DOMES - PAVILIONS 2015 info@vikingdome.com www.vikingdome.com +370 - PDF document

May 10, 2023 •124 likes •432 views

DOMES - PAVILIONS 2015 info@vikingdome.com www.vikingdome.com +370 670 03131 RECREATIONAL BUILDING DOME, D34m, ZOOSAFARI, BORYSEW, PL 908 m 2 Floor area Cover Transparent PVC tilt Frame Galvanized steel Entrance 3 entrances O-door,

  1. DOMES - PAVILIONS 2015 info@vikingdome.com www.vikingdome.com +370 670 03131

  2. RECREATIONAL BUILDING – DOME, D34m, ZOOSAFARI, BORYSEW, PL 908 m 2 Floor area Cover Transparent PVC tilt Frame Galvanized steel Entrance 3 entrances O-door, with two- leaved glass doors Diameter 34 m. Height 12 m. Geometry Geodesic dome Icosahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  3. DOME FOR EVENTS & PROJECTIONS, D28m, MOTOR SHOW BOLOGNA, IT Floor m 2 800 m 2 Cover Transparent PVC tilt with extra white tilt, inner tilt for video projections Frame Galvanized steel Entrance 3 entrances O-door, with two-leaved glass doors Diameter 28 m Height 14 m Geometry Geodesic dome Icosahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  4. ICOSAHEDRON DOME D20+D8M TUBE STEEL, SILVER PVC 314m² + 113m 2 Floor area Cover Silver PVC tilt with transparent PVC panoramic window Frame TUBE, stainless steel Entrance 2 entrances O-door, with two-leaved glass doors Diameter 20 m + 8 m Height 10 m + 4 m Geometry Geodesic dome Icosahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  5. ICOSAHEDRON DOMES D20+D13M TUBE STEEL, COLORED PVC Floor area 800 m 2 Cover Cream colour PVC tilt, transparent PVC panoramic window Frame TUBE, stainless steel Entrance 3 entrances O-door, with two-leaved glass doors. Diameter 20 m. + 13m Height 10 m. + 6,5m Geometry Geodesic domesIcosahedron Architector Ri čardas Stulpinas Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  6. ICOSAHEDRON DOMES D20+D6M TUBE STEEL, WHITE PVC BLOCKOUT 314m² + 28m 2 Floor area Cover White PVC BlockOut, for video projection Frame TUBE, galvanized steel Entrance 1 oval entrance O-door with two- leaved plastic doors. Diameter 20 m. + 6 m. Height 10 m. + 3 m. Geometry Geodesic dome Icosahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  7. OCTAHEDRON DOME D15M, TUBE STEEL WHITE AND TRANSPARENT PVC Floor area 177 m 2 Cover White PVC 630 gr/m2, removable transparent PVC panoramic window Frame TUBE, stainless steel Entrance 2 oval entrances O-tent Diameter 15 m. Height 7.5 m. Geometry Geodesic domeOctahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  8. OCTAHEDRON DOME D15M TUBE STEEL, COLORED PVC 177 m 2 Floor area Cover White and red PVC sheet 630 gr/m2 Frame TUBE, stainless steel Entrance 2 entrances Diameter 15 m. Height 7.5 m. Geometry Geodesic dome Icosahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  9. SVYTURYS BEACH BAR / NIDA LT 95 m 2 Floor area Cover White PVC sheet, transparent panoramic window Frame TUBE, steel pipe, painted white Entrance 3 entrances O-door, with two-leaved wooden doors Diameter 11 m. Height 5.5 m. Geometry Geodesic dome Icosahedron Class Special structure info@vikingdome.com www.vikingdome.com +370 670 03131

  10. ICOSAHEDRON DOME D11M TUBE STEEL, RED PVC Floor area 95 m² Cover Red PVC sheet. Front open air. Frame TUBE, steel pipe, painted white Entrance Wide entrance (can be entrance for a car) Diameter 11 m. Height 5,5 m. Geometry Geodesic dome Icosahedron Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  11. ICOSAHEDRON DOME D10M, TUBE STEEL, WHITE AND TRANSPARENT PVC 79 m 2 Floor area Cover White & Transparent PVC sheet Frame TUBE, stainless steel Entrance Wide entrance Entrance 10 m. Height 5 m. Geometry Geodesic dome stage Icosahedron Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  12. MODIFIED OCTAHEDRON DOME WHITE PVC, THERMOINSOLATION Floor area 55 m 2 Cover White PVC sheet with photoprint, thermoinsulation, acoustic textil Frame TUBE, stainless steel Entrance 2 entrances Length,width 10 m. , 6 m. Height 3 m. Geometry Geodesic structure Icosahedron Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  13. OCTAHEDRON DOME D8M TUBE STEEL # WHITE PVC Floor area 50 m² Cover White PVC sheet 630 gr/m2 Frame TUBE, steel pipe, painted grey Entrance 1 entrance, sheet sash fastener Diameter 8 m. Height 4 m. Geometry Geodesic dome Octasahedron, V4 Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  14. ICOSAHEDRON DOME, STAR WOOD FRAME, TRANSPARENT PVC Floor area 28 m 2 Cover Transparent PVC tilt Frame STAR, impregnated wood Entrance 1 entrance Diameter 6 m. Height 3 m. Geometry Geodesic dome Icosahedron V4 Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  15. STAGE DECORATION, ICOSAHEDRON DOME, TUBE STEEL Floor area 28 m 2 Cover - Frame TUBE, steel pipe, painted yellow Entrance Wide entrance Diameter 6 m. Height 3 m. Geometry Geodesic dome Icosahedron Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  16. ICOSAHEDRON DOMES TUBE, WHITE PVC Floor area Cover White PVC sheet with transparent panoramic window Frame Cinkuotas plienas Entrance 1 entrance, sheet sash fastener Diameter 7 m Height 3.5 m Geometry Geodesic dome Icosahedron V4 Class Ordinary structure info@vikingdome.com www.vikingdome.com +370 670 03131

  17. GEODESIC DOME GEOMETRY TECNOLOGY Pavilions, Stages, Pergolas VikingDome design and manufacture a geodesic geometry multi-purpose, fast assembly, temporary and permanent building constructions, structures. Installation does not take much time, so you can quickly assemble and disassemble various size and complexity of the structures. Several domes can be interconnected to create a spectacular modular complex. Each structure can be used as a pavilion, or as Estrada by dismantling part of the pavilion. Frame elements without covers can be used as a decorative sculpture, or pergola can decorate parks, squares, homesteads. Wide choice of sizes, designs, colours and functions. Available sizes – up to 40 meters in diameter. Floor area up to 2000 m 2 . By request the dome frame can be covered with standard roof coverings (bitumen, tin, multi-layer, tilt). Various choice of bearing constructions (frames) TUBE, STAR, BULB connecting systems •The steel frame (stainless, galvanized, painted) •Wooden frame (impregnated, painted) •Fiberglass frame •Aluminium frame info@vikingdome.com www.vikingdome.com +370 670 03131

  18. TUBE CONNECTORS SYSTEM Different lengths of metal parts are connected with screws, ensuring strong and seismically stable aerodynamic construction. Construction frame are made from various types of pipes: stainless or galvanized steel, aluminium. Frame painting posibility with wide choice of desired colours. The temporary structure can be installed on all types of surfaces: asphalt, wooden terraces and elsewhere. It can be attached to the ground or surface with a help of anchors or weights. Permanent structure is attached to a concrete foundation or other solid surface. info@vikingdome.com www.vikingdome.com +370 670 03131

  19. STAR CONNECTORS SYSTEM STAR connectors designed for DIY build the dome-shaped structures. STAR connectors are accurately cut from the steel sheet with laser. The choice of material: • Stainless steel AISI304, unpolished, matte; • Painted steel RAL powder coating ; • Galvanized steel Zn, Hot-dip galvanization 50 mkr; • Galvanized Zn and RAL painted steel . info@vikingdome.com www.vikingdome.com +370 670 03131

  20. BULB CONNECTORS SYSTEM BULB connectors designed for dome-shaped Hexagon type structures. Fast assembling, light weight. The choice of material for hub: • Painted steel RAL powder coating ; • Galvanized steel Zn, Hot-dip galvanization 50 mkr; Galvanized Zn and RAL painted steel . • info@vikingdome.com www.vikingdome.com +370 670 03131

  21. PVC TILT COVER Convincing quality for tents and textile architecture. • Excellent resistance to soiling • Long-term whiteness • Outstanding weather properties • Optimal weldability • High UV resistance All tilt products are seam solder with high frequency equipment, can be welded or sewn. 500-1500 gr/m 2 +37067003131 info@vikingdome.com www.vikingdome.com +370 670 03131

  22. TRANSPARENT PVC TILT COVER Transparent pavilions, greenhouses or window coverings are made from unreinforced or reinforced transparent PVC tilt with coloured decorative elements. Transparent PVC tilt is hardly flammable and has long life, spends UV and solar radiarion required for plant photosynthesis. Easily cleaned with regular detergents, waterproof. Can be used during winter season. All tilt products are seam solder with high frequency equipment, can be welded or sewn. +37067003131 info@vikingdome.com www.vikingdome.com +370 670 03131
