EE-562 : Robot Motion Planning Lecture 1 ت�اب�ور ِى�� ءء ۵۶۲ Dr Abubakr Muhammad Assistant Professor Electrical Engineering, LUMS Director, CYPHYNETS Lab http://cyphynets.lums.edu.pk
Resources Course material from • CMPE-633x series (2010-13) at CYPHYNETS http://cyphynets.lums.edu.pk/index.php/Teaching • CMU course RI 16-735 by Howie Choset. Textbooks • Principles of Robot Motion by Choset et al. • Planning Algorithms by Steven Lavalle
What is a robot? • Public perception • Pop culture images
What is a Robot? A mechanical system that has sensing, actuation and computation capabilities. Other names (in other disciplines) • Autonomous system • Intelligent agent • Control system
What is a robot? • Is a toaster a robot? • Is a movie recommender system a robot? • Is a thermostat a robot? • Is a car cruise control system a robot? • Is an aircraft auto-pilot a robot?
What are Robots? • A robot is an intelligent connection of perception to action. • A robot is an autonomous system which exists in the physical world, senses its environment and acts in it to achieve some goals.
Think again … • Is a toaster a robot? • Is a movie recommender system a robot? • Is a thermostat a robot? • Is a car cruise control system a robot? • Is an excavator a robot? • Is an aircraft auto-pilot a robot? A robot is an autonomous system which exists in the physical world, senses its environment and acts in it to achieve some goals.
What Makes a Robot? A robot consists of: • – sensors – effectors/actuators – communication – controller A robot is a rational agent capable of • – acting autonomously – achieving goals Robota means self labour, drudgery, hardwork in Czech • • �اب�ور = �آ + � + ور ( Urdu Wikipedia)
What is Robotics? The art and science of making robots • Where are roboticists found • – Electrical engineering (control systems) – Mechanical engineering (mechanisms) – Computer science (AI, learning) – Mechatronics – Bioengineering Increasingly important • – Lawyers (legal issues, labor laws) – Philosophers (ethical issues) – Economists (disruptive technologies) – Social scientists (the social impacts of automation, aesthetics)
When did the first robots appear? • Hero’s automatic devices (~50 AD Alexandria) • Su Song’s clock towers (~1000 AD China) • Al-Jazari’s hydraulic automatons (~1200 AD Arabia) • Leonardo de Vinci’s mechanical knights (~1500 AD) • Tea serving karakuri puppets (~1800 AD)
Modern Robotics Three broad categories 1. Industrial robots: manipulators (1970’s) 2. Mobile robots: platforms with autonomy (1980’s) 3. Mobile manipulators = manipulator + mobility (2000’s)
Industrial Manipulators
Some Mobile Robots Terminology • UAV: Unmanned Aerial Vehicle • UGV: Unmanned Ground Vehicle • UUV: Unmanned Undersea (underwater) Vehicle • AUV: Autonomous Underwater Vehicle
Bio-inspired / Walking Machines
Why do we create robots? • A question for – the philosopher: rationalize the need? – the psychologist: man’s creative traits? – the theologist: man’s obsession with divinity? • A personal view point – Bible: “God created man in His own image.” (Genesis 1:27) – Hadith: “Allah created Adam in His image.” (Bukhari, ﻕﻠﺧ ﷲ ﻰﻠﻋ ﻡﺩﺁﻪﺗﺭﻭﺻ Muslim)
Why Robots? • Natural continuation of the industrial & information revolutions – automation • Better at dull repetitive tasks • Increased productivity • Can perform risky/dangerous tasks • Can work round the clock • No labor unions ! • Fukushima Daichii nuclear reactor (2011 earthquake) – 1,973 TEPCO emergency workers affected by radiation
Robots and Future Economies • Why do Robots have a role to play? • Where will be the greatest impact? – Driving, Mining, Agriculture, Healthcare, Humanitarian, Defense • What are the challenges and problems? – Legal challenges – Ethical issues • Robots and the developing world: What will be the social impact? – Automation and society – Social engineering – Conflicts and responsibility
Self-Driving Trucks for Mining • 17 Self-driving trucks deployed for mining in australia • Increased accuracy in operation as compared to humans • Improved earth excavation
Autonomous Driving • Market for advanced driver assistance systems to grow from $10 billion now to $130 billion in 2016 • Projected to reach $500 billion by 2020
Autonomous Driving • Tesla—90% autonomous vehicle within 3 years • EURO-NCAP automated emergency braking mandatory by 2014 • For 5-star safety rating, vehicle has to be ‘robotic’
Defense: Unmanned Aerial Vehicles • Drones—combat, surveillance • First appeared during the vietnam war • First recorded targeted killing– 2002 (afghanistan) • Global UAV market-- $5.9 billion now to $8.35 billion in 2018
Defense: Unmanned Aerial Vehicles • NYU/stanford report—2,562-3,325 fatalities in pakistan • U.S pullout from Afghanistan-- integration of decommissioned UAVs • Market ripe for drones for surveillance • Other uses: weather research, law enforcement
Defense: Driverless Vehicles • 1/3 of all U.S Military vehicles to be autonomous by 2015 • Terramax-- Oshkosh Trucking Corporation • Black Knight – Unmanned Tank
Unmanned Agricultural Machines • Efficient utilization of resources • Uavs for spraying insecticides • Driverless tractors
Unmanned Agricultural Machines • Possible Applications: Weeding, Harvesting, Pruning, Canal Cleaning (‘ Bhal Safai ’) • Lettuce Bot (Blue River Technology)— Eliminates Leafy Buds 20x Faster
Humanitarian • Landmine detection • Bomb disposal • Prosthetic limbs—full restoration of original capabilities
Surgical Robots • Surgical robotics-higher precision, repeatability, cost-effective • Significantly lower blood loss • Minimally invasive surgery
Surgical Robots • Flagship--da vinci surgical robot • Surgical robot market to reach significant growth • Market size: $3.2 billion in 2012, anticipated to reach $19.96 billion by 2019
Assistive Robots • Robotic vacuum cleaners • Global market share of robotic vacuum cleaners-- 12% of $680 million
Assistive Robotics • Growing elderly population in developed countries • Demographics to change by 2050 • Over 60 to form 22% of the world population compared to the 11% today • Needs: visual assistance, emergency assistance, mobility assistance
Factories of the Future • Declining costs – Industrial grade manipulators ~ > $100,000 – Baxter (rethink robotics) costs $22,000 • Small & Medium Enterprises (SME’s) entering the fray • Need consistent quality • Lean operation • Higher productivity • Higher accuracy in safety critical applications
Baxter-Capabilities VS
Case Study: China • Low cost robots competing against the minimum wage rate • Youth unwilling to perform manual labor • Delta electronics and foxconn looking to develop a $10,000 robot
Case Study: India • India--Market for Robots Will Increase From 1,547 to 3,500 Units By 2015 • SME’s entering into robotics • Labor is plenty but unskilled • Job hopping
Challenges: Demons of Automation • Unemployment ? – classical debate from romantic era • Worker lay-off • Eventually little or no need for skilled labor • Driving may look obsolete in 25 years – 4 million driving jobs will be lost • Agricultural robotics—farming labor to lose jobs
Challenges: Legal and Ethical • Autonomous driving and legal aspects – Who is driving the car? – Accident and insurance – Passenger safety • Surgical robots – Similar issues – Patient care, liability • Drones (e.g. unmanned aerial vehicles UAVs) – Who pulled the trigger? – Wars and international law • Social Acceptance of Robots
What is in store for developing countries? • A storm is coming? • Major challenges to the social fabric • Raise ethical challenges • From nuclear age to the robotic age • A brave new world?
What is in store for countries like Pakistan? Why Automation in developing countries like Pakistan? • – Devolution of governance – Ensuring rights – Conflict resolution Entitlements Participation Bridging the gap of “expertise” – a different • robotics paradigm • Major challenges Accountability – Natural resources – Food and Agriculture Problems – Critical infra-structures – Security Robotics, AI and automation may be the answer to some of these! •
What is a Motion Planner? High Level Specifications Motion Planner Low Level descriptions of how to move
What is a Motion Planner? High Level Specifications Motion Planner Low Level descriptions of how to move
What is a Motion Planner? High Level Specifications Motion Planner Low Level descriptions of how to move Do this while 1. Avoiding obstacles 2. Obey differential constraints 3. Handle uncertainties 4. Achieve optimality
