred over traditional graphs for tasks that involve reading and exploration of connections � To show hidden graph structure � Highlight and preview of adjacent nodes � Animated change of tree structure � Visual hints about graph structure B. Lee, C.S. Parr, C. Plaisant, B.B. Bederson, V.D. Veksler, W.D. Gray, C. Kotfila (2006) TreePlus: Interactive Exploration of Networks with Enhanced Tree Layouts To appear in TVCG Special Issues on Visual Analytics B. Lee, C.S. Parr, C. Plaisant, B.B. Bederson (2005) Visualizing Graphs as Trees: Plant a seed and watch it grow Proceedings of GD 2005 (poster) , LNCS , pp. 516-518

  17. Generalization to other datasets e.g. NetLens for Scientific Publications (Papers and Authors)

  18. User evaluation � Heuristic review at NIST � 5 PEOPLE – self trained with video) � Usability Study � 9 people, training, debriefing � Other improvements Improved feedback � • +++ Improvement of flow management Addition of My List � Adaptive explanations of views � Video training � Documentation of source / processing of variables �

  19. Implementation � C# (using piccolo toolkit) � MS Access Database � NetLens component code available on request

  20. Conclusions - Future Directions � Conclusions � Simple content actor model helpful � Powerful yet simple � Training about flow behavior � Continue integration with other IJKD data � E.g. Entity resolution � Evaluation (case studies of analysis) � Needs for Proto � Tool � Facilitate code customization for different applications � Flexible entities switching (to handle any choice of pairs) � Usability

  21. Thank You � plaisant@cs.umd.edu (301)405-2768 � bederson@cs.umd.edu (301) 405-2764 � NetLens: www.cs.umd.edu/hcil/netlens � TreePlus: www.cs.umd.edu/hcil/treeplus � Papers and Video demonstrations available from website. � Source code available on request.

  22. OTHER relevant HCIL projects

  23. Temporal Data (Categorical): PatternFinder for Patient History Search Fails, Karlson, Shahamat & Shneiderman, VAST 2006

  24. Systematic & Flexible Network Exploration with SocialAction Abstraction reveals Clustering shows relationships grouping Perer & Shneiderman, InfoVis 2006

  25. Network Visualization with Semantic Substrates • Meaningful layout of nodes • User controlled visibility of links Shneiderman & Aris, InfoVis 2006
