Natthawute Sae-Lim, Shinpei Hayashi, and Motoshi Saeki Department of Computer Science School of Computing Tokyo Institute of Technology INTRODUCTION 2 Code smell [1] An indicator of a design flaw or a problem in the source code One of the


  1. Natthawute Sae-Lim, Shinpei Hayashi, and Motoshi Saeki Department of Computer Science School of Computing Tokyo Institute of Technology

  2. INTRODUCTION 2

  3. Code smell [1] An indicator of a design flaw or a problem in the source code One of the factors that cause technical debt Increases code component’s fault-proneness Data Class Feature Envy “Every time you make a “Classes that have fields, kind of change, you have getting and setting to make a lot of little methods for the fields, changes to a lot of and nothing else.” different classes.” [1] M. Fowler. Refactoring: Improving the Design of Existing Code . Addison-Wesley, 1999. 3

  4. Problem The number of code smell is overwhelming 4

  5. Related Work Code Smells Prioritization [ICPC 2016] [MTD 2015] Context-Based Code Smells Towards a Prioritization of Prioritization Code Debt: A Code Smell for Prefactoring Intensity Index Sae-Lim et al. Fontana et al. Code Smells Filtration [CSMR 2004] [ICSE 2015] Using history information to Filtering Code Smells improve design flaws Detection Results detection Fontana et al. Ratiu et al. 5

  6. Related Work Code Smells Prioritization Task relevance Smell severity Code Smells Filtration Historical False positive information 6

  7. Motivation Code Smells Prioritization Task relevance Smell severity No empirical evidence on how developers Code Smells Filtration handle code smells History False positive information 7

  8. Research Questions RQ 1 : What are the factors used by developers in the code smell selection process? RQ 2 : What are the factors used by developers in the code smell prioritization process? 8

  9. STUDY DESIGN 9

  10. Data Collection JabRef Class A God Line 1 Summary Class B Data Line 2 + Class C Blob x5 x22 Description … … Line 3 Line 4 Task Solution Code smell 10

  11. Data Collection Selection Prioritization This smell should be solved This smell should be solved because … (in this order) because … ① Class A God Class C Blob ✔ ② Class B Data Class A God … … Class C Blob ✔ … … x10 Code smells Code smells x10 11

  12. Coding Technique Response Codes It involves many issues. Task relevance It is not a Blob Class after False positive looking into the code. 3 issues came from this Task relevance, single class. This class is Smell severity too generic. 12

  13. RESULTS 13

  14. 15 Final Codes Smell severity Task relevance Smell coupling Task importance Co-located smells Task implementation cost Smell false positive Task implementation risk Testability Module importance Readability Module dependency Maintainability Understandability Refactoring cost 14

  15. RQ 1 : Selection Process Top 5 Factors Code Number of responses 33 Task relevance 11 Smell severity Task implementation cost 5 5 Testability 4 Co-located smells Factors considered together Code Number of responses Task relevance, Smell severity 9 5 Task relevance, Testability 15

  16. RQ 2 : Prioritization Process Top 5 Factors Code Number of responses Module importance 14 10 Task relevance 5 Testability 4 Smell severity 3 Maintainability Factors considered together Code Number of responses Module importance, Task relevance 4 3 Module importance, Testability 16

  17. CONCLUSION 17

  18. Conclusion How do developers select and prioritize code smells? Task relevance Selection: Smell severity Module importance Prioritization: Task relevance 18

  19. Take-home message Factors that have not been considered Testability Factors that have Readability been considered Smell coupling Smell severity Maintainability Task relevance Task importance Smell false positive Refactoring cost Co-located smells Understandability Module importance Module dependency Task implementation risk Task implementation cost 19
