Exploiting performance measures from advanced SAS systems for autonomous MCM operations Torstein Olsmo Sb Research manager, Underwater Robotics Norwegian Defence Research Establishment (FFI) Undersea Defence Technology (UDT), 14/5-2019 The


  1. Exploiting performance measures from advanced SAS systems for autonomous MCM operations Torstein Olsmo Sæbø Research manager, Underwater Robotics Norwegian Defence Research Establishment (FFI) Undersea Defence Technology (UDT), 14/5-2019

  2. The Role of the Norwegian Navy Allied support -Sea Allied support -Air

  3. WW II Mine fields in the Oslo fjord Minefind • British air-dropped mining of Sea Mine Ground the inlets to Oslo Milco • Established in May 1940, Uxo September 1941 and Sea Mine Ground (Cleared) November 1941 in the inner part of the fjord • Established between September 1944 and April 1945 in the outer parts • “Cleared” mid 90s using Oksøy class • 30+ new objects found a few years ago • Several new objects found last year Courtesy of B. E. Marthinsen

  4. Future NOR MMCM concept

  5. Norwegian NMCM Structure Road Map 2016 2018 2020 2022 2024 2026 2028 Current MMCM Capacity MMCM Future MMCM Capacity Conceptual Definition Teams Project Phase phase Phase • From MCM vessels to support vessels • From ship integrated systems to modular systems • From ship-based organization to team organization 2015 2026 2028 Technology Development & Testing IOC FOC

  6. HUGIN autonomous underwater vehicle (AUV)

  7. RNoN AUV Batch Procurement • Four Kongsberg HUGIN AUVs with 3000 m depth rating – 1 st vehicle delivered week 36, first container system (with 2 nd vehicle) delivered week 48 • Main payload sensors – Synthetic Aperture Sonar (Mine detection & classification, mapping) – Multi-beam Echo Sounder (MD&C, Mapping) – Laser Camera (Contact identification and detailed mapping) – B/W still image camera (ID and detailed imaging) • In-mission processing – SAS and Automatic Target Recognition (ATR) • Performance evaluation – MCM Insite delivered by FFI

  8. Increased autonomy Autonomous Supervised Autonomous Adaptive plan Prior, fixed plan Accompanying surface vessel Adapt to environment, Autonomous navigation Acoustical updates of status, status and sensor data commands and position Emergency actions to reach mission goals

  9. AUVs in MCM The AUV revolution – 1995-2005 The SAS revolution – 2000-2010 Side scan sonar Detection of ground mines The autonomy revolution Detection and classification of ground mines from one pass Detection and classification of ground mines from one pass Identification in a second pass in the same mission

  10. HISAS • Prototype developed 2001-2005 • Around 20 production systems delivered since 2009 • In use with – Royal Norwegian Navy – Finnish Navy – Polish Navy – NAVO, USA – German MoD – Various civilian customers • More than 10 systems currently under delivery to military and civilian customers

  11. SAS is suitable for imaging small objects… Range 105 m Range 130 m Range 100 m Range 110 m Range 45 m

  12. …and large objects 240 x 100 m area Courtesy Norwegian Coastal Administration

  13. Example advanced SAS products: Sonar image and bathymetry SAS image SAS bathymetry

  14. Example advanced SAS products: Coherence and fusion image Coherence Fusion

  15. Example advanced SAS products: Anisotropy and variance Anisotropy Multiscale variance

  16. MCM Insite Performance Model in real-time autonomy system Sonar Performance Performance Table selected based on mine Performance Resolutions Table Table Table threat and data analysis system SNR Table look-ups Sharpness Fraction MCM Insite Undetectable Multi-scale Variances Anisotropy Performance Performance Performance Maps Maps Vehicle Data Maps Exported Results Performance parameters

  17. MCM Insite integrated into Reflection AUV PMA tool

  18. In-mission MCM performance evaluation test in 2018 (1)

  19. In-mission MCM performance evaluation test in 2018 (2) AUV tracks

  20. MANEX’13 • Multi-national AutoNomous EXperiment (MANEX) • 30/9 – 25/10 2013 outside Elba Island, Italy • NATO STO Centre for Maritime Research & Experimentation (CMRE)

  21. Single-mission concept demonstrated during CMRE exercises Area search In-mission ATR In-mission replanning In-mission EOID In-mission SAS processing

  22. Classification results Cylinder 99% Rockan 81% Manta 99% Manta 63%

  23. New procedure for MCM operations MILEC MILCO MINE Neutralize Detect Classify Identify NOMBO NON MILCO Search, Reacquire & Reacquire & MINE list MILCO list Classify & Map Identify Neutralize

  24. Questions?
