Discovering Gold in Chile Disclaimer These presentation materials - PDF document

1 Discovering Gold in Chile Disclaimer These presentation materials (the Presentation Materials) are being supplied to you for information purposes only. The Presentation Materials have been prepared by and are the sole responsibility of


  1. 1 Discovering Gold in Chile

  2. Disclaimer These presentation materials (the “Presentation Materials”) are being supplied to you for information purposes only. The Presentation Materials have been prepared by and are the sole responsibility of the Company. The Directors of the Company have taken all reasonable care to ensure that the facts stated herein are true to the best of their knowledge, information and belief. These Presentation Materials are being distributed on request in or from the United Kingdom only to persons to whom it may lawfully be communicated (together “Relevant Person”). Any person who is not a Relevant Person should not rely on this document nor taken any action upon it. Loeb Aron & Company Ltd. have approved the Presentation Materials for the purposes of s.21 of FSMA, Loeb Aron & Company Ltd. are authorised and regulated by the Financial Services Authority. These Presentation Materials do not constitute, or form part of, a prospectus relating to the Company, nor do they constitute or contain any invitation or offer to any person to underwrite, subscribe for, or otherwise acquire, or dispose of any shares in the Company or advise persons to do so in any jurisdiction, nor shall it, or any part of it, form the basis of or be relied on in any connection with any contract. No reliance may be placed for any purpose whatsoever on the information or opinions contained in this document or on its completeness and no liability whatsoever is accepted for any loss howsoever arising from any use of this document or its contents otherwise in connection therewith. This document does not constitute a recommendation regarding the shares of the Company. By accepting these Presentation Materials, the Recipient acknowledges that they are intended for them only and neither the Company, nor its advisers nor its representatives accept liability whatsoever for any loss howsoever arising, directly or indirectly, from the use of this document or its contents or otherwise arising in connection therewith. Some statements contained in these Presentation Materials or in documents referred to therein are or may be forward-looking statements. Actual results may differ from those expressed in such statements, depending on a variety of factors. Past performance of the Company cannot be relied on as a guide to future performance. Any forward-looking information contained in these Presentation Materials has been prepared on the basis of a number of assumptions which may prove to be incorrect, and accordingly, actual results may vary. The Presentation Materials are believed to be correct only as at the date of their publication and the Company have no obligation to update the Presentation Materials after that date and give no warranty to any person as to the accuracy or correctness after the date of publication. 2

  3. Catalina Resources PLC – Company Overview • UK-registered Public Limited Company, seeking listing in 2010 • 492,720 ordinary £1 shares in issue; 57 shareholders • Mineral exploration for precious metals in Chile • Operates in Chile through 100%-owned Chilean-registered subsidiary • Strong management; with specific geological skills • Corporate objective of project development to farm-out when appropriate • Our main project is currently: La Falda – a multi-million oz gold-porphyry target with additional epithermal potential • JV on La Falda signed with AIM-listed Minera IRL 3

  4. Catalina Resources PLC - Projects La Falda: (14,387.5 ha) Gold & Silver - Maricunga Belt, Chile Discovery by Catalina of a new Maricunga-style, potentially multi-million oz gold-porphyry Associated epithermal gold potential - typical of these deposits in Chile’s Maricunga Belt NI 43-101 report completed Diamond drilling starting early December 2009 4

  5. Gold Porphyry Deposits of the Maricunga Gold Belt 5

  6. La Falda – Epithermal Mineralisation The La Falda lithocap hosts a well- View of Falda Norte Hill showing high-level epithermal alteration preserved, high-sulphidation epithermal gold system It displays extensive advanced argillic alteration Abundant native sulphur, very high Falda lithocap with advanced levels of mercury (>50ppm) and argillic alteration of stratified high Ag/Au ratios samples indicate volcanoclastic units almost complete preservation of the Silicified Breccia Structures cutting the Falda Lithocap mineralised system Widespread gypsum, seen both as The main epithermal exploration target at La stockwork veins and as alteration, is Falda is a bonanza-grade gold and silver also a feature of both the La Coipa deposit in the 3-14m wide, near-vertical, and Marte mines in the Maricunga silicified breccia structures seen cutting the Belt and the El Indio gold mine lithocap further south 6

  7. La Falda – Gold-bearing banded quartz veins Lithocap Au-Porphyry (Central) Au-Porphyry (Norte) Gold-bearing banded quartz veins at La Falda. Veins similar to these host the main orebodies in the other Maricunga gold-porphyry deposits The exploration targets at La Falda are: A multi-million ounce near-surface gold-porphyry and associated high-grade epithermal gold-silver mineralisation The potential scale of the porphyry target can be extrapolated from Kinross’ Maricunga Mine, Lobo-Marte and Cerro Casale deposits; Andina Minerals’ Volcan Project and Exeter Resource Corporation’s Caspiche deposit 7

  8. Maricunga Gold Porphyry Deposits - Resources Deposit / Owner Category Tonnes Gold Gold Copper Copper (Mt) (g/t) (M Oz) (%) (Mlb) Mine Maricunga Kinross Reserves & 111.5 0.63 2.3 - - Resources Volcan Andina Total M&I 492.5 0.62 9.8 - - Resources Lobo- Kinross Total 106.9 1.71 5.9 - - Marte Resources Caspiche Exeter Inferred 1117.0 0.55 19.6 0.22 4,840 Cerro Barrick 51% Reserves & 1,665.3 0.54 28.8 0.21 7,751 Casale Kinross 49% Resources Kinross produces >200,000 oz per year from its Maricunga Mine 8

  9. La Falda – A Panoramic View, looking south Au-Porphyry Lithocap (Central) Au-Porphyry (Norte) Jeffrey W. Hedenquist, is an independent geological consultant specialising in epithermal and porphyry Cu-Au deposits world-wide. In his February 2008 report, following a field visit to La Falda, he summarised: “ These observations indicate that the very top of the porphyry intrusions is exposed, with both Central and Norte host to banded quartz veins typical of the style of veins that are related to mineralisation in other Maricunga porphyry gold deposits; vertical intervals in these ore deposits are up to at least 300 m. As a result of this strong similarity between La Falda and porphyry gold deposits in the Maricunga district, this prospect has taken on a completely new – and positive - perspective” 9

  10. La Falda Porphyry Norte Pole Reduced Magnetic Map A ground magnetic survey has Falda Norte Structure outlined a large (approximately 2 km by 1 km) weak magnetic high around the underlying intrusive Porphyry Central Magnetic highs (pink) are due to Underlying the presence of magnetite and Intrusive are often flanked and cut by strong magnetic lows (dark blue) Circular Feature Magnetite often accompanies gold in Maricunga gold-porphyries Magnetic lows may represent areas where later alteration has destroyed magnetite Similar patterns are observed in Falda Sur Structure other Maricunga porphyries 10

  11. La Falda – IP – Plan of Chargeability at 4200m Elevn. An Induced Polarisation (IP) survey has revealed a 2.4 by 2 km chargeability anomaly This contains a promising target zone (approximately 2 km E-W by 600 m N-S) encompassing all of the magnetic anomaly The anomaly is probably due to sulphides It suggests a large geological feature (an intrusive gold-porphyry?) not solely epithermal gold in linear fracture zones 200 x 200 m grid 11

  12. La Falda – IP Survey – Stacked Chargeability Sections The IP anomaly is consistent with the presence of sulphides below a depth of approximately 100m - persisting to at least 350-400m These stacked chargeability sections indicate extensive sulphides beneath both the lithocap and the porphyry intrusives Drilling will start at the Porphyry Norte sector and step out along the strike of the anomalies 12

  13. La Falda – IP – Plan of Resistivity at 4200m Elevn . The La Falda resistivity data display anomalies characteristic of other Maricunga gold-porphyries In Maricunga gold deposits, areas of low resistivity may: • flank several sides of a typical deposit • be associated with: � a variety of geological structures � propylitic or argillic alteration Low resistivity may also be found at depth below the central gold-hosting zone Areas of higher resistivity are often associated with banded quartz veining and associated silicification 13

  14. La Falda – IP Survey – Stacked Resistivity Sections At La Falda: A zone of low resistivity underlies the central resistive zone at depths of ~300 m Based on the resistivity data, the priority zone for gold exploration is the central resistive zone between sections 515600E and 517000E. At depth, the entire central resistive zone appears to be underlain by low–resistivity material, consistent with observations at other Maricunga deposits. 14
