EMGAS COMPRESSED NATURAL GAS (CNG) INITIATIVE IN DUBAI Member of ENOC Group 1
EMGAS Sources of Gas Supply RENEWABLE ENERGY SOURCES NATURAL GAS PIPELINES Al Aweer Sewarage Treatment Plant STP Existing Existing Dec 2017 5,000 SCM/Day 15,000 SCM/Day 30,000 SCM/Day 50,000 SCM/Day Member of ENOC Group
General Project Outline Member of ENOC Group
EMGAS Sources of Gas Supply Member of ENOC Group
General Project Outline Biological Highly Desulphurization Economically Technology Proven CNG Standard CNG Technology Components Member of ENOC Group
Emirates Gas CNG Initiatives Member of ENOC Group 6
Objectives Of Emirates Gas CNG Project • Contribute to building a sustainable future, promote clean environment in Dubai, and reduce air pollution; • Develop the Natural Gas Vehicle industry as an alternate and sustainable energy solution which would reduce fuel costs; • Reduce the carbon footprint of the Dubai by substantially reducing the exhaust emissions and pollutants such as carbon monoxide, carbon dioxide, nitrous oxide and other ozone depleting substances; • Being the most favored tourist destination, to bring Dubai in league with the leading developed cities of the world to promote CNG as an alternate environmentally friendly fuel Member of ENOC Group 7
Emirates Gas Marketing Strategy Installation of CNG Daughter Stations at Dedicated Fleet Owners premises in Dubai Address potential Government Fleets Member of ENOC Group 8
Emirates Gas Philosophy ECONOMY CNG SAFETY ENVIROMENT Member of ENOC Group
CNG Mother Station Member of ENOC Group 10
CNG Daughter Station Member of ENOC Group 11
EMGAS CNG Daughter Station Member of ENOC Group 12
EMGAS Mini CNG Daughter Station Member of ENOC Group 13
EMGAS CNG Mobile Filling Unit Member of ENOC Group 14
Successful Results of CNG Trials at Dubai Airports CNG Consumptions 350 363 359 319 300 301 250 200 150 124 155 119 114 100 50 LEP - WEEK1 WEEK2 WEEK3 WEEK4 Cars Buses Member of ENOC Group
Estimated CO2 Reductions (based on 320 petrol vehicles) 600 Tons / Year 450 410 400 Per vehicle basis 350 300 8.0 Savings 2.2 Tons 7.0 250 Tons per Tons Savings 6.0 Annum 190 200 1.5 Tons per Annum 5.0 150 4.0 Tons 100 3.0 50 2.0 1.0 0 0.0 Car Bus & Others Car Van / Busses Petrol 5.0 7.4 CNG 3.5 5.2 Savings 1.5 2.2 Member of ENOC Group
Fuel Cost Benefits (based on current CNG pricing & 320 petrol vehicles) AED 4,205,000 / Year AED 3,580,000 AED 4,000,000.00 Per vehicle basis AED 3,500,000.00 AED 2,100 AED 3,000,000.00 AED 1,900 AED 1,700 Van / Bus AED 2,500,000.00 AED 1,500 Savings AED 1,300 AED 2,000,000.00 1600Dhs/ AED 1,100 month AED Car AED 1,500,000.00 AED 900 625,000 AED 700 Savings AED 1,000,000.00 AED 500 410Dhs/ month AED 300 AED 500,000.00 AED 100 Car Van / Bus AED 0.00 Petrol Cost AED 575 AED 2,100 Car Bus & Others CNG Cost AED 165 AED 500 Savings AED 410 AED 1,600 Member of ENOC Group
Estimated ROI (current CNG conversion cost) AED 20,000.00 AED 18,000.00 AED 16,000.00 AED 14,000.00 AED 12,000.00 AED 10,000.00 AED 8,000.00 AED 6,000.00 6 months AED 4,000.00 16 months AED 2,000.00 AED 0.00 Car Van / Busses Annual Savings AED 5,000.00 AED 19,000.00 Conversion Cost AED 7,000.00 AED 10,000.00 ROI in Months 16 6 Member of ENOC Group
Statistics – NGV’s Worldwide Country Natural Gas WORLD TOTAL Vehicles 19,625,077 VEHICLES Iran 3,500,000 Pakistan 2,790,000 Regional Natural Gas Breakdown Vehicles Argentina 2,389,570 Asia 12,402,580 Brazil 1,773,403 Eurasia 420,650 India 1,800,000 Africa 203,683 Italy 823,000 Europe 1,265,544 China 3,000,000 C & S America 5,180,815 Bangladesh 220,000 North America 151,805 Member of ENOC Group 19
Statistics – Refueling Stations Country NGV Refueling WORLD TOTAL Stations 25,134 CNG Stations Pakistan 2,997 Argentina 1,932 Regional NGV Refueling Iran 2,186 Breakdown Stations Asia 13,734 Brazil 1,805 Eurasia 735 China 5,730 Africa 189 India 903 Europe 3,898 Italy 1,022 C & S America 5,049 Bangladesh 585 North America 1,529 Member of ENOC Group 20
Current UAE CNG/NGV Statistics Emirate Operational CNG Stations Abu Dhabi 10 (Owned & operated by ADNOC) Al Ain 2 (Owned & operated by ADNOC) 2 (CNG Mother Station and Mobile Filling Unit – Dubai owned & operated by ENOC) Sharjah 1 (Owned & operated by SEWA) Sharjah 4 (Owned & operated by ADNOC) Emirate Natural Gas Vehicles Abu Dhabi 3,000 Dubai 300 Sharjah 350 Member of ENOC Group 21
CNG Advantages The Environmentally Clean Advantage Compressed natural gas is the cleanest burning fuel operating today CNG vehicles produce the fewest emissions of any motor fuel In gasoline vehicles, fueling emissions account for at least 50% of a vehicle’s total hydrocarbon emissions CNG is a fossil fuel that generates less air pollutants and greenhouse gases Tailpipe emissions from gasoline operated cars release carbon dioxide, which contributes to global warming. This is greatly reduced with natural gas. Member of ENOC Group 22
CNG Advantages The Performance Advantage Natural gas gives the same mileage as gasoline in a converted vehicle Dedicated CNG engines are superior in performance to gasoline engines CNG has an octane rating of 130 and has a slight efficiency advantage over gasoline Because CNG is already in a gaseous state, NGVs have superior starting and drivability, even under severe hot and cold weather conditions NGVs experience less knocking and no vapor locking Member of ENOC Group 23
CNG Advantages The Maintenance Advantage Some fleet operators have reduced maintenance costs by as much as 40% by converting their vehicles to CNG Intervals between tune-ups for natural gas vehicles are extended 30,000 to 50,000 miles Intervals between oil changes for natural gas vehicles are dramatically extended – anywhere from 10,000 to 25,000 additional miles depending on how the vehicle is used Natural gas does not react to metals the way gasoline does, so pipes and mufflers last much longer Member of ENOC Group 24
Vintage NGV’s 1940 Bottles in the Boot 1940 1955 Vintage Fuelling Horizontally Installed Bottles Member of ENOC Group 25
Modern NGVs Member of ENOC Group 26
Modern NGVs OEM(s) AFTERMARKET CONVERSIONS Member of ENOC Group 27
OEM / NGVs Typical OEM Installation Mercedes E200 NGT Member of ENOC Group 28
CNG Kit Components 1. CNG Filling receptacle 2. High pressure cylinders 2 3. Multifunctional cylinder valves 1 5 4. Solenoid Line valve 6 7 3 9 4 8 5. High pressure pipe & fittings 6. Pressure regulator 7. Low pressure filter 8. Sequential injection 9. ECU (Electronic Control Unit) Member of ENOC Group 29
CNG AUTOMOTIVE CYLINDERS Member of ENOC Group 30
State of the ART for CNG Cylinders 200 bar or 240 bar TYPE 1 All metal, steel or aluminium TYPE 2 A thick metallic, steel or aluminium liner, reinforced with resin impregnated continuous filament, hoop wrapped (Ex. filament: glass, aramide) - (Ex. resin: thermoplastic, polyester) TYPE 3 A thick metallic, steel or aluminium liner, reinforced with resin impregnated filament (glass or carbon), fully wrapped. TYPE 4 Resin impregnated continuous filament (carbon fiber or hybrid carbon and glass fibers) with a non-metallic liner, all composite. Member of ENOC Group 31
Typical Installation of Type1 Cylinders Member of ENOC Group 32
Q&A Member of ENOC Group 33
THANK YOU Member of ENOC Group 34
