Data Structures in Java Lecture 3: ADTs in Java. 9/16/2015 Daniel - PowerPoint PPT Presentation

Data Structures in Java Lecture 3: ADTs in Java. 9/16/2015 Daniel Bauer 1

Today • ADTs and Data Structures in Java (Generics, Interfaces etc., Java Standard Library) • Linked List Implementation. • Binary Search Example.

Recitation Sessions • Tuesday 7:30pm, 413 Kent • Thursday 7:30pm, 614 Schermerhorn • Friday 2:00pm, 603 Hamilton (NEW) • Also: One more TA, see schedule on website.

Homework 0 and 1 • Some of you still had trouble with HW 0. Had to make sure everyone got set up first. • HW 1 out asap! New due date: Sun 9/27, 11:59pm

Homework Late Policy • You will lose 1% of the total homework score for every 6 minutes your homework is late. • The latest pushed version of your homework will be graded. • Homework submitted later than 10h after the official deadline will receive no credit. • If you need to miss a homework assignment you need to talk to me in advance (except in emergencies… take care of the emergency first!) • Document your code! Undocumented code will result in lower scores.

Outline • Some Java features useful for implementing Data Structures. • Generics, Interfaces, Nested classes. • Iterator, Iterable from the Java API. • Implementation of Linked List. • Implementation of Binary Search. • Lists in the Java Collections API.

Array Lists public class SimpleArrayList { public static final int DEFAULT_CAPACITY = 10; private int theSize; private Integer[] theItems; } 1 7 3 5 2 1 3

Doubly Linked Lists • Also maintain reference to previous node in the list. • Speeds up append at end of list. public class Node { public Integer data; public Node next; public Node prev; public Node(Integer d, Node n, Node p) { data = d; next = n; prev = n; } } head A 0 A 1 A 2 tail A 3

Making ADTs More General • Problem: Our lists can only store Integers. • Possible Solution: Polymorphism. Choose the most general class of items that you expect to see in the List. public class Person {…} Person[] arr = new Person[10];
 public class Employee arr[0] = new Employee(…); extends Person{…} arr[1] = new Student(…); e.g. for an Array public class Student extends Person {…}

Java Generics • We don’t normally know what kind of object to expect in a data structure. • Java allows to add type parameters (<> syntax) to definitions of classes. Such classes are called generic classes. public class MyArrayList<AnyType> { private AnyType[] theItems; ... public AnyType get(int idx) { ... } public boolean add(int idx, AnyType x) { ... } }

Java Generics (2) • Type parameters make it possible to create a new data structure for specific objects (and their sub- types) during runtime. MyArrayList<Integer> l = new MyArrayList<Integer>(); • In Java 7 and 8, this can be simplified using the <> (Diamond) operator: MyArrayList<Integer> l = new MyArrayList<>(); • Type of l is inferred automatically.

Nested Classes • Usually every Java class is defined in its own .java file. • Sometimes classes have a specific purpose (in relation to another class), e.g. Node is specific to MyLinkedList . class OuterClass { ... static class StaticNestedClass { ... } class InnerClass { ... } }

Static Nested Classes public class MyLinkedList<AnyType> implements Iterable<AnyType>{ private static class Node<AnyType> { public Node( AnyType d, Node<AnyType> p, Node<AnyType> n ) { data = d; prev = p; next = n; } public AnyType data; public Node<AnyType> prev; public Node<AnyType> next; } . . . } • Static nested classes cannot access any instance members of the outer class. • They essentially behave like normal top-level classes.

Inner Classes public class MyLinkedList<AnyType> implements Iterable<AnyType>{ private int theSize; private Node<AnyType> beginMarker; private Node<AnyType> endMarker; public java.util.Iterator<AnyType> iterator( ) { return new LinkedListIterator( ); } private class LinkedListIterator implements java.util.Iterator<AnyType> { private Node<AnyType> current = beginMarker.next; ... } } • Instances of inner classes can access instance members of the outer instance that created it.


 For-Each Loops • Iterable s support special Java syntax
 for (T item : someIterable) { System.out.println(item.toString()); } • No need to explicitly get the Iterator and call next() repeatedly.

Java Iterators package java.lang; interface Iterator<T> { boolean hasNext(); T next(); void remove(); } Our LinkedList implementation should be compatible with the Iterator interface. http://docs.oracle.com/javase/7/docs/api/java/util/Iterator.html

The Iterable Interface package java.lang; interface Iterable<T> { Iterator<T> iterator(); } • Using Iterables and Iterators: Iterator<T> someIterator = someIterable.iterator() while (someIterator.hasNext()) { T nextItem = someIterator.next(); System.out.println(nextItem.toString()); } • Don’t implement Iterable and Iterator in the same class! http://docs.oracle.com/javase/7/docs/api/java/lang/Iterable.html

The Comparable Interface compareTo returns
 package java.lang;
 negative int if this < o
 public interface Comparable<AnyType> { positive int if this > o
 int compareTo(AnyType other); } 0 if this == o • comparison usually involves querying some member of other. • The type parameter makes sure that all other objects have these fields. http://docs.oracle.com/javase/7/docs/api/java/lang/Comparable.html

Binary Search Given a sorted list, find the entry with a specific key. x = 1024 A = 0 5 10 13 15 23 23 42 217 1024 4929 1024 •Find entry y in the middle if A: y = A[A.length/2] • if (y == x) we found the entry. • if (y < x) continue search on second half of A. • if (y > x) continue search on first half of A. •In the worst case we need log 2 (length(A)) steps. 19

Binary Search with Comparable public class BinarySearch<AnyType extends Comparable<AnyType>> { public int binarySearch( AnyType [ ] a, AnyType x ) { int low = 0, high = a.length - 1; while( low <= high ) { int mid = ( low + high ) / 2; if( a[ mid ].compareTo( x ) < 0 ) low = mid + 1; else if( a[ mid ].compareTo( x ) > 0 ) high = mid - 1; else return mid; // Found } return -1; } }

Static Generic Methods public static <AnyType extends Comparable<AnyType>> int binarySearch( AnyType [ ] a, AnyType x ) { int low = 0, high = a.length - 1; while( low <= high ) { int mid = ( low + high ) / 2; if( a[ mid ].compareTo( x ) < 0 ) low = mid + 1; else if( a[ mid ].compareTo( x ) > 0 ) high = mid - 1; else return mid; // Found } return -1; }

A Comparable Person Class public class Person implements Comparable<Person> { private String firstName; private String lastName; public Person(String last, String first) { lastName = last; firstName = first; } public int compareTo(Person other) { int lastNameComp = lastName.compareTo(other.lastName); if (lastNameComp == 0) return firstName.compareTo(other.firstName); else return lastNameComp; } }

Searching for Presidents Person[] presidents = { new Person("Adams","John "), new Person("Adams","John Quincy "), new Person("Arthur","Chester Alan "), new Person("Buchanan","James "), new Person("Bush","George "), new Person("Bush","George W."), new Person("Carter","Jimmy "), new Person("Cleveland","Grover "), new Person("Clinton","Bill "), . . . new Person("Washington","George "), new Person("Wilson","Woodrow ") }; int index = BinarySearch.binarySearch(presidents,
 new Person("Obama","Barack")); System.out.println(index);

The Java Collection API package java.util; interface Collection<E> extends Iterable<E> { boolean add(E e); boolean addAll(Collection<? extends E> c); void clear(); boolean contains(Object o); boolean containsAll(Collection<?> c); boolean isEmpty(); Iterator<E> iterator(); // via Iterable boolean remove(Object o); boolean removeAll(Collection<?> c); boolean retainAll(Collection<?> c); int size(); Object[] toArray(); <T> T[] toArray(T[] a); } http://docs.oracle.com/javase/7/docs/api/java/util/Collection.html

Lists in the Java API interface Iterable Iterator (T) iterator() interface Collection interface Set interface Queue interface List Vector interface Dequeue ArrayList Stack LinkedList http://docs.oracle.com/javase/7/docs/api/java/util/Collection.html

Java API List Interface package java.util; interface List<E> extends Collection<E> { E get(int index); int indexOf(Object o); int lastIndexOf(Object o); E remove(int index); E set(int index, E element); List<E> subList(int fromIndex, int toIndex) } http://docs.oracle.com/javase/7/docs/api/java/util/List.html
