Energy Labelling: Simplified Method for Solar Thermal Consultation process: solar thermal experts 08 April 2020 Competition Law Rules Generally, all communications or discussions which could directly influence decisions by an individual

SLIDE 1

Energy Labelling: Simplified Method for Solar Thermal

Consultation process: solar thermal experts 08 April 2020

SLIDE 2

▪ Generally, all communications or discussions which could directly influence decisions by an individual company regarding production levels, product pricing, marketing strategies, or selection of customers or suppliers must be avoided. The following areas will not be discussed during meetings: ▪ Price or any elements of price or pricing policies, including costs, discounts, rebates, profit margins, etc. ▪ Terms or conditions of sale, including warranties, credit, and shipping arrangements. ▪ Specific competitors, suppliers, or customers. ▪ Sales or production quotas or limits, allocation of customers or sales territories or refusal to sell to certain customers or to buy from certain suppliers. ▪ The market share or sales territory of any specific competitor. ▪ The operating statistics, inventories, sales, marketing methods, or strategies of any specific competitor. ▪ Controlling competition or excluding any competitor from any market ▪ By implementing these measures, Solar Heat Europe/ESTIF remains in line with legal requirements.

Competition Law Rules

SLIDE 3

▪ The meeting will be recorded:

– For minuting purposes. – For uploaded in the members’area of SHE’s website.

▪ If the recording or the posting of the recording

f the meeting is an issue, please do not hesitate

to mention it.

Meeting Recording

SLIDE 4

Simplified method for solar thermal systems

SLIDE 5

▪ Starting point

– Solar thermal devices are heat generators that:

Can supply up most of water heating needs
Can supply considerable part of the space heating

– Not consuming energy, hence no product label except for solar water heater (thermosiphon with immersion electric heater) – Contributes to increase performance of package (package label) – Package label not working on market:

overall complexity, hard for installers to calculate solar devices,

issues with method, difficult (or none) market surveillance.

Simplified method for ST

SLIDE 6

During this period, a group of solar heat experts worked actively on a Simplified Method for Solar Thermal: – Adaptation of the original proposal from Solar Heat Europe by the consultants in March 2019 version of reports. – This adaptation was considered too simple and not reflecting adequately the potential of solar thermal but was a good indication that a simplified method for solar thermal was possible. A new Solar Heat Europe proposal – was presented to the consultants, European Commission and other stakeholders. Thanks to intense work from several experts (Andreas Bohren (SPF), Stefan Abrecht (Solar Heat Initiative) and also Gerard van Amerongen (VA Consult)

Simplified method for ST

SLIDE 7

One major innovation of the proposal: the “Solar Device Efficiency” (previously Solar Enhancement Factor) In brief, it has been identified by experts that the improvement a solar thermal system brings to a non-solar heat generator (usually referred in solar systems as a back-up heater, such as a boiler, a heat pump or an electric heater) can be identified as a function. This solar device efficiency is based on heat loads for space or water heating. Thus, it can be calculated for each specific solar thermal system both for water heaters and combination heaters.

Simplified method for ST

SLIDE 8

Source: Stefan Abrecht

Simplified method for ST

SLIDE 9

Source: Stefan Abrecht

Simplified method for ST

SLIDE 10

▪ SHE PROPOSAL

– Simplifying installer tasks, using Solar Device Efficiency:

– Option 1: produce a label class of solar system with the backup heater – Option 2: produce a factor for multiplication with the backup heater efficiency

Simplified method for ST

SLIDE 11

Select the collector Read the table Select row / column Read label class Read fη Get backup ηwh Multiply ηwh x fη Read label class ErP table Option 1 Option 2

Option 1: X = Label class Option 2: X = fη ηsys = ηbh x fη => label class

Simplified method for ST

▪ Simple calculation process

SLIDE 12

Results of ScenoCalc for one collector module - COMBI HEATING Number of collector modules: Service: ↓ 1 2 3 4 5 6 7 8 9 10 11 12 13 14 15 WH x x x x x x x x x x x x x x x SH x x x x x x x x x x x x x x x

Simplified method for ST

▪ Table to facilitate installer

Option 1: X = Label class Option 2: X = fη ηsys = ηbh x fη => label class

SLIDE 13

Input:

Collector test results (EN12975)

Output:

ηSH+Sol=ηSH x ηSol ηSH=Existing

XLSH

Simplified method for ST

SLIDE 14

Example „Look-up table“ water heating

Title of the presentation Load profíle M L XL XXL M L XL XXL M L XL XXL demand [kWh/a] 1523 2799 4427 5626 1523 2799 4427 5626 1523 2799 4427 5626

No. modules

hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh hsol-wh 2,0 m² 1 188% 137% 107% 96% 367% 231% 170% 129% 172% 138% 116% 105% 4,0 m² 2 299% 225% 171% 150% 500% 451% 329% 248% 232% 197% 165% 145% 6,0 m² 3 371% 302% 231% 201% 500% 500% 489% 367% 239% 239% 205% 180% 8,0 m² 4 405% 369% 288% 250% 500% 500% 500% 485% 239% 262% 236% 211% 10,0 m² 5 405% 426% 341% 296% 500% 500% 500% 500% 239% 268% 260% 238% 12,0 m² 6 405% 473% 391% 339% 500% 500% 500% 500% 239% 268% 275% 260% 14,0 m² 7 405% 510% 437% 380% 500% 500% 500% 500% 239% 268% 282% 277% 16,0 m² 8 405% 537% 480% 418% 500% 500% 500% 500% 239% 268% 282% 290% 18,0 m² 9 405% 554% 519% 454% 500% 500% 500% 500% 239% 268% 282% 299% 20,0 m² 10 405% 561% 555% 487% 500% 500% 500% 500% 239% 268% 282% 303% Solar device efficiency collector gross area Würzburg ≈ Strasbourg Athens Stockholm ≈ Helsinki average warmer colder

Table - Water heating results

A+++ /Premium FPC Collector type:

SLIDE 15

… multiplied with backup efficiency and tank factor = Hybrid efficiency

Title of the presentation

SLIDE 16

… and gives label classes

Title of the presentation

SLIDE 17

Pdesignh [kW] 3,0 6,0 10,0 15,0 3,0 6,0 10,0 15,0 3,0 6,0 10,0 15,0 demand [kWh/a] 6198 12396 20660 30990 4008 8016 13360 20040 7395 14790 24650 36975

no. Modules

hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh hsol-sh 2,0 m² 1 108% 104% 102% 102% 113% 106% 103% 102% 107% 104% 102% 101% 4,0 m² 2 115% 108% 105% 103% 132% 113% 107% 104% 114% 107% 104% 103% 6,0 m² 3 123% 111% 107% 105% 157% 121% 111% 107% 121% 111% 106% 104% 8,0 m² 4 130% 115% 109% 106% 188% 132% 116% 110% 129% 114% 109% 106% 10,0 m² 5 138% 119% 111% 108% 225% 143% 121% 113% 136% 118% 111% 107% 12,0 m² 6 145% 123% 114% 109% 268% 157% 127% 116% 143% 121% 113% 109% 14,0 m² 7 153% 126% 116% 111% 318% 171% 134% 120% 150% 125% 115% 110% 16,0 m² 8 160% 130% 118% 112% 373% 188% 141% 123% 157% 129% 117% 111% 18,0 m² 9 168% 134% 120% 114% 435% 206% 149% 127% 164% 132% 119% 113% 20,0 m² 10 175% 138% 123% 115% 503% 225% 157% 132% 171% 136% 121% 114%

Table - Space heating results

Würzburg ≈ Strasbourg Athens Stockholm ≈ Helsinki average warmer colder collector gross area Solar device efficiency Collector type: A+++ /Premium FPC

Example „Look-up table“ space heating

Title of the presentation

SLIDE 18

… multiplied with backup efficiency = Hybrid efficiency

Title of the presentation

SLIDE 19

… and gives label classes

Title of the presentation

SLIDE 20

▪ Requirements:

Collector parameters (EN12975 and ISO9806)

+ Collector gross yield (to be introduced in standards)

– New basis for the determination of the performance of a solar system considering all relevant collector parameters, the local climate and operating conditions. – Already in use for more than 20 years to compare the performance of collectors in an unambiguous way – Adopted in the CEN Solar Keymark certification scheme as Scenocalc – Information is easily available – Product fiche (from manufacturer or in EPREL for recent products) – Solar Keymark database and SK certificates

Simplified method for ST

SLIDE 21

▪ Easily available data

Simplified method for ST

SLIDE 22

MultiBin Method

The method, from the perspective of the user (installer), is explained in annex1. This method uses an individual calculation: the solar device efficiency is calculated for each collector individually in a extended ScenoCalc version and can be supplied by test institutes/Solar Keymark Datasheets or a calculation tool can be provided for manufacturers to create the tables themselves. The relevant files are available on the folder MBM and include:

Aris2004.xlsx (simulation for Standard flat plate collector, Aris 2004)
AS+.xlsx (simulation for Standard "unglazed" collector, AS+)
Germanstar HP70-24.xlsx (simulation for Standard ETC, Germanstar

HP70-24)

Simplified method for ST

SLIDE 23

Single bin with polynomials Method The method and the overall approach to the simplified method is explained in annex2.

uses a single bin approach
uses of fixed Polynomials/Nomograms.
The Polynomials are exemplary derived from Scenocalc.
Nomograms would allow simple visual method (also for the market surveillance)

The relevant files are available on the folder SBPM and include the Look up tables generator.

Simplified method for ST

SLIDE 24

Questions & Answers
