Donn ees Manquantes : 2 exemples S eparation de RFI sur SMOS & - PowerPoint PPT Presentation

Donn ees Manquantes : 2 exemples S eparation de RFI sur SMOS & Video Inpainting Andr es Almansa GT SPU Traitement donn ees spatiales 27 septembre, 2014 Andr es Almansa Donn ees Manquantes SMOS images restoration


  1. Donn´ ees Manquantes : 2 exemples S´ eparation de RFI sur SMOS & Video Inpainting Andr´ es Almansa GT SPU ”Traitement donn´ ees spatiales” 27 septembre, 2014 Andr´ es Almansa Donn´ ees Manquantes

  2. SMOS images restoration from L1a data: A sparsity-based variational approach Andr´ es Almansa (Telecom ParisTech) J. Preciozzi, P. Mus´ e (UdelaR) S. Durand (U. Paris Descartes) , A. Khazaal, B. Roug´ e (CESBIO) GT SPU ”Traitement donn´ ees spatiales” 27 septembre, 2014 A. Almansa SMOS images restoration from L1a data

  3. Interferometry principle Measure the phase di ff erence of incident radiation Cross-correlation between all pairs of receivers to obtain the Visibility Function V kl T b can be obtained indirectly from V kl ZZ U k ( ξ ) U ⇤ 1 l ( ξ )˜ r kl ( t ) ( T b ( ξ ) � T r ) e � i 2 π u T kl ξ d ξ V k , l = p Ω k Ω l 1 � || ξ || 2 || ξ ||  1 [Corbella et. al. 2004] A. Almansa SMOS images restoration from L1a data

  4. The MIRAS instrument Antenna configuration Support of T b is the unit circle Optimum sampling grid on visibilities is an hexagonal grid Two possible configurations: triangular or Y shaped arrays Frequency coverage is larger for Y-shaped (but does not cover the entire hexagonal domain) [Camps et al. 1998] A. Almansa SMOS images restoration from L1a data

  5. Recovering T b from visibilities T ZZ U k ( ξ ) U ⇤ 1 l ( ξ )˜ r kl ( t ) z }| { T b ( ξ ) � T r ) e � i 2 π u T kl ξ d ξ V k , l = ( p Ω k Ω l 1 � || ξ || 2 || ξ ||  1 Consider the discrete version of this linear operator, it can be stated by means of matrix G : G T = V dim( T ) > dim( V ): the problem is under constrained A. Almansa SMOS images restoration from L1a data

  6. Generation of L1B: Zero padding regularization Anterrieu 2004 T k V � G T k 2 min 2 s.t. ( I � P Ω ) T = 0 with P Ω = F � 1 Z Ω Z ⇤ Ω F This problem can be reformulated as: A z }| { ˆ G F � 1 Z Ω ˆ t k 2 T = arg min t 2 Ω k V � 2 ˆ ˆ T is SMOS L1B data product, V is SMOS L1A data product T can be simply recovered from ˆ T by T = F � 1 Z Ω ˆ T A. Almansa SMOS images restoration from L1a data

  7. Zero padding limitations Strong Gibbs e ff ects: illegal transmitters introduce outliers Poor spectral extrapolation: limited resolution Direct Method: T b = F � 1 ( ˆ T ) Regularized Method - Blackmann: T b = F � 1 ( B ˆ T ) A. Almansa SMOS images restoration from L1a data

  8. Objetives of the present work Recover the brightness temperature directly from visibilities A. Almansa SMOS images restoration from L1a data

  9. Objetives of the present work Recover the brightness temperature directly from visibilities Remove noise and signal e ff ects generated from illegal emissions (outliers) A. Almansa SMOS images restoration from L1a data

  10. Objetives of the present work Recover the brightness temperature directly from visibilities Remove noise and signal e ff ects generated from illegal emissions (outliers) Extrapolate the image spectrum to minimize Gibbs e ff ects A. Almansa SMOS images restoration from L1a data

  11. Proposed method Main idea : Separate 3 sources u : Original brightness temperature image ) TV semi-norm o : RFI Outliers ) Sparsity norm ( ` 1 or ` 0 ) n : Gaussian measurement noise ) ` 2 data fidelity term A. Almansa SMOS images restoration from L1a data

  12. Variational Formulation Proposed method 8 9 > > > > < 1 = 2 k G ( o + u ) � V k 2 min + � (TV H ( u ) + µ S ( o )) (1) 2 u , o > | {z } > > > | {z } : ; E 2 ( u , o ) E 1 ( u , o ) where µ Trade-o ff between sparsity and regularity � is chosen to satisfy k G ( o + u ) � V k 2 2  | Ω | � 2 TV H ( u ): Total Variation for H -bandlimited images [Moisan 2007] ! reduces staircaising e ff ect [Moisan 2007] How to discretize the total variation of an image? Proc. Appl. Math. Mech., 2007 A. Almansa SMOS images restoration from L1a data

  13. Proposed Method: Numerical Implementation Two stage process: Stage one Solve the minimization problem with sparsity term S ( o ) = k o k 1 the problem is convex can be solved iteratively with a Forward-Backward algorithm converges to a global minimum Stage two Starting from the previous solution, we solve the same problem with S ( o ) = k o k 0 the problem is non-convex due to the ` 0 norm for this functional the Forward-Backward algorithm converges to a local minimum [Blumensath and Davies 2005] A. Almansa SMOS images restoration from L1a data

  14. Proposed Method: Numerical Implementation Algorithm The k -th iteration starting from seed x 0 = ( u 0 , o 0 ) is ⇢ x k +1 / 2 x k � � r E 1 ( x k ) = x k +1 prox γ E 2 ( x k +1 / 2 ) . = Di ff erential operator r E 1 ( u , o ) = ( G ⇤ G ( u + o ) � V , G ⇤ G ( u + o ) � V ) . Proximal operators � � prox γ E 2 ( u , o ) = prox γλ TV ( u ) , prox γλ µ S ( o ) prox γ TV : modified version of [Chambolle 2004] with spectral projection prox γ k · k 1 : the soft-threshold or shrinkage operator prox γ k · k 0 : the hard-threshold operator A. Almansa SMOS images restoration from L1a data

  15. Proposed Method: Numerical Implementation Implementation limitations G ⇤ G is a huge full matrix of size 16384 x 16384 Explicit multiplication by this matrix on each iteration is impractical. Change of basis to Fourier domain: r E 1 ( u , o ) = F ⇤ (( GF ⇤ ) ⇤ GF ⇤ F ( u + o ) � ( GF ⇤ ) ⇤ V ) FG ⇤ GF ⇤ is even bigger than G ⇤ G (32768 ⇥ 32768) but highly sparse: to keep 99 . 99% we need 0 . 008 coe ffi cients. A. Almansa SMOS images restoration from L1a data

  16. Final algorithm Final algorithm 1 Set S ( · ) = k · k 1 2 Initialize � a Iterate until convergence (FB) 8 u k � � F ∗ ( FG ∗ GF ∗ F ( u + o ) � FG ∗ V u k +1 / 2 = > > o k � � F ∗ ( FG ∗ GF ∗ F ( u + o ) � FG ∗ V < o k +1 / 2 = u k +1 prox γλ TV H ( u k +1 / 2 ) = > > : o k +1 s γλ µ ( o k +1 / 2 ) . = b If k GF ∗ F ( o + u ) � V k 2 2 � | Ω | � 2 |  ✏ , update � and go to a) 3 Set S ( · ) = k · k 0 and go to 2) A. Almansa SMOS images restoration from L1a data

  17. Numerical implementation: µ selection We model an outlier as a cylinder c of radius r and height h : µ selection If ` 1 then c is an outlier if TV ( c ) � µ k c k 1 , leading to a µ  2 r If ` 0 then c is an outlier if TV ( c ) � µ k c k 0 , i.e. µ  2 h r A. Almansa SMOS images restoration from L1a data

  18. Experiments on real data Google Earth view of two of the regions used on the experiments. The left one corresponds to snapshot 996 and the right one to snapshot 1050 A. Almansa SMOS images restoration from L1a data

  19. Experiments on real data Comparison between previous works and our method. F � 1 Blackman Using L1b method The proposed method This snapshot corresponds to Central Europe, with Italy clearly visible. Color scale mapped between 0 and 300 K. A. Almansa SMOS images restoration from L1a data

  20. Experiments on real data Comparison between previous works and our method. F � 1 Blackman Using L1b method The proposed method This snapshot corresponds to North Europe. Color scale mapped between 0 and 300 K. A. Almansa SMOS images restoration from L1a data

  21. Experiments on simulated data u gt u L 1 a u L 1 b Temperatures Di ff erence L 1 L 2 L 1 u L 1 a � u gt 3.197598 5.418558 57.679203 u L 1 b � u gt 9.587280 12.994680 87.467700 Results from simulated data. The error is measured over all the image, not only the free of aliasing (FOA) zone. A. Almansa SMOS images restoration from L1a data

  22. Conclusions We propose a variational method to restore images from the L1A SMOS data product. The method models the observations as the superposition of three components on the spatial domain: The target brightness temperature map u The outliers image o due to the illegal emissions A gaussian noise image n The method is numerically tractable by a change of basis from spatial to spectrum domain The method also extrapolates the spectral domain of u thanks to the total variation semi-norm The method is general enough to be used for other restoration problems A. Almansa SMOS images restoration from L1a data

  23. Future work Better separation if RFI are finely localized [Veterli 2002], [Candes 2013], [Duval 2014] More detailed restoration with patch-based (non-local) regularization A. Almansa SMOS images restoration from L1a data
